FRONT DOOR GLASS AND REGULATOR
Revision: 2006 November2007 350Z
REGULATOR ASSEMBLY
Removal
1. Remove front door finisher. Refer to GW-51, "DOOR GLASS" .
2. Remove mounting bolts, and remove module assembly.
3. Disconnect harness connector for the module assembly, and
unclip the harness from the back.
Installation
Install in the reverse order of removal.
Inspection after Removal
Check regulator assembly for the following items. If a malfunction is
detected, replace or grease it.
Wire wear
Regulator deformation
Grease condition for each sliding part
The arrows in the figure show the application points of body grease.
Disassembly and AssemblyNIS00058
REGULATOR ASSEMBLY
Disassembly
Remove power window motor and guide rail from module assem-
bly.
Assembly
Assemble in the reverse order of removal.
Inspection after InstallationNIS00059
SETTING OF LIMIT SWITCH
If any of the following work has been done, set the limit switch (integrated in the motor).
Removal and installation of regulator.
Removal and installation of motor from regulator.
Operate the regulators as a unit.
Removal and installation of the glass.
Resetting
After installing each component to the vehicle, follow the steps below.
SIIA0287E
PIIA2162E
PIIA2163E
FRONT DOOR GLASS AND REGULATOR
GW-53
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2006 November2007 350Z
1. With the door open, lift up and hold the power window switch until the door glass is fully closed.
2. Get inside the vehicle and close the door.
NOTE:
You need to close the door so the door switch is fully depressed.
3. Press and hold the reset switch. While holding the reset switch, press down and hold the power window
switch until the door glass is fully opened.
4. Relese the reset switch.Then, lift up and hold the power window
switch until the door glass is fully closed.
5. Open the door to release the door switch. The door glass should
partially move down.
CAUTION:
Do not use the window auto function.
Do not release the switch before the window is fully
stopped.
FITTING INSPECTION
Check that glass is securely fit into glass run groove.
Lower glass slightly [approx. 10 to 20 mm (0.39 to 0.79 in)] and check the distance between the edge of
glass and the body side welt. If the distance is not constant, adjust the glass position by loosening and
tightening following bolts.
–Regulator mounting bolt and nut
–Glass and guide rail mounting bolt
Raise the glass fully and adjust the glass top end and body side
welt fitting with the adjusting bolt at the lower of the regulator
rear rail.
NOTE:
Turn the adjusting bolt clockwise to move the door glass
upper end outward.
Turn the adjusting bolt counterclockwise to move the door
glass upper end inward.
If water leaks, repair the fitting (Roadster only). Refer to RF-
11 6 , "Repairing Method for Water Leakage Around Doors" .
