other sidewall of the tire, or (2) the
outward facing sidewall of an asymmetri-
cal tire that has a particular side that must
always face outward when mounted on a
vehicle.TYPES OF TIRES
WARNING

When changing or replacing tires, be
sure all four tires are of the same
type (i.e., Summer, All Season or
Snow) and construction. A NISSAN
dealer may be able to help you with
information about tire type, size,
speed rating and availability.

Replacement tires may have a lower
speed rating than the factory
equipped tires, and may not match
the potential maximum vehicle
speed. Never exceed the maximum
speed rating of the tire.

Replacing tires with those not origi-
nally specified by NISSAN could af-
fect the proper operation of the tirepressure monitoring system (TPMS).

For additional information regarding
tires, refer to “Important Tire Safety
Information” (US) or “Tire Safety In-
formation” (Canada) in the Warranty
Information Booklet.
All season tiresNISSAN specifies all season tires on some
models to provide good performance for use all
year round, including snowy and icy road condi-
tions. All season tires are identified by ALL
SEASON and/or M&S on the tire sidewall. Snow
tires have better snow traction than all season
tires and may be more appropriate in some
areas.Summer tiresNISSAN specifies summer tires on some models
to provide superior performance on dry roads.
Summer tire performance in snow and ice will be
substantially reduced. Summer tires do not have
the tire traction rating M&S on the tire sidewall.
If you operate your vehicle in snowy or icy
conditions, NISSAN recommends the use of
snow or all season tires on all four wheels.
Snow tiresIf snow tires are needed, it is necessary to select
tires equivalent in size and load rating to the
original equipment tires. If you do not, it can
adversely affect the safety and handling of your
vehicle.
Generally, snow tires will have lower speed
ratings than factory equipped tires and may not
match the potential maximum vehicle speed.
Never exceed the maximum speed rating of the
tire.
If you operate your vehicle in snowy or icy
conditions, NISSAN recommends the use of
snow or all season tires on all four wheels.
For additional traction on icy roads, studded tires
may be used. However, some provinces and
states prohibit their use. Check local, state and
provincial laws before installing studded tires.
Skid and traction capabilities of studded snow
tires, on wet or dry surfaces, may be poorer than
that of non-studded snow tires.
Maintenance and do-it-yourself
8-35


06.10.24/Z33-D/V5.0


TIRE CHAINS
CAUTION
Tire chains/cables cannot be installed
on 265/35R19 size tires. Installation of
the tire chains/cables on 265/35R19
size tires will cause damage to the ve-
hicle. If you plan to use tire
chains/cables, you should install
245/45R18 size tires on your vehicle.
Use of tire chains may be prohibited according
to location. Check the local laws before installing
tire chains. When installing tire chains, make
sure they are of proper size for the tires on your
vehicle and are installed according to the chain
manufacturer’s suggestions.Use only SAE
class “S” chains.Class “S” chains are used on
vehicles with restricted tire to vehicle clearance.
Vehicles that can use Class “S” chains are
designed to meet the SAE standard minimum
clearances between the tire and the closest
vehicle suspension or body component required
to accommodate the use of a winter traction
device (tire chains or cables). The minimum
clearances are determined using the factory
equipped tire size. Other types may damage
your vehicle. Use chain tensioners when recom-mended by the tire chain manufacturer to ensure
a tight fit. Loose end links of the tire chain must
be secured or removed to prevent the possibility
of whipping action damage to the fenders or
undercarriage. If possible, avoid fully loading
your vehicle when using tire chains. In addition,
drive at a reduced speed. Otherwise, your ve-
hicle may be damaged and/or vehicle handling
and performance may be adversely affected.

Never install the tire chains on a T-type
spare tire.

Do not use the tire chains on dry roads.

Tire chains must be installed only on the
rear wheels and not on the front wheels.
CHANGING WHEELS AND TIRES
Tire rotationTires cannot be rotated in this vehicle, as
front tires are different size from rear tires
and the direction of wheel rotation is fixed
in each tire.
A pin is on the front brake rotor to prevent
the rear wheels from being installed in
place of the front wheels. The spare tire
can be installed in place of the front and
rear wheels. When installing the spare
tire in the front wheel, the hole in the
spare tire wheel must be aligned with the
pin on the brake rotor.
8-36
Maintenance and do-it-yourself


06.10.24/Z33-D/V5.0


1. Wear indicator
2. Wear indicator location markTire wear and damage
WARNING

Tires should be periodically in-
spected for wear, cracking,
bulging or objects caught in the
tread. If excessive wear, cracks,
bulging or deep cuts are found,the tire(s) should be replaced.

The original tires have built-in
tread wear indicators. When the
wear indicators are visible, the
tire(s) should be replaced.

Tires degrade with age and use.
Have tires, including the spare,
over 6 years old checked by a
qualified technician because
some tire damage may not be
obvious. Replace the tires as
necessary to prevent tire failure
and possible personal injury.

Improper service of the spare
tire may result in serious per-
sonal injury. If it is necessary to
repair the spare tire, contact a
NISSAN dealer.

For additional information re-
garding tires, refer to “Impor-
tant Tire Safety Information”
(US) or “Tire Safety Informa-tion” (Canada) in the Warranty
Information Booklet.
Replacing wheels and tiresWhen replacing a tire, use the same size, speed
rating and load carrying capacity as originally
equipped. See “Specifications” in the “9. Tech-
nical and consumer information” section for rec-
ommended types and sizes of tires and wheels.
WARNING

The use of tires other than those
recommended or the mixed use of
tires of different brands, construction
(bias, bias-belted or radial), or tread
patterns can adversely affect the ride,
braking, handling, ground clearance,
body-to-tire clearance, tire chain
clearance, speedometer calibration,
headlight aim and bumper height.
Some of these effects may lead to
accidents and could result in serious
personal injury.

If the wheels are changed for any
SDI1663
Maintenance and do-it-yourself
8-37


06.10.24/Z33-D/V5.0


WHEELS AND TIRES
Road wheelModel Type Position SizeOffset
in (mm)
Coupe AluminumFront 18 x 8JJ 1.18 (30)
Rear 18 x 8-1/2JJ 1.30 (33)
Front 18 x 9JJ* 1.18 (30)
Rear 19 x 10JJ* 1.18 (30)
Roadster AluminumFront 18 x 8JJ 1.18 (30)
Rear 18 x 8-1/2JJ 1.30 (33)TireModel Type Position Size Pressure (COLD)
CoupeConventionalFront 225/45R18 91W 240 kPa (35 psi)
Rear 245/45R18 96W 240 kPa (35 psi)
Front 245/40R18 93W* 240 kPa (35 psi)
Rear 265/35R19 94W* 240 kPa (35 psi)
Spare — T145/80D17 107M 420 kPa (60 psi)
Road-
sterConventionalFront 225/45R18 91W 240 kPa (35 psi)
Rear 245/45R18 96W 240 kPa (35 psi)
Spare — T145/80D17 107M 420 kPa (60 psi)
*: For option
DIMENSIONS AND WEIGHTS
Vehicle body Coupe Roadster
Overall length in (mm) 169.8 (4,314) 169.8 (4,314)
Overall width in (mm) 71.5 (1,815) 71.5 (1,815)
Overall height in (mm) 52.1 (1,323) 52.5 (1,333)
Front tread in (mm) 60.5 (1,536) 60.5 (1,536)
Rear tread in (mm)60.6 (1,540)*1
60.9 (1,546)*260.6 (1,540)
Wheelbase in (mm) 104.3 (2,650) 104.3 (2,650)
Gross vehicle weight rating
(GVWR)lb(kg)
See the F.M.V.S.S. or C.M.V.S.S. cer-
tification label on the driver’s side
lock pillar. Gross axle weight rating
(GAWR)
Front lb(kg)
Rear lb(kg)
*1: For model with 245/45R 18 tires
*2: For model with 265/35R 19 tires
9-8
Technical and consumer information


06.10.24/Z33-D/V5.0


no more than 1/16″smaller than the hole in
the ball mount.

The threaded shank of the hitch ball must be
long enough to be properly secured to the
ball mount. There should be at least 2 threads
showing beyond the lock washer and nut.
Class I hitchClass I trailer hitch equipment (receiver, ball
mount and hitch ball) can be used to tow trailers
of a maximum weight of 2,000 lb(909 kg).
You may add Class I trailer hitch equipment to
the vehicle that has a 2,000 lb(909 kg) maxi-
mum weight rating, but your vehicle is only
capable of towing the maximum trailer weights
shown in the Towing Load/Specification Chart
earlier in this section.
CAUTION

Do not use axle-mounted hitches.

The hitch should not be attached to
or affect the operation of the impact-
absorbing bumper.

Do not modify the vehicle exhaust
system, brake system, etc. to install atrailer hitch.

To reduce the possibility of addi-
tional damage if a vehicle is struck
from the rear, where practical, re-
move the hitch and/or receiver when
not in use.

After the hitch is removed, seal the
bolt holes to prevent exhaust fumes,
water or dust from entering the pas-
senger compartment.

Regularly check that all trailer hitch
mounting bolts are securely mounted.Tire pressures
When towing a trailer, inflate the ve-
hicle tires to the recommended cold
tire pressure indicated on the Tire and
Loading Information label.

Trailer tire condition, size, load rating
and proper inflation pressure should
be in accordance with the trailer and
tire manufacturers’ specifications.
Safety chainsAlways use a suitable chain between a vehicle
and the trailer. The safety chain should be
crossed and should be attached to the hitch, not
to the vehicle bumper or axle. Be sure to leave
enough slack in the chain to permit turning
corners.Trailer lights
CAUTION
When splicing into the vehicle electrical
system, a commercially available
power-type module/converter must be
used to provide power for all trailer
lighting. This unit uses the vehicle bat-
tery as a direct power source for all
trailer lights while using the vehicle tail
light, stoplight and turn signal circuits
as a signal source. The module/
converter must draw no more than 15
milliamps from the stop and tail lamp
circuits. Using a module/converter that
exceeds these power requirements may
damage the vehicle’s electrical system.
See a reputable trailer dealer to obtainTechnical and consumer information
9-19


06.10.24/Z33-D/V5.0


Supplemental restraint system............................... 1-28
Precautions on supplemental restraint
system.................................................................... 1-28
Supplemental side and curtain side-impact
air bag system............................................................ 1-39
Switch
Audio control steering wheel switch ............. 4-29
Hazard warning flasher switch ........................ 2-27
Headlight switch ................................................. 2-24
Ignition switch ........................................................ 5-6
Ignition switch automatic transmission
models .......................................................... 5-7, 5-10
Ignition switch manual transmission
models .......................................................... 5-7, 5-13
Power door lock switch....................................... 3-4
Rear window and outside mirror defroster
switch..................................................................... 2-23
Traction control system (TCS) off switch .... 2-29
Turn signal switch .............................................. 2-26
Vehicle dynamic control (VDC) off switch ... 2-29
T
Tachometer.................................................................... 2-5
Temperature display .................................................... 2-9
Temperature gauge, Engine coolant
temperature gauge ...................................................... 2-5
Theft (NISSAN Vehicle Immobilizer System),
Engine start................................................................. 2-19
Three-way catalyst....................................................... 5-3
Tilting passenger’s seat ............................................. 1-7
Tilting steering wheel ............................................... 3-25
Tire pressure, Low tire pressure warning
light ............................................................................... 2-13Tires
Flat tire ..................................................................... 6-2
Low tire pressure warning system .................... 5-3
Spare tire .............................................................. 8-38
Tire and Loading information label ................. 8-31
Tire and Loading Information label................. 9-11
Tire chains ............................................................ 8-36
Tire dressing ........................................................... 7-4
Tire pressure ........................................................ 8-29
Tire pressure monitoring system (TPMS) ...... 5-3,
6-2
Tire rotation .......................................................... 8-36
Types of tires ....................................................... 8-35
Uniform tire quality grading .............................. 9-22
Wheel/tire size ....................................................... 9-8
Wheels and tires ................................................ 8-29
Top tether strap child restraints ............................ 1-24
Top, Soft top .............................................................. 3-13
Towing
Flat towing ............................................................ 9-21
Tow truck towing ................................................ 6-10
Towing a trailer.................................................... 9-17
Towing load/specification chart ...................... 9-17
Towing safety....................................................... 9-18
TPMS, Tire pressure monitoring system................ 5-3
TPMS, Tire pressure warning system..................... 6-2
Traction control system (TCS)............................... 5-23
Traction control system (TCS) off switch ........... 2-29
Trailer towing .............................................................. 9-17
Transceiver, HomeLink
Universal
Transceiver .................................................................. 2-42
Transmission
Automatic transmission fluid (ATF) ................ 8-12
Driving with automatic transmission ..... 5-7, 5-10Driving with manual transmission .......... 5-7, 5-13
Transmission selector lever lock release ...... 5-13
Transmitter (See remote keyless entry system) ... 3-5
Traveling or registering your vehicle in another
country ............................................................................ 9-9
Trip computer ............................................................... 2-8
Trip odometer ............................................................. 2-10
Trunk
Interior trunk lid release .................................... 3-11
Light ....................................................................... 2-42
Secondary trunk lid release ............................. 3-12
Trunk lid................................................................. 3-10
Turn signal switch ..................................................... 2-26
U
Underbody cleaning .................................................... 7-3
Uniform tire quality grading .................................... 9-22
Up-shift indicator (M/T models) ............................ 5-14
Up-shift indicator setting (rpm) (M/T models) ... 2-10
V
Vanity mirror light ...................................................... 2-41
Vehicle
Dimensions and weights ..................................... 9-8
Identification number (VIN) ................................. 9-9
Loading information............................................ 9-13
Recovery (freeing a stuck vehicle) ................. 6-12
Security system ................................................... 2-18
Vehicle dynamic control (VDC) off switch ... 2-29
Vehicle dynamic control (VDC) system ........ 5-23
Ventilated net seats..................................................... 1-6


06.10.24/Z33-D/V5.0

10-6

Ventilators ...................................................................... 4-8
Voice command (See Bluetooth
Hands-Free
Phone System)........................................................... 4-37
Volt meter ...................................................................... 2-8
W
Warning labels, Air bag warning labels .............. 1-42
Warning light
Air bag warning light .............................. 1-43, 2-14
Anti-lock Braking System (ABS) warning
light......................................................................... 2-11
Brake warning light ............................................ 2-12
Door open warning light ................................... 2-12
Low tire pressure warning light ...................... 2-13
Seat belt warning light ...................................... 2-14
Warning lights ............................................................ 2-11
Warning, Hazard warning flasher switch ............ 2-27
Warning, Tire pressure monitoring system
(TPMS) .................................................................. 5-3, 6-2
Warning, Warning/indicator lights and audible
reminders ..................................................................... 2-11
Warranty, Emission control system warranty ..... 9-23
Washer switch
Rear window wiper and washer switch........ 2-22
Windshield wiper and washer switch ........... 2-21
Washing ......................................................................... 7-2
Waxing............................................................................ 7-3
Weights (See dimensions and weights) ............... 9-8
Wheel/tire size.............................................................. 9-8
Wheels and tires ....................................................... 8-29
Cleaning aluminum alloy wheels ....................... 7-4
Window washer fluid ............................................... 8-14Window(s)
Automatic adjusting function ........................... 2-40
Cleaning................................................................... 7-3
Power windows................................................... 2-38
Windshield wiper and washer switch .................. 2-21
Wiper
Rear window wiper and washer switch........ 2-22
Windshield wiper and washer switch ........... 2-21
Wiper blades ....................................................... 8-18
X
Xenon headlights....................................................... 2-24


06.10.24/Z33-D/V5.0

10-7
