ENGINE OIL
LU-7
C
D
E
F
G
H
I
J
K
L
MA
LU
Revision: 2006 November2007 350Z
OIL PRESSURE CHECK
WARNING:
Be careful not to burn yourself, as engine oil may be hot.
Oil pressure check should be done in “Neutral position” (M/T models) or “Parking position” (A/T
models).
1. Check the engine oil level. Refer to LU-6, "
ENGINE OIL LEVEL" .
2. Remove undercover with power tool.
3. Disconnect harness connector at oil pressure sensor, and
remove oil pressure sensor using deep socket (commercial ser-
vice tool).
CAUTION:
Do not drop or shock oil pressure sensor.
4. Install the oil pressure gauge (SST) and hose (SST).
5. Start the engine and warm it up to normal operating temperature.
6. Check the engine oil pressure with engine running under no-load.
NOTE:
When the engine oil temperature is low, the engine oil pressure becomes high.
Engine oil pressure [Engine oil temperature at 80 °C (176 °F)]
kPa (kg/cm2 , psi)
If difference is extreme, check engine oil passage and oil pump for engine oil leaks.
7. After the inspections, install oil pressure sensor as follows:
a. Remove old liquid gasket adhering to oil presser sensor and the mating surface.
b. Apply liquid gasket and tighten oil pressure sensor to the specification.
Use Genuine RTV Silicone Sealant or equivalent. Refer to GI-45, "
RECOMMENDED CHEMICAL
PRODUCTS AND SEALANTS" .
c. After warming up engine, make sure there is no leakage of engine oil with running engine.
Changing Engine OilNBS0001F
WARNING:
Be careful not to burn yourself, as engine oil may be hot.
1 : Oil pressure switch
A: 2WD
: Engine front
PBIC4933E
SLC926
Engine speed Approximate discharge pressure
Idle speed More than 98 (1.0, 14)
2,000 rpm More than 294 (3.0, 43)
: 14.7 N·m (1.5 kg-m, 11 ft-lb)
OIL FILTER
LU-9
C
D
E
F
G
H
I
J
K
L
MA
LU
Revision: 2006 November2007 350Z
OIL FILTERPFP:15208
Removal and InstallationNBS0001G
REMOVAL
WARNING:
Be careful not to get burned when engine and engine oil may be hot.
CAUTION:
Oil filter is provided with relief valve. Use Genuine NISSAN Oil Filter or equivalent.
When removing, prepare a shop cloth to absorb any engine oil leakage or spillage.
Do not allow engine oil to adhere to drive belts.
Completely wipe off any engine oil that adheres to engine and vehicle.
1. Remove undercover with power tool.
2. Using oil filter wrench [SST: KV10115801(J38956)] (B), remove
oil filter.
INSTALLATION
1. Remove foreign materials adhering to oil filter installation surface.
2. Apply engine oil to the oil seal contact surface of new oil filter.
3. Screw oil filter manually until it touches the installation surface,
then tighten it by 2/3 turn. Or tighten to specification.
INSPECTION AFTER INSTALLATION
1. Check the engine oil level. Refer to LU-6, "ENGINE OIL" .
2. Start engine, and check there is no leaks of engine oil.
3. Stop engine and wait for 10 minutes.
4. Check the engine oil level and adjust engine oil. Refer to LU-6, "
ENGINE OIL" .
A: 2WD
: Engine front
PBIC4934E
SMA010
Oil filter:
: 17.7 N·m (1.8 kg-m, 13 ft-lb)
SMA229B
