REAR PARCEL BOXPush the upper part of the lid to open the rear
parcel box. For models without the Navigation
system, two boxes are available.
WARNING
Keep rear parcel box lid closed while
driving to help prevent injury in an acci-
dent or a sudden stop.
STOWING GOLF BAGSFollow the instructions here to stow golf bags in
the rear cargo space of your vehicle. Normally
two bags can be stowed in the luggage area
(Coupe models) or one bag in the trunk (Road-
ster models).
However, in some cases you may not be able to
stow the above number of golf bags in your
vehicle, depending on their sizes or types.
Coupe modelsNormally, two standard golf bags can be stowed
across the strut tower bar in the luggage area as
illustrated (A and B). When stowing a golf bag A
in the rear space, insert the top of the golf bag
SIC1977
SIC2196
Instruments and controls
2-37


07.2.9/Z33-D/V5.0


4 Display screen, heater, air conditioner and
audio systemsSafety note .............................................................................. 4-2
Control panel buttons — with navigation system .......... 4-2
Names of the components ............................................ 4-2
How to use joystick and “ENTER” button ................. 4-3
How to use “BACK” button .......................................... 4-3
Setting up the start-up screen ..................................... 4-3
How to use “INFO” button ............................................ 4-3
How to use “SETTING” button .................................... 4-5
How to use the “
” button.................................... 4-8
Ventilators ............................................................................... 4-8
Center ventilators ............................................................ 4-8
Side ventilators ................................................................ 4-8
Heater and air conditioner (Automatic) .......................... 4-9
Automatic operation .................................................... 4-10
Manual operation .......................................................... 4-10
Operating tips ............................................................... 4-11
Servicing air conditioner .................................................. 4-12
Audio system ....................................................................... 4-12
Radio ............................................................................... 4-12
FM radio reception ...................................................... 4-13AM radio reception ...................................................... 4-13
Satellite (SAT) radio reception (if so equipped) ... 4-13
Audio operation precautions ..................................... 4-14
FM-AM radio with compact disc (CD) player ...... 4-19
FM-AM-SAT radio with compact disc (CD)
changer ........................................................................... 4-23
CD care and cleaning ................................................. 4-29
Steering wheel switch for audio control (if so
equipped)......................................................................... 4-29
Antenna ........................................................................... 4-30
Car phone or CB radio .................................................... 4-31
Bluetooth
Hands-Free Phone System with
NISSAN voice recognition (if so equipped) ............... 4-31
Using the system ........................................................... 4-33
Control buttons .............................................................. 4-35
Getting started ............................................................... 4-35
List of voice commands ............................................... 4-37
Speaker adaptation (SA) mode ................................. 4-42
Troubleshooting guide.................................................. 4-45

07.2.9/Z33-D/V5.0


WARNING

Do not disassemble or modify this
system. If you do, it may result in
accidents, fire, or electric shock.

Do not use this system if you notice
any abnormality, such as a frozen
screen or lack of sound. Continued
use of the system may result in acci-
dent, fire or electric shock.

In case you notice any foreign object
in the system hardware, spill liquid
on it, or notice smoke or smell com-
ing from it, stop using the system
immediately and contact a NISSAN
dealer. Ignoring such conditions may
lead to accidents, fire, or electric
shock.When you use this system, make sure the engine
is running.
If you use the system with the engine not
running (ignition ONor ACC) for a long
time, it will use up all the battery power,
and the engine will not start.
Reference symbols:
“ENTER”button
This is a button on the control panel.
“Display”key
This is a select key on the screen. By selecting
this key you can proceed to the next function.
NAMES OF THE COMPONENTS1. JOYSTICK and “ENTER” button
2. “INFO” button
3. “SETTING” button
4. “BACK” button
5. “
” brightness control button
For Navigation System control buttons (other
than above), refer to the separate Navigation
System Owner’s Manual.
SAA1289
SAFETY NOTE
CONTROL PANEL BUTTONS —
WITH NAVIGATION SYSTEM4-2
Display screen, heater, air conditioner and audio systems


07.2.9/Z33-D/V5.0


HOW TO USE JOYSTICK AND
“ENTER” BUTTONChoose an item on the display using the joystick
and push the ENTER button for operation.HOW TO USE “BACK” BUTTONThis button has two functions.
To return to the previous screen:
When this button is pushed during setup, setup
will be canceled, and the screen will return to the
previous screen.
To finish the set-up:
When this button is pushed after setup is com-
pleted, the settings will be renewed as directed,
and the screen will return to the map.
INFO:
When the “BACK” button must be pushed, (for
example, after the setup is finished) instructions
are given in the operation procedure of each
section in this manual. If the “BACK” button is
pushed when not finished with the setup, the
setting will be canceled, and the screen will
return to the previous screen.
SETTING UP THE START-UP
SCREENWhen you turn the ignition key to the ACC
position, the SYSTEM START-UP warning is
displayed on the screen. Read the warning and
select the “OK” key then push the “ENTER”
button.
If you do not push the ENTER button, this
system will not proceed to the next step display.
To proceed to the next step, refer to the separate
Navigation System Owner’s Manual.
HOW TO USE “INFO” BUTTONWhen the “INFO” button is pushed, the “Main-
tenance” screen will be displayed.Maintenance informationTo set the maintenance interval for the Engine
Oil or Oil Filter, choose an item using the joystick
and push the “ENTER” button.
You can also set to display a message to remind
you that the maintenance needs to be per-
formed.
The following example shows how to set the
engine oil change interval. Use the same steps
SAA1290
Display screen, heater, air conditioner and audio systems
4-3


07.2.9/Z33-D/V5.0


Maintenance noticeThe “Maintenance Notice” screen (“ENGINE
OIL” or “OIL FILTER”) will be automatically
displayed as shown when both of the following
conditions are met:

the vehicle is driven the set distance and the
ignition switch is turned OFF.

the ignition switch is turned ON the next time
the vehicle will be driven.
To return to the previous display after the
“Maintenance Notice” screen is displayed,
push the “BACK” button.The “Maintenance Notice” screen displays
each time the ignition switch is turned ON until
one of the following conditions are met:

“Reset Distance” is selected.

“Interval Reminder” is set OFF.

the maintenance interval is set again.*: Refer to the separate Navigation System
Owner’s Manual.
HOW TO USE “SETTING” BUTTONThe “Settings” screen will appear when the
“SETTING” button is pushed.
SAA1332
SAA1292
Engine Oil
1
/Oil Filter
2
SAA1293
Display screen, heater, air conditioner and audio systems
4-5


07.2.9/Z33-D/V5.0


Cleaning exterior and interior .......................... 7-2, 7-5
Clock ............................................................................ 2-30
Clutch fluid.................................................................. 8-13
Coat hooks ................................................................. 2-38
Cold weather driving ................................................ 5-25
Command (See Bluetooth
Hands-Free
Phone System)........................................................... 4-37
Compact Disc (CD) changer (See audio
system) ......................................................................... 4-26
Compact Disc (CD) player (See audio
system) ......................................................................... 4-21
Compact spare tire ................................................... 8-38
Console box................................................................ 2-35
Control panel buttons (models with navigation
system) ........................................................................... 4-2
Controls
Control panel buttons (display with
navigation system) ................................................ 4-2
Heater and air conditioner controls
(automatic) .............................................................. 4-9
Steering wheel audio controls ........................ 4-29
Coolant
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Checking engine coolant level........................... 8-8
Corrosion protection ................................................... 7-6
Cruise control............................................................. 5-16
Cup holders ................................................................ 2-33
Curtain side-impact air bag system ..................... 1-39
D
Daytime running light system ................................. 2-25Defroster switch, Rear window and outside
mirror defroster switch ............................................. 2-23
Dimensions and weights ............................................ 9-8
Display controls (See control panel buttons),
With navigation system .............................................. 4-2
Door open warning light .......................................... 2-12
Drive belts ................................................................... 8-16
Driving
Cold weather driving ......................................... 5-25
Driving with automatic transmission ..... 5-7, 5-10
Driving with manual transmission .......... 5-7, 5-13
Precautions when starting and driving ............ 5-2
E
Economy, Fuel............................................................ 5-18
Elapsed time ............................................................... 2-10
Emission control information label ........................ 9-10
Emission control system warranty......................... 9-23
Engine
Before starting the engine .................................. 5-9
Break-in schedule............................................... 5-18
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Changing engine oil and filter ......................... 8-10
Checking engine coolant level........................... 8-8
Checking engine oil level .................................... 8-9
Coolant temperature gauge ............................... 2-5
Engine block heater ........................................... 5-26
Engine compartment check locations.............. 8-7
Engine cooling system ......................................... 8-8
Engine oil................................................................. 8-9
Engine oil and oil filter recommendation......... 9-5Engine oil viscosity ............................................... 9-5
Engine serial number ......................................... 9-10
Engine specifications ........................................... 9-7
If your vehicle overheats ...................................... 6-9
Oil pressure gauge ............................................... 2-7
Starting the engine ............................................... 5-9
Event data recorders ................................................ 9-25
Exhaust gas (Carbon monoxide).............................. 5-2
F
F.M.V.S.S./C.M.V.S.S. certification label ............. 9-10
Filter, Air cleaner housing filter .............................. 8-18
Filter, Changing engine oil and filter .................... 8-10
Flashers (See hazard warning flasher switch) ... 2-27
Flat tire............................................................................ 6-2
Flat towing .................................................................. 9-21
Floor mat cleaning ....................................................... 7-5
Fluid
Automatic transmission fluid (ATF) ................ 8-12
Brake and clutch fluid ....................................... 8-13
Brake fluid............................................................. 8-13
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Engine coolant ....................................................... 8-8
Engine oil................................................................. 8-9
Power steering fluid ........................................... 8-12
Window washer fluid ......................................... 8-14
FM-AM radio with Compact Disc (CD)
player ............................................................................ 4-19
FM-AM-SAT radio with Compact Disc (CD)
changer ........................................................................ 4-23
Front manual seat adjustment .................................. 1-3
Front passenger air bag and status light ............ 1-36


07.2.9/Z33-D/V5.0

10-2
