FL-12
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2006 November2007 350Z
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Standard and LimitNBS000J2
Tightening TorqueNBS000J3
Unit : N·m (kg-m, ft-lb)
N·m (kg-m, in-lb)* Fuel tank capacity
Approx. 76 (20 US gal, 16-3/4 Imp gal)
Fuel recommendation Refer to GI-5
Main fuel level sensor unit, fuel filter and fuel pump assembly 2.0 - 2.5 (0.20 - 0.26, 18 - 22)*
Sub fuel level sensor unit 2.0 - 2.5 (0.20 - 0.26, 18 - 22)*
Fuel tank mounting band 37.0 - 49.0 (3.8 - 5.0, 28 - 36)
Fuel filler tube 10.9 - 14.7 (1.1 - 1.5, 8 - 10)
Fuel tank protector 10.9 - 14.7 (1.1 - 1.5, 8 - 10)
