2007 MERCEDES-BENZ S CLASS ECO mode

316 Controls in detailStarter switch positionsSmartKey with KEYLESS-GO*
Vehicles equipped with the KEYLESS-GO
feature are supplied with a SmartKey with
integrated KEYLESS-GO function and a re-
movable KEYLESS-GO start / stop button.
With the KEYLESS-GO start/stop button
inserted and the SmartKey with
KEYLESS-GO present in the vehicle, press-
ing the KEYLESS-GO start/stop button

without the brake pedal depressed
corresponds to the various starter
switch positions (
page 315)


with the brake pedal firmly depressed
will start the engine (
page 360)If you wish or should there be a need to in-
sert the SmartKey with KEYLESS-GO in the
starter switch, the KEYLESS-GO start/stop
button can be easily removed by pulling it
out of the starter switch.
1KEYLESS-GO start/stop button
2Starter switch

Insert KEYLESS-GO start/stop
button1 into starter switch 2 (if not
inserted already).
i
The function of the SmartKey overrules the
KEYLESS-GO function.
i
The KEYLESS-GO start/stop button does
not need to be removed from the starter switch
when you leave the vehicle. However, always
take the SmartKey with KEYLESS-GO with you
when you leave the vehicle. As long as the
SmartKey with KEYLESS-GO is in the vehicle, the
vehicle’s electrical systems can be switched on
or the engine can be started using the
KEYLESS-GO start/stop button.
i
When you switch from SmartKey mode back
to KEYLESS-GO mode, the system requires
2 seconds of detection time before you can use
the KEYLESS-GO button as usual.

344 Controls in detailLighting
Turn the exterior lamp switch to *.
With the SmartKey in starter switch po-
sition 1 or the KEYLESS-GO*
start/stop button pressed once, only
the parking lamps will switch on and off
automatically.
When the engine is running, the low
beam headlamps, the tail and parking
lamps, the license plate lamps, and the
side marker lamps will switch on and
off automatically.Daytime running lamp mode

Turn exterior lamp switch to
positionM or*.
When the engine is running, the low
beam headlamps are switched on. In
low ambient light conditions, the fol-
lowing lamps will switch on additional-
ly:

tail and parking lamps


license plate lamps


side marker lamps
For nighttime driving you should turn the
exterior lamp switch to positionB to
permit activation of the high beam head-
lamps.
Canada only
The daytime running lamp mode is manda-
tory and therefore in a constant mode.
When the engine is running, and you shift
from a driving position to positionN orP,
the low beam headlamps will switch off
with a 3-minute delay.When the engine is running, and you


turn the exterior lamp switch to
positionC, the parking lamps
switch on additionally.


turn the exterior lamp switch to
positionB, the manual headlamp
mode has priority over the daytime run-
ning lamp mode.
The corresponding exterior lamps
switch on (
page 622).
USA only
By default, the daytime running lamp mode
is deactivated. Activate the daytime run-
ning lamp mode using the control system,
see “Daytime driving lamps mode on/off
(USA only)” (
page 255).
When the engine is running, and you turn
the exterior lamp switch to position C
orB, the manual headlamp mode has
priority over the daytime running lamp
mode.
The corresponding exterior lamps switch
on (
page 622).
i
The front fog lamps and rear fog lamp can-
not be switched on manually with exterior lamp
switch in position*. To activate the fog
lamps, turn exterior lamp switch to
positionB and pull the exterior lamp switch
to first or second stop (
page 345).

374 Controls in detailAutomatic transmissionHill start assist system
On uphill grades with a gradient angle of
more than 5°, the hill start assist system
maintains the pressure in the brake sys-
tem for approximately 1 second after you
have released the brake pedal. Therefore,
you can start off smoothly without the
vehicle moving immediately after releasing
the brake pedal.The hill start assist system is inactive


when starting off on a level road or
downhill grades


with the automatic transmission in
neutral position N


with the electric parking brake set


if the ESP
® has switched off due to a
malfunction
Automatic shift program
The program mode selector switch is used
to adjust

shift program


suspension tuning of Airmatic*
(page 402) or ABC* (
page 404)


engine control
Program mode selector switchC Comfort For comfort driving
S Sport For standard driving
The selected program mode CorS ap-
pears in the tachometer display.
Warning!
G
The hill start assist system is not designed
to function as a parking brake and does not
prevent the vehicle from moving when
parked on an incline.
Always set the electric parking brake in
addition to shifting to park positionP.

375 Controls in detail
Automatic transmission
1Current program mode
Press program mode selector switch
repeatedly until the letter of the
desired program mode appears in the
tachometer display.Program modeC:


Engine, automatic transmission and
suspension tuning are comfortable.


The vehicle starts out in second
gear (both forward and reverse) for
gentler starts. This does not apply if
full throttle is applied or gear
range1 is selected.


Traction and driving stability are
improved on icy roads.


Upshifts occur earlier even when
you give more gas. The engine then
operates at lower rpms and the
wheels are less likely to spin.
Program modeS:


Engine, automatic transmission and
suspension tuning are more perfor-
mance oriented.


The vehicle starts out in first gear.


Upshifts occur later.
Steering wheel gearshift control
With drive positionD selected, you can
limit or extend the gear range.
The steering wheel gearshift buttons are
located on the back of the steering wheel
to the left and right.
!
Never change the program mode when the
automatic transmission is out of park positionP.
This could result in a change of driving character-
istics for which you may not be prepared.
i
The last selected program mode (CorS) is
switched on when the engine is restarted.
!
Allow engine to warm up under low load use.
Do not place full load on the engine until the op-
erating temperature has been reached.
Shift into reverse gearR or park positionP only
when the vehicle is stopped.
Avoid spinning of a drive wheel for an extended
period when driving off on slippery road surfac-
es. This may cause serious damage to the driv-
etrain which is not covered by the
Mercedes-Benz Limited Warranty.

377 Controls in detail
Automatic transmission
Emergency operation (Limp-Home Mode)
If vehicle acceleration becomes less re-
sponsive or sluggish or the automatic
transmission no longer shifts, the automat-
ic transmission is most likely operating in
limp-home (emergency operation) mode.
In this mode only second gear and reverse
gear can be selected.
Stop the vehicle in a safe location.

Shift to park positionP.

Turn off the engine.

Wait at least 10 seconds before
restarting.

Restart the engine.

Shift to drive positionD (for second
gear) or reverse gearR.

Have the automatic transmission
checked at an authorized
Mercedes-Benz Center as soon as pos-
sible.

427 Controls in detail
Automatic climate control
The automatic climate control is operation-
al whenever the engine is running. You can
operate the climate control system in ei-
ther the automatic or manual mode. The
system cools or heats the interior depend-
ing on the selected interior temperature
and the current outside temperature.
It can only function optimally when you are
driving with the windows and the tilt/slid-
ing sunroof/panorama sunroof* closed.
It is possible to completely deactivate the
climate control system (
page 428). Nearly all dust particles, pollutants and
odors are filtered out before outside air en-
ters the passenger compartment through
the air distribution system.The following automatic climate control
functions can be operated via COMAND:
i
If you have the air distribution and air vol-
ume automatically controlled, you can adjust the
temperature, footwell temperature and air flow.
The following basic settings are recommended:


Automatic air distribution control
(page 428)


Temperature: 72°F (22°C) (
page 429)


Footwell temperature: 0 (
page 232)


Air flow: focused (
page 233)
Warning!
G
Follow the recommended settings for heat-
ing and cooling given on the following pages
and in the “COMAND automatic climate
control” section (
page 229). Otherwise
the windows could fog up, impairing visibili-
ty and endangering you and others.
i
Severe conditions (e.g. strong air pollution)
may require replacement of the filter before its
scheduled interval. A clogged filter will reduce
the air volume to the interior.
If the vehicle interior is hot, ventilate the interior
before driving off, see “Summer opening fea-
ture” (page 355). The automatic climate con-
trol will then adjust the interior temperature to
the set value much faster.
Keep the air intake grille in front of the wind-
shield free of snow, leaves, sticks, and any other
debris.
Do not obstruct air volume by placing objects on
the air volume-through exhaust slots below the
rear window.Function
Page
Temperature
230
Air distribution
230
Air volume
230
Switching off cooling (“AC
OFF”)
231
Central climate control (“Mono”)
232
Footwell temperature
232
Air flow from air vents
233
Rear climate control*
234

432 Controls in detailAutomatic climate controlVehicles with tilt/sliding sunroof
Convenience closing: Press
button
,
for approximately
2 seconds.
The side windows and/or tilt/sliding
sunroof will close. You can release
button
,
once the closing proce-
dure has begun. The windows and
tilt/sliding sunroof continue closing
until they are fully closed. The indicator
lamp on the button comes on. The air
recirculation mode is activated.

Convenience opening: Press
button
,
for approximately
2 seconds.
The side windows and/or tilt/sliding
sunroof will return to their previous po-
sition. You can release button
,
once the opening procedure has be-
gun. The windows and tilt/sliding sun-
roof continue opening until they have
reached their previous positions. The
indicator lamp on the button goes out.
The air recirculation mode is deactivat-
ed.Vehicles with panorama roof*

Convenience closing: Press and hold
button
,
until the side windows and
the tilt/sliding panel are closed or have
reached the desired position. The indi-
cator lamp on the button comes on.
The air recirculation mode is activated.

Convenience opening: Press and hold
button
,
until the side windows and
the tilt/sliding panel are opened or
have reached the desired position.
The indicator lamp on the button goes
out. The air recirculation mode is deac-
tivated.
The closing of the side windows and the
tilt/sliding sunroof or tilt/sliding panel* can
be reversed by again pressing and holding
button,.
i
A window or tilt/sliding sunroof (or tilt/slid-
ing panel*) will only return to its previous posi-
tion if it has not been moved to another position
using the respective window switch or tilt/slid-
ing sunroof (or tilt/sliding panel*) switch after it
was closed with button,.
A window or tilt/sliding sunroof (or tilt/sliding
panel*) that has been moved will remain in its
current position if button, i s u s e d t o r e o p e n
the remaining windows or tilt/sliding sunroof (or
tilt/sliding panel*).


434 Controls in detailAutomatic climate controlRear passenger compartment adjust-able air vents
Rear center console air vents
1Left center air vent, adjustable
2Right center air vent, adjustable
3Thumbwheel for right center air vents
4Thumbwheel for left center air vents
Opening/closing air vents:
Turn thumbwheel3 or 4.Rear passenger compartment climate
control*
Automatic climate control panel, rear
i
Vehicles without rear passenger compart-
ment climate control*:
The temperature at the air vents for rear passen-
ger compartment1 and2 will be approxi-
mately the same as at the dashboard center air
vents.
Warning!
G
Follow the recommended settings for heat-
ing and cooling as given in the instructions
for the front climate control (
page 424).
Otherwise the windows could fog up, impair-
ing visibility for the driver and endangering
you and others.
i
At low outside temperatures or if you have
switched off the cooling function, you cannot
cool the rear passenger compartment.
Item
1
Temperature control, left
2
Air distribution, left
(automatic, manual)
3
Air volume (automatic, manual)
4
Mode selector
5
Air distribution, right
(automatic, manual)
6
Temperature control, right
