WATER OUTLET AND WATER PIPING
CO-29
C
D
E
F
G
H
I
J
K
L
MA
CO
Revision: 2006 November2007 350Z
CAUTION:
Be careful not to damage engine coolant temperature sensor.
8. Remove oil level gauge and guide. Refer to EM-44, "
FRONT TIMING CHAIN CASE" .
9. Remove water outlet, heater pipe, water bypass hoses and water pipe.
INSTALLATION
Note the following, and install in the reverse order of removal.
Securely insert each hose, and install clamp at a position where it does not interfere with the pipe bulge.
When inserting water pipe into water outlet, apply neutral detergent to O-ring.
INSPECTION AFTER INSTALLATION
Check for leaks of engine coolant using radiator cap tester adapter (commercial service tool) and radiator
cap tester (commercial service tool). Refer to CO-10, "
LEAK CHECK" .
Start and warm up engine. Visually make sure that there is no leaks of engine coolant.
CO-30
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2006 November2007 350Z
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00100
Standard and LimitNBS00025
ENGINE COOLANT CAPACITY (APPROXIMATE)
Unit: (US qt, Imp qt)
RADIATOR
Unit: kPa (kg/cm2 , psi)
THERMOSTAT
Engine coolant capacity (With reservoir tank at “MAX” level) 9.0 (9-1/2, 7- 7/8)
Reservoir tank engine coolant capacity (At “MAX” level) 0.8 (7/8, 3/4)
Cap relief pressureStandard 108 - 127 (1.1 - 1.3, 16 - 18)
Limit 88 (0.9, 13)
Leakage test pressure157 (1.6, 23)
Valve opening temperature 82°C (180°F)
Maximum valve lift 9.0 mm / 95°C (0.354 in / 203°F)
Water closing temperature 77°C (171°F)
