IP-12
INSTRUMENT PANEL ASSEMBLY
Revision: 2006 November2007 350Z
[ ]:number indicates step in removal procedures.
NOTE:
*1: Console rear pocket and coin holder bracket assembly. Refer to IP-16, "
CENTER CONSOLE" .
*2: Audio, Instrument upper box, and triple meter assembly. Refer to IP-17, "
CLUSTER LID C" .
REMOVAL
(A) Kicking Plate (RH/LH)
Remove kicking plate (RH/LH). Refer to EI-35, "BODY SIDE TRIM" .
(B) Foot Rest
Remove foot rest. Refer to EI-43, "FLOOR TRIM" .
(C) Dash Side Finisher (RH/LH)
1. Remove plastics nut.
2. Remove dash side finisher (RH/LH).
(D) Instrument Driver Panel Lower
1. Remove screws.
2. Remove data link connector.
3. Pull to disengage metal clip by removing panel in horizontal direction.
4. Disconnect in-vehicle sensor and each electrical parts.
5. Remove the grommet, and remove hood lock cable.
(E) Steering Column Lower Cover
1. Remove screws.
2. Disengage the tab, remove only lower side. (Upper side is integrated in combination meter.)
(F) Combination Meter
After removing bolts, remove harness connector.
(G) Spiral cable
Remove bolts and remove spiral cable. Refer to SRS-42, "SPIRAL CABLE" .
PIIA2271E
PIIA2270E
