Page 112 of 720

NISSAN 350Z 2007 Z33 Engine Control Workshop Manual EC-112
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
81
82
85
86
89
90R/B
L/R
BR
W/B
G/Y
Y/RFuel injector No. 3
Fuel injector No. 6
Fuel injector No. 2
Fuel injector No. 5
Fuel injector No. 1
Fu

Page 113 of 720

NISSAN 350Z 2007 Z33 Engine Control Workshop Manual TROUBLE DIAGNOSIS
EC-113
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2006 November2007 350Z
98 SBAccelerator pedal position
sensor 2[Ignition switch: ON]
Engine stopped
Accelerator pedal: Fully released1.9

Page 114 of 720

NISSAN 350Z 2007 Z33 Engine Control Workshop Manual EC-114
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
: Average voltage for pulse signal (Actual pulse signal can be confirmed by oscilloscope.)110 Y Engine speed output signal[Engine is running]

Page 117 of 720

NISSAN 350Z 2007 Z33 Engine Control Workshop Manual TROUBLE DIAGNOSIS
EC-117
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2006 November2007 350Z
ENGINE CONTROL COMPONENT PARTS/CONTROL SYSTEMS APPLICATION
ItemDIAGNOSTIC TEST MODE
WORK
SUPPORTSELF-DIAGNOSTIC
RE

Page 118 of 720

NISSAN 350Z 2007 Z33 Engine Control Workshop Manual EC-118
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
X: Applicable
*1: This item includes 1st trip DTCs.
*2: This mode includes 1st trip freeze frame data or freeze frame data. The items appear o

Page 119 of 720

NISSAN 350Z 2007 Z33 Engine Control Workshop Manual TROUBLE DIAGNOSIS
EC-119
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2006 November2007 350Z
*: This function is not necessary in the usual service procedure.
SELF-DIAG RESULTS MODE
Self Diagnostic Item
Regard

TROUBLE DIAGNOSIS
EC-119
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2006 November2007 350Z
*: This function is not necessary in the usual service procedure.
SELF-DIAG RESULTS MODE
Self Diagnostic Item
Regarding items of DTC and 1st trip DTC, refer to EC-48, "EMISSION-RELATED DIAGNOSTIC INFORMA-
TION ITEMS" .)
Freeze Frame Data and 1st Trip Freeze Frame Data
EVAP SYSTEM CLOSE CLOSE THE EVAP CANISTER VENT CONTROL VALVE IN
ORDER TO MAKE EVAP SYSTEM CLOSE UNDER THE
FOLLOWING CONDITIONS.
IGN SW ON
ENGINE NOT RUNNING
AMBIENT TEMPERATURE IS ABOVE 0°C (32°F).
NO VACUUM AND NO HIGH PRESSURE IN EVAP SYS-
TEM
FUEL TANK TEMP. IS MORE THAN 0°C (32°F).
WITHIN 10 MINUTES AFTER STARTING EVAP SYS-
TEM CLOSE
WHEN TRYING TO EXECUTE EVAP SYSTEM CLOSE
UNDER THE CONDITION EXCEPT ABOVE, CONSULT-
III WILL DISCONTINUE IT AND DISPLAY APPROPRI-
ATE INSTRUCTION.
NOTE:
WHEN STARTING ENGINE, CONSULT-III MAY DIS-
PLAY “BATTERY VOLTAGE IS LOW. CHARGE BAT-
TERY”, EVEN IN USING CHARGED BATTERY.When detecting EVAP vapor leak
point of EVAP system
VIN REGISTRATION
IN THIS MODE, VIN IS REGISTERED IN ECM. When registering VIN in ECM
EXH V/T CONTROL LEARN
IN THIS MODE, OPERATION TO LEARN EXHAUST
VALVE TIMING CONTROL MAGNET RETARDER
CHARACTERISTIC.When learning the exhaust valve
timing control
TARGET IDLE RPM ADJ*
IDLE CONDITION When setting target idle speed
TARGET IGN TIM ADJ*
IDLE CONDITION When adjusting target ignition tim-
ing WORK ITEM CONDITION USAGE
Freeze frame data
item*Description
DIAG TROUBLE
CODE
[PXXXX]
The engine control component part/control system has a trouble code, it is displayed as PXXXX. (Refer to
EC-8, "
INDEX FOR DTC" .)
FUEL SYS-B1
“Fuel injection system status” at the moment a malfunction is detected is displayed.
One mode in the following is displayed.
Mode2: Open loop due to detected system malfunction
Mode3: Open loop due to driving conditions (power enrichment, deceleration enleanment)
Mode4: Closed loop - using oxygen sensor(s) as feedback for fuel control
Mode5: Open loop - has not yet satisfied condition to go to closed loop FUEL SYS-B2
CAL/LD VALUE [%]
The calculated load value at the moment a malfunction is detected is displayed.
COOLANT TEMP
[°C] or [°F]
The engine coolant temperature at the moment a malfunction is detected is displayed.
L-FUEL TRM-B1 [%]
“Long-term fuel trim” at the moment a malfunction is detected is displayed.
The long-term fuel trim indicates much more gradual feedback compensation to the base fuel schedule
than short-term fuel trim. L-FUEL TRM-B2 [%]
S-FUEL TRM-B1 [%]
“Short-term fuel trim” at the moment a malfunction is detected is displayed.
The short-term fuel trim indicates dynamic or instantaneous feedback compensation to the base fuel
schedule. S-FUEL TRM-B2 [%]

Page 120 of 720

NISSAN 350Z 2007 Z33 Engine Control Workshop Manual EC-120
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
*: This item is the same as that of 1st trip freeze frame data.
DATA MONITOR MODE
Monitored Item
×: Applicable ENGINE SPEED
[rpm]
The engin

EC-120
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
*: This item is the same as that of 1st trip freeze frame data.
DATA MONITOR MODE
Monitored Item
×: Applicable ENGINE SPEED
[rpm]
The engine speed at the moment a malfunction is detected is displayed.
VEHICL SPEED
[km/h] or [mph]
The vehicle speed at the moment a malfunction is detected is displayed.
ABSOL TH-P/S [%]
The throttle valve operating angle at the moment a malfunction is detected is displayed.
B/FUEL SCHDL
[msec]
The base fuel schedule at the moment a malfunction is detected is displayed.
INT/A TEMP SE
[°C] or [°F]
The intake air temperature at the moment a malfunction is detected is displayed. Freeze frame data
item*Description
Monitored item [Unit] Description Remarks
ENG SPEED [rpm]
Indicates the engine speed computed from the signals
of the crankshaft position sensor (POS) and camshaft
position sensor (PHASE).Accuracy becomes poor if engine speed drops
below the idle rpm.
If the signal is interrupted while the engine is
running, an abnormal value may be indicated.
MAS A/F SE-B1 [V]
The signal voltage of the mass air flow sensor is dis-
played.
When the engine is stopped, a certain value is
indicated.
When engine is running specification range is
indicated in “SPEC”. MAS A/F SE-B2 [V]
B/FUEL SCHDL [msec]
“Base fuel schedule” indicates the fuel injection pulse
width programmed into ECM, prior to any learned on
board correction.When engine is running specification range is
indicated in “SPEC”.
A/F ALPHA-B1 [%]
The mean value of the air-fuel ratio feedback correc-
tion factor per cycle is indicated.
When the engine is stopped, a certain value is
indicated.
This data also includes the data for the air-fuel
ratio learning control.
When engine is running specification range is
indicated in “SPEC”. A/F ALPHA-B2 [%]
COOLAN TEMP/S [°C]
or [°F]
The engine coolant temperature (determined by the
signal voltage of the engine coolant temperature sen-
sor) is displayed.When the engine coolant temperature sensor
is open or short-circuited, ECM enters fail-safe
mode. The engine coolant temperature deter-
mined by the ECM is displayed.
A/F SEN1 (B1) [V]
The A/F signal computed from the input signal of the
A/F sensor 1 is displayed.
A/F SEN1 (B2) [V]
HO2S2 (B1) [V]
The signal voltage of the heated oxygen sensor 2 is
displayed.
HO2S2 (B2) [V]
HO2S2 MNTR(B1)
[RICH/LEAN]
Display of heated oxygen sensor 2 signal:
RICH: Means the amount of oxygen after three way
catalyst is relatively small.
LEAN: Means the amount of oxygen after three way
catalyst is relatively large.
When the engine is stopped, a certain value is
indicated.
HO2S2 MNTR(B2)
[RICH/LEAN]
VHCL SPEED SE [km/
h] or [mph]
The vehicle speed computed from the vehicle speed
signal sent from combination meter is displayed.
BATTERY VOLT [V]
The power supply voltage of ECM is displayed.
ACCEL SEN 1 [V]
The accelerator pedal position sensor signal voltage is
displayed.ACCEL SEN 2 signal is converted by ECM
internally. Thus, it differs from ECM terminal
voltage signal. ACCEL SEN 2 [V]

Page 121 of 720

NISSAN 350Z 2007 Z33 Engine Control Workshop Manual TROUBLE DIAGNOSIS
EC-121
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2006 November2007 350Z
TP SEN 1-B1 [V]The throttle position sensor signal voltage is dis-
played.THRTL SEN 2-B1 signal is converted by EC

TROUBLE DIAGNOSIS
EC-121
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2006 November2007 350Z
TP SEN 1-B1 [V]The throttle position sensor signal voltage is dis-
played.THRTL SEN 2-B1 signal is converted by ECM
internally. Thus, it differs from ECM terminal
voltage signal. TP SEN 2-B1 [V]
FUEL T/TMP SE [°C]
or [°F]
The fuel temperature (determined by the signal volt-
age of the fuel tank temperature sensor) is displayed.
INT/A TEMP SE [°C] or
[°F]
The intake air temperature (determined by the signal
voltage of the intake air temperature sensor) is indi-
cated.
EVAP SYS PRES [V]
The signal voltage of EVAP control system pressure
sensor is displayed.
FUEL LEVEL SE [V]
The signal voltage of the fuel level sensor is displayed.
START SIGNAL [ON/
OFF]
Indicates start signal status [ON/OFF] computed by
the ECM according to the signals of engine speed and
battery voltage.After starting the engine, [OFF] is displayed
regardless of the starter signal.
CLSD THL POS [ON/
OFF]
Indicates idle position [ON/OFF] computed by ECM
according to the accelerator pedal position sensor sig-
nal.
AIR COND SIG [ON/
OFF]
Indicates [ON/OFF] condition of the air conditioner
switch as determined by the air conditioner signal.
P/N POSI SW
[ON/OFF]
Indicates [ON/OFF] condition from the park/neutral
position (PNP) switch signal.
PW/ST SIGNAL [ON/
OFF]
[ON/OFF] condition of the power steering system
(determined by the signal voltage of the power steer-
ing pressure sensor) is indicated.
LOAD SIGNAL [ON/
OFF]
Indicates [ON/OFF] condition from the electrical load
signal.
ON: Rear window defogger switch is ON and/or light-
ing switch is in 2nd position.
OFF: Both rear window defogger switch and lighting
switch are OFF.
IGNITION SW
[ON/OFF]
Indicates [ON/OFF] condition from ignition switch sig-
nal.
HEATER FAN SW
[ON/OFF]
Indicates [ON/OFF] condition from the heater fan
switch signal.
BRAKE SW
[ON/OFF]
Indicates [ON/OFF] condition from the stop lamp
switch signal.
INJ PULSE-B1 [msec]
Indicates the actual fuel injection pulse width compen-
sated by ECM according to the input signals.When the engine is stopped, a certain com-
puted value is indicated.
INJ PULSE-B2 [msec]
IGN TIMING [BTDC]
Indicates the ignition timing computed by ECM
according to the input signals.When the engine is stopped, a certain value is
indicated.
CAL/LD VALUE [%]
“Calculated load value” indicates the value of the cur-
rent air flow divided by peak air flow.
MASS AIRFLOW [g·m/
s]
Indicates the mass air flow computed by ECM accord-
ing to the signal voltage of the mass air flow sensor.
PURG VOL C/V [%]
Indicates the EVAP canister purge volume control
solenoid valve control value computed by the ECM
according to the input signals.
The opening becomes larger as the value increases.
INT/V TIM(B1) [°CA]
Indicates [°CA] of intake camshaft advanced angle.
INT/V TIM(B2) [°CA]
EXH/V TIM B1 [°CA]
Indicates [°CA] of exhaust camshaft retarded angle.
EXH/V TIM B2 [°CA] Monitored item [Unit] Description Remarks

Load next 8 pages

Page: < prev 1-10 ... 33-40 41-48 49-56 57-64 65-72 73-80 81-88 89-96 97-104 ... 448 next >

carplay height alternator belt fuse chart dead battery fog light bulb
