2007 MERCEDES-BENZ SLR CLASS headlamp

129 Controls in detail
Control system
Settings menu
In the
Settings menu there are two
functions:

The function Press reset button for
3 seconds
with which you can reset
most the settings to those set at the
factory.

A collection of submenus with which
you can make individual settings for
your vehicle.
The following settings and submenus are
available:Resetting to factory settings
You can reset the functions of most sub-
menus to the factory settings.
For safety, the
Light circuit Headlamp
mode
submenu in the Lighting menu can
be reset with the vehicle at standstill only.
Press button è or ÿ repeatedly
until the
Settings... menu appears in
the multifunction display.
Press the reset button in the instru-
ment cluster (
page 114) for approxi-
mately 3 seconds.
In the right multifunction display you
will see the request to press the reset
button again to confirm.
Press the reset button again.
The functions of most the submenus
will reset to factory settings.
FunctionPage
Resetting to factory settings129
Submenus in the Settings menu130
Instrument cluster submenu132
Time submenu133
Lighting submenu134
Vehicle submenu138
iThe settings you have changed will not be re-
set unless you confirm the action by pressing the
reset button a second time. After approximately
5 seconds, the
Settings... menu reappears
in the multifunction display.

131 Controls in detail
Control system
The table below shows what settings can
be changed within the various menus.
Detailed instructions on making individual
settings can be found on the following
pages.
Instrument clusterTimeLightingVehicle
(page 132)(page 133)(page 134)(page 138)
Selecting digital speedometer
display modeSetting time (hours)Setting daytime running lamp
mode (USA only)Setting station selection mode
(radio)
Selecting standard displaySetting time (minutes)Setting locator lightingSetting automatic locking
Selecting languageSetting night security illumina-
tion (Headlamps delayed
switch-off)
Setting interior lighting delayed
switch-off

134 Controls in detail
Control system
Setting time (hours)
Move the selection marker with button
æ orç to the
Time submenu.
Press buttonj ork repeatedly
until this message appears in the left
multifunction display:
Set time Hour.
The selection marker is on the hour
setting.
Press buttonæ orç to set the
hour.Setting time (minutes)
Move the selection marker with button
æ orç to the
Time submenu.
Press buttonj ork repeatedly
until this message appears in the left
multifunction display:
Set time
Minute(s)
.
The selection marker is on the minute
setting.
Press buttonæ orç to set the
minutes.Lighting submenu
Access the
Lighting submenu via the
Settings menu. Use the Lighting sub-
menu to change the lamp and lighting
settings on your vehicle.
The following functions are available:
FunctionPage
Setting daytime running lamp
mode (USA only)135
Setting locator lighting135
Setting night security illumina-
tion (Headlamps delayed
switch-off)136
Setting interior lighting delayed
switch-off 137

135 Controls in detail
Control system
Setting daytime running lamp mode
(USA only)
Move the selection marker with button
æ or ç to the
Lighting sub-
menu.
Press button j or k repeatedly
until you see this message in the left
multifunction display:
Light circuit
Headlamp mode
.
The selection marker is on the current
setting.
Press buttonæ orç to select
manual operation (
Manual) or daytime
running lamp mode (
Constant)
activated.With daytime running lamp mode activated
and the exterior lamp switch in
positionM orU, the low beam
headlamps are switched on when the
engine is running.
In low ambient light conditions the
following lamps will switch on additionally:

Parking lamps

Tail lamps

License plate lamps

Side marker lamps
For more information on the daytime
running lamp mode, see “Daytime running
lamp mode” (
page 108).Setting locator lighting
With the locator lighting feature activated
and the exterior lamp switch in
positionU, the following lamps will
switch on during darkness when the
vehicle is unlocked with the SmartKey:

Parking lamps

Tail lamps

License plate lamps

Side marker lamps

Front fog lamps
The locator lighting switches off when the
driver’s door is opened.
If you do not open a door after unlocking
the vehicle with the SmartKey the lamps
will switch off automatically after approxi-
mately 40 seconds.
iThis function is not available in countries
where the daytime running lamp mode is manda-
tory and therefore in a constant mode.
iIf you turn the exterior lamp switch to anoth-
er position, the corresponding lamp(s) will
switch on.
For safety reasons, resetting the
Lighting sub-
menu to factory settings (
page 129) will not
reset the daytime running lamp mode.
The following message appears in the right multi-
function display:
Cannot be fully reset to
factory settings when driving
.

136 Controls in detail
Control system
Move the selection marker with button
æ or ç to the
Lighting
submenu.
Press button j or k repeatedly
until you see this message in the left
multifunction display:
Locator lighting.
The selection marker is on the current
setting.
Press button æ or ç to switch
the locator lighting function
On.
Turn the exterior lamp switch to
positionU when exiting the vehicle
(
page 106).
The locator lighting feature is
activated.Setting night security illumination
(Headlamps delayed switch-off)
Use this function to set whether you would
like the exterior lamps to remain on for
15 seconds during darkness after exiting
the vehicle and closing the doors.
With the delayed shut-off feature activated
and the exterior lamp switch in
positionU before the engine is turned
off, the following lamps will switch on
when the engine is turned off:

Parking lamps

Tail lamps

License plate lamps

Side marker lamps

Front fog lamps
If after turning off the engine you do not
open a door or do not close an opened
door, the lamps will automatically switch
off after 60 seconds.
Move the selection marker with button
æ or ç to the
Lighting sub-
menu.
Press button j or k repeatedly
until you see this message in the left
multifunction display:
Headlamps delayed switch-off.
The selection marker is on the current
setting.
Press button æ or ç to switch
the headlamps delayed shut-off feature
On or Off.
Turn the exterior lamp switch to
positionU before turning off the
engine (
page 106).
The headlamps delayed switch-off
feature is activated.

182 Controls in detail
Good visibility
For information on the windshield wipers,
see “Switching on windshield wipers”
(
page 52).
Headlamp cleaning system
The button is located on the left side of the
dashboard.
1Headlamp washer button
Switch on the ignition (page 40).
Press button 1.
The headlamps are cleaned with a
high-pressure water jet.For information on filling up the washer
reservoir, see “Windshield washer system
and headlamp cleaning system”
(
page 257).
Rear view mirrors
For more information on setting the rear
view mirrors, see “Mirrors” (
page 43).
Auto-dimming mirror
The reflection brightness of the interior
rear view mirror will respond automatically
to glare when

the ignition is switched on
and

incoming light from headlamps falls on
the sensor in the interior rear view
mirror
The rear view mirror will not react if

reverse gearR is engaged

the interior lighting is turned on
iThe headlamps will automatically be
cleaned when you have

switched on the headlamps
and

operated the windshield wipers with wind-
shield washer fluid fifteen times
When you switch off the ignition, the counter
resets.

249 Operation
At the gas station
Windshield washer and headlamp
cleaning system
For more information on filling up the
washer reservoir, see “Windshield washer
system and headlamp cleaning system”
(
page 257).Vehicle lighting
Check function and cleanliness. For more
information on replacing light bulbs, see
“Replacing bulbs” (
page 359).
For more information on exterior lamps,
see “Exterior lamp switch” (
page 106).Tire inflation pressure
For more information on tire inflation pres-
sure, see “Checking tire inflation pressure
manually” (
page 269).

251 Operation
Engine compartment
The release lever is located in the driver’s
footwell.
1Release lever
The hood folding mechanism is disengaged
in two stages.
Pull release lever1 downwards.
This completes the first stage.2Hood latch
The hood latches are located in the upper
air intake next to the headlamp units.
Pull the hood latches2.
This completes the second stage.
Pull the hood towards you to the stop.
!Make sure the windshield wipers are not
folded away from the windshield. Otherwise the
windshield wipers or the hood could be dam-
aged.
Make sure there is sufficient clearance before
opening the hood. A minimum clearance in front
of the vehicle of
3/4ft (25 cm) is required.
iIf it was not possible to release the hood,
pull the release lever downwards more firmly.
