2007 MERCEDES-BENZ S CLASS mirror controls

338 Controls in detailMemory functionStoring exterior rear view mirror park-ing position
For easier parking, you can adjust the pas-
senger-side exterior rear view mirror so
that you can see the right rear wheel as
soon as you engage reverse gearR.
For information on activating the parking
position, see “Activating exterior rear view
mirror parking position” (
page 335).
1Memory button M
2Adjustment button
3Selector switch for right or left exterior
mirror

Stop the vehicle.

Make sure the ignition is switched on
(page 315).

Press switch3 until the exterior mir-
ror on the front passenger side is se-
lected.

Adjust the passenger-side exterior rear
view mirror with button2 so that you
see the rear wheel and the road curb.

Press memory button M.

Within 3 seconds, press one of adjust-
ment buttons2.
The parking position is stored if the
mirror does not move.
i
If the mirror does move, repeat the above
steps. After the setting is stored, you can move
the mirror again.

349 Controls in detail
Lighting
Interior lighting in the front
The controls are located in the overhead
control panel.
1Left reading lamp on/off
2Rear interior lamps on/off
3Front interior lighting on/off
4Interior lighting control
5Right reading lamp on/offAutomatic control

Deactivating: Press button4.
The OFF indicator lamp next to the but-
ton comes on.
The interior lighting remains switched
off in darkness, even when you:

unlock the vehicle


remove the SmartKey from the
starter switch


open a door


open the trunk

Activating: Press button4.
The interior lighting switches on in
darkness when you:

unlock the vehicle


remove the SmartKey from the
starter switch


open a door


open the trunkThe interior lighting switches off auto-
matically following an adjustable time
delay (
page 226).
Manual control

Switching on/off front interior light-
ing: Press button 3.

Switching on/off rear interior light-
ing: Press button 2.

Switching on/off front reading
lamps: Press button 1 or 5.
The reading lamps are integrated into
the interior rear view mirror.

Ambient lighting: the brightness of
the ambient lighting is adjusted via
COMAND (
page 79).
!
Leaving an interior light switch in the ON po-
sition for extended periods of time with the en-
gine turned off could result in a discharged
battery.
i
If the door remains open, the interior lighting
switches off automatically after approximately
5minutes.
An interior lamp switched on manually does not
go out automatically.

413 Controls in detail
Driving systems
Dynamic Rear View Monitor*
The Dynamic Rear View Monitor is an elec-
tronic and visual parking aid. It shows you
the area behind the vehicle on the
COMAND display.
In addition, the Dynamic Rear View Moni-
tor contains guide lines to help you with re-
verse parking (back-in parking) and
parallel parking.
The area behind the vehicle is displayed as
a reverse-mirror image similar to the view
in a rear-view mirror.The Dynamic Rear View Monitor is in the
handle strip of the trunk lid.
1Dynamic Rear View Monitor
View through the camera
i
The image from the Dynamic Rear View
Monitor is shown on the COMAND display
(
page 31).
Warning!
G
Please note that objects which do not touch
the ground, such as the bumper of a vehicle
parked behind you, a trailer hitch, or the
back of a truck, may appear to be further
away than they actually are. In this case, you
should not use the guide lines to judge dis-
tance. The use of the guide lines to judge
distance increases the risk of impacting the
objects.

455 Controls in detail
Useful features
Useful features
Sun visors
1Sun visor
2Vanity mirror cover
3Vanity mirror lamp
4Document holderGlare from front

Swing sun visor1 down.
Glare from front and sides

Disengage sun visor1 from the
mounting.

Pivot sun visor1 to the side.
Vanity mirror in sun visor

To use vanity mirror, lift up cover2.
Vanity mirror lamp3 comes on.
Document holder
You can use the plastic tab of document
holder4 to hold admission tickets, park-
ing passes, or similar items in place.
Vanity mirror in rear
Opening: Press mark1.
The vanity mirror swings down in the di-
rection of the arrow.

Closing: Swing vanity mirror up until it
engages.
Warning!
G
Do not use the vanity mirror while driving.
Keep the vanity mirrors in the sun visors
closed while vehicle is in motion. Reflected
glare can endanger you and others.
!
Close vanity mirror cover2 (if open) before
you disengage sun visor1 from the mounting
and pivot it to the side.
i
If you disengage sun visor1 from the
mounting, vanity mirror lamp2 will switch off.

462 Controls in detailUseful featuresTele Aid
The Tele Aid system
(Tele
matic A
larm I
dentification on D
e-
mand)
The Tele Aid system consists of three
types of response:


automatic and manual emergency


roadside assistance, and


informationThe Tele Aid system is operational provid-
ing that the vehicle’s battery is charged,
properly connected, not damaged and mo-
bile phone and GPS coverage are available.
The speaker volume of a Tele Aid call can
be adjusted when using the volume control
on the multifunction steering wheel. To
raise, press buttonæ and to lower,
press buttonç or use the COMAND
volume thumbwheel , on the lower
part of the front central console
(
page 89).

To activate, press the SOS button, the
Roadside Assistance button• or
the Information button¡, depend-
ing on the type of response required.Shortly after the completion of your
Tele Aid acquaintance call, you will receive
a user ID and password. By visiting
www.mbusa.com and selecting “Tele Aid”
(USA only), you will have access to account
information, remote door unlock and
more.
System self-check
Initially, after switching on the ignition,
malfunctions are detected and indicated.
If a malfunction is detected, the indicator
lamps in the SOS button, the Roadside As-
sistance button• and the Information
button¡ stay on longer than
10 seconds or do not come on. The mes-
sage “Tele Aid not activated” or “Tele Aid
inoperative” appears in the multifunction
display.
!
The initial activation of the Tele Aid system
may only be performed by completing the sub-
scriber agreement and placing an acquaintance
call using the Information button¡. Failure
to complete either of these steps will result in a
system that is not activated.
If you have any questions regarding activation,
please call the Response Center at
1-800-756-9018 (in the USA) or
1-888-923-8367 (in Canada).
i
The Tele Aid system utilizes the mobile
phone network for communication and the GPS
(Global Positioning System) satellites for vehicle
location. If either of these signals are unavail-
able, the Tele Aid system may not function and if
this occurs, assistance must be summoned by
other means.
i
The SOS button is located above the interior
rear view mirror (
page 464).
The Roadside Assistance button• and the
Information button¡ are located below the
center armrest cover (page 465).

463 Controls in detail
Useful features
Emergency calls
An emergency call is initiated
automatically following an accident in
which the emergency tensioning devices
(ETDs) or air bags deploy.An emergency call can also be initiated
manually by opening the cover next to the
interior rear view mirror labeled SOS, then
briefly pressing the button located under
the cover. For instructions on initiating an
emergency call manually (
page 464).
Once the emergency call is in progress, the
indicator lamp in the SOS button will begin
to flash. The message:


“Connecting call” appears in the multi-
function display


“Emergency Call Activated” appears in
the COMAND display
and the audio system is muted. When the
connection is established, the message:


“Call connected” appears in the multi-
function display


“Emergency Call Activated” appears in
the COMAND display All information relevant to the emergency,
such as the location of the vehicle (deter-
mined by the GPS satellite location sys-
tem), vehicle model, identification number
and color are generated.
A voice connection between the Response
Center and the occupants of the vehicle
will be established automatically soon af-
ter the emergency call has been initiated.
The Response Center will attempt to deter-
mine more precisely the nature of the acci-
dent provided they can speak to an
occupant of the vehicle.
Warning!
G
If the indicator lamps in the SOS button, in
the Roadside Assistance button•
and/or in the Information button¡ do
not come on during the system self-check,
or if any of these indicators remain illuminat-
ed continuously in red and/or the message
“Tele Aid not activated” or “Tele Aid inopera-
tive” is displayed in the multifunction display
after the system self-check, a malfunction in
the system has been detected.
If a malfunction is indicated as outlined
above, the system may not operate as ex-
pected. Have the system checked at the
nearest Mercedes-Benz Center as soon as
possible.
i
During the emergency call message “Emer-
gency Call Activated” is displayed, operation
from COMAND is not possible. The automatic cli-
mate control can be still adjusted using the
switches on the climate control panel.
i
If no vehicle occupant responds, an ambu-
lance will be sent to the vehicle immediately.

470 Controls in detailUseful featuresGarage door opener
The integrated remote control is capable of
operating up to three separately controlled
devices. It provides a convenient way to re-
place up to three hand-held remote con-
trols used to operate devices such as
garage door openers, gate openers, or oth-
er devices compatible with HomeLink
® or
some other systems.
Before the integrated remote control can
be used, it must be programmed to the ga-
rage door opener, gate operator or other
device you wish to operate. See the follow-
ing instructions for programming informa-
tion.
Interior rear view mirror with integrated re-
mote control1Indicator lamp
2 3 4Signal transmitter button
Needed for programming (not part of vehi-
cle equipment):
5Hand-held remote control of ga-
rage door opener, gate operator
or other device
6Hand-held remote control but-
ton
Warning!
G
Before programming the integrated remote
control to a garage door opener or gate
operator, make sure people and objects are
out of the way of the device to prevent po-
tential harm or damage. When programming
a garage door opener, the door moves up or
down. When programming a gate operator,
the gate opens or closes.
Do not use the integrated remote control
with any garage door opener that lacks
safety stop and reverse features as required
by U.S. federal safety standards (this
includes any garage door opener model
manufactured before April 1, 1982).
A garage door that cannot detect an object
– signaling the door to stop and reverse –
does not meet current U.S. federal safety
standards.
When programming a garage door opener,
park the vehicle outside the garage.
