2007 MERCEDES-BENZ SL600 engine coolant

ContentsOperation......................................... 257
The first 1000 miles (1500 km) ......... 258
Driving instructions ............................ 259
Drive sensibly – save fuel ............. 259
Drinking and driving ..................... 259
Pedals .......................................... 259
Power assistance ......................... 260
Brakes .......................................... 260
Driving off..................................... 262
Parking ......................................... 263
Tires ............................................. 263
Hydroplaning ................................ 264
Tire traction .................................. 265
Tire speed rating .......................... 265
Winter driving instructions ........... 266
Standing water ............................. 267
Passenger compartment .............. 268
Driving abroad .............................. 268
Control and operation of radio
transmitters.................................. 268
Catalytic converter ....................... 269
Emission control........................... 269
Coolant temperature .................... 270At the gas station .............................. 271
Refueling ...................................... 271
Check regularly and before a
long trip........................................ 272
Engine compartment ......................... 274
Hood ............................................ 274
Engine oil ..................................... 275
Transmission fluid level ................ 279
Oil level in the ABC system .......... 279
Coolant ........................................ 280
Battery ......................................... 281
Windshield washer system and
headlamp cleaning system ........... 282
Tires and wheels ................................ 283
Important guidelines .................... 283
Tire care and maintenance ........... 284
Direction of rotation ..................... 286
Loading the vehicle ...................... 286
Recommended tire inflation
pressure ....................................... 291
Checking tire inflation pressure ... 292
MOExtended system* .................. 301
Tire labeling.................................. 302
Load identification ....................... 306
DOT, Tire Identification Number
(TIN) ............................................. 307Maximum tire load ....................... 308
Maximum tire inflation pressure .. 309
Uniform Tire Quality Grading
Standards (U.S. vehicles) ............. 309
Tire ply material ........................... 311
Tire and loading terminology........ 312
Rotating tires ............................... 315
Winter driving .................................... 316
Winter tires .................................. 316
Block heater (Canada only) .......... 317
Snow chains................................. 318
Maintenance...................................... 319
Maintenance service indicator
message ...................................... 319
Calling up the maintenance
service indicator display .............. 320
Resetting the maintenance
service indicator .......................... 321
Vehicle care....................................... 322
Cleaning and care of the vehicle .. 322

ContentsFuels, coolants, lubricants, etc. ......... 444
Capacities .................................... 444
Engine oils .................................... 446
Engine oil additives ...................... 446
Air conditioning refrigerant .......... 446
Brake fluid .................................... 447
Premium unleaded gasoline ......... 447
Fuel requirements ........................ 448
Gasoline additives ........................ 448
Coolants ....................................... 449
Windshield and headlamp
washer system ............................. 452Index................................................. 453

23 At a glance
Exterior view
Item
Page
1
TrunkOpening the trunk
111
Closing the trunk
113
Spare wheel
388
Vehicle tool kit
388
2
Rear lamps
398
3
Rear window defroster
183
4
Fuel filler flap
271
Refueling
271
Gasoline
447
5
DoorsLocking and unlocking
102
Opening and closing
111
Locking/unlocking in an
emergency
391
6
Exterior rear view mirrorsAdjusting
48
Auto-dimming rear view
mirrors
180
Item
Page
7
Towing
421
Installing towing eye bolt
423
8
Tires and wheels
283
Checking tire inflation
pressure
292
Run Flat Indicator*
293
Tire Pressure Monitoring
System (TPMS)
295
Advanced Tire Pressure
Monitoring System
(Advanced TPMS)*
298
General information
283
Flat tire
405
Vehicle tool kit
388
9
HoodOpening
274
Engine oil
275
Coolant
280,
449
Item
Page
a
Headlamp cleaning
system
180,
282
b
Front lamps
398
c
Windshield wipers
57
Wiper blades, replacing
403
Wiper blades, cleaning
326
d
WindshieldCleaning with wiper fluid
58
Cleaning
326
e
Retractable hardtopOpening/closing
199
Wind screen
204
Luggage cover
205
Sunshade for panorama
roof*
208

27 At a glance
Instrument cluster
Item
Page
1
Coolant temperature
gauge with:DCoolant temperature
warning lamp
337
2
Speedometer with:LLeft turn signal indi-
cator lamp
56
KRight turn signal indi-
cator lamp
56
;Brake warning lamp,
USA only
335
3Brake warning lamp,
Canada only
335
vABS/ESP
® warning
lamp
332
Item
Page
EDistronic* indicator
lamp
1 (white) or
distance warning
lamp (red)
213,
339
3
Left multifunction display
with:

Trip odometer
137


Main odometer


Stored speed for

Cruise control


Distronic*
209
151,
213
1Vehicles without Distronic*: Warning/indicator
lamp without function. It illuminates when the igni-
tion is on. It should go out when the engine is run-
ning.
Item
Page
4
Reset button for:

Resetting trip odometer
137


Resetting individual set-
tings
153


Adjusting instrument
cluster illumination
136

59 Getting started
Driving
Problems while driving
The engine runs erratically and misfires

An ignition cable may be damaged.


The engine electronics may not be op-
erating properly.


Unburned gasoline may have entered
the catalytic converter and damaged it.

Give very little gas.

Have the problem repaired by an au-
thorized Mercedes-Benz Center as
soon as possible.The coolant temperature gauge is
above 248°F (120°C)
The coolant is too hot and is no longer
cooling the engine.

Stop the vehicle as soon as possible in
a safe location and turn off the engine.
Allow engine and coolant to cool.

Check the coolant level and add cool-
ant if necessary (
page 280).In case of accident
If the vehicle is leaking gasoline:

Do not start the engine under any cir-
cumstances.

Notify local fire and/or police authori-
ties.
If the extent of the damage cannot be de-
termined:

Notify an authorized Mercedes-Benz
Center.
If no damage can be determined on the


major assemblies


fuel system


engine mount:

Start the engine in the usual manner.

137 Controls in detail
Instrument cluster
To brighten illumination
Turn reset button 1 in the instrument
cluster clockwise.
The instrument cluster illumination will
brighten.
To dim illumination

Turn reset button 1 in the instrument
cluster counterclockwise.
The instrument cluster illumination will
dim.
Coolant temperature gauge
Trip odometer
Make sure you are viewing the trip
odometer display (
page 139).

If it is not displayed, press the j or
k button on the multifunction
steering wheel repeatedly until the trip
odometer appears.

Press and hold reset button1
(page 136) until the trip odometer is
reset.
Warning!
G


Driving when your engine is overheated
can cause some fluids which may have
leaked into the engine compartment to
catch fire. You could be seriously
burned.


Steam from an overheated engine can
cause serious burns which can occur
just by opening the hood. Stay away
from the engine if you see or hear steam
coming from it.
Turn off the engine, get out of the vehicle
and do not stand near the vehicle until the
engine has cooled down.
!
Excessive coolant temperature triggers the
coolant temperature warning lamp (
page 337)
and a warning in the multifunction display
(
page 371).
The engine should not be operated with the cool-
ant temperature above 248°F (120°C). Doing so
may cause serious engine damage which is not
covered by the Mercedes-Benz Limited
Warranty.
i
During severe operating conditions, e.g.
stop-and-go traffic, the coolant temperature may
rise close to 248°F (120°C).

194 Controls in detailAutomatic climate controlActivating
Moist air can fog up the windows. You can
dehumidify the air with the air condition-
ing.
Press button 2 once more
(page 185).
The indicator lamp on the button
comes on.
The air conditioning uses the refrigerant
R134A. This refrigerant is free of CFCs
which are harmful to the ozone layer.
Residual heat and ventilation
With the engine switched off, it is possible
to continue to heat or ventilate the interior
for up to 30 minutes. This feature makes
use of the residual heat produced by the
engine.Activating
With the SmartKey:

Turn the SmartKey in the starter switch
to position1 or0, or remove it from
the starter switch.

Press button T (
page 185).
The indicator lamp on the button
comes on.
With KEYLESS-GO*:

Turn off the engine by pressing the
KEYLESS-GO* start/stop button and
open the driver’s door (with the driver’s
door open, the starter switch is in posi-
tion 0, same as with the SmartKey re-
moved from the starter switch)

Press button T (
page 185).
The indicator lamp on the button
comes on.
!
If the 2 button on the automatic climate
control panel starts to flash, this indicates that
the air conditioning is losing refrigerant. The
compressor has turned off. The air conditioning
cannot be turned on again.


Have the air conditioning checked at the
nearest authorized Mercedes-Benz Center.
i
How long the system will provide heating de-
pends on the coolant temperature and the se-
lected temperature. The blower will run at low
speed regardless of the air distribution control
setting.

270 OperationDriving instructions
Coolant temperature
During severe operating conditions, e.g.
stop-and-go city traffic, the coolant tem-
perature may rise close to approx. 266°F
(130°C).
The engine should not be operated with
the coolant temperature over 248°F
(120°C). Doing so may cause serious en-
gine damage which is not covered by the
Mercedes-Benz Limited Warranty.
Warning!
G
Inhalation of exhaust gas is hazardous to
your health. All exhaust gas contains carbon
monoxide (CO), and inhaling it can cause un-
consciousness and possible death.
Do not run the engine in confined areas
(such as a garage) which are not properly
ventilated. If you think that exhaust gas
fumes are entering the vehicle while driving,
have the cause determined and corrected
immediately. If you must drive under these
conditions, drive only with at least one win-
dow fully open at all times.
Warning!
G


Driving when your engine is badly over-
heated can cause some fluids, which
may have leaked into the engine com-
partment, to catch fire. You could be se-
riously burned.


Steam from an overheated engine can
cause serious burns and can occur just
by opening the engine hood. Stay away
from the engine if you see or hear steam
coming from it. Turn off the engine, get
out of the vehicle and do not stand near
the vehicle until the engine has cooled
down.
