404 Operation
Tires and wheels
Rotating tires
Tire rotation can be performed on vehicles
with tires of the same dimension all
around. If your vehicle is equipped with
tires of the same dimension all around,
tires can be rotated, observing a
front-to-rear rotation pattern that will
maintain the intended rotation (spinning)
direction of the tire (
page 375).
In some cases, such as when your vehicle
is equipped with mixed-size tires (different
tire dimension front vs. rear), tire rotation
is not possible.If applicable to your vehicle’s tire configu-
ration, tires can be rotated according to
the tire manufacturer’s recommended in-
tervals in the tire manufacturer’s warranty
pamphlet located in your vehicle literature
portfolio. If none is available, tires should
be rotated every 3 000 to 6 000 miles
(5 000 to 10 000 km), or sooner if neces-
sary, according to the degree of tire wear.
The same rotation (spinning) direction
must be maintained (
page 375).
Rotate tires before the characteristic tire
wear pattern becomes visible (shoulder
wear on front tires and tread center wear
on rear tires).
Thoroughly clean the mounting face of
wheels and brake disks, i.e. the inner side
of the wheels/tires, during each rotation.
Check for and ensure proper tire inflation
pressure.For information on wheel change, see “Flat
tire” (
page 497).
Warning!G
Rotate front and rear wheels only if the tires
are of the same dimension.
If your vehicle is equipped with mixed-size
tires (different tire dimensions front vs.
rear), tire rotation is not possible.
Warning!G
Have the tightening torque checked after
changing a wheel. Wheels could become
loose if not tightened with a torque of
110 lb-ft (150 Nm).
Only use genuine Mercedes-Benz wheel
bolts specified for your vehicle’s rims.
Page 567 of 570
566 Index
Tire inflation pressure
Checking 382
Checking manually 383
Checking tire pressure electronically,
Advanced Tire Pressure Monitoring
System (Advanced TPMS)*, (Canada
only) 388
Checking tire pressure electronically,
Tire Pressure Monitoring System
(TPMS), (USA only) 385
Recommended tire inflation
pressure 380
Tires 373, 532
Advanced Tire Pressure Monitoring
System (Advanced TPMS)*, (Canada
only) 388
Air pressure 401
Care and maintenance 374
Cleaning 375
Collapsible tire, Spare wheel 534
Combination low tire pressure/TPMS
malfunction telltale, USA only 27
Direction of rotation, Spinning 375
Driving instructions 352
Hydroplaning 352
Important guidelines 373Important notes, Tire inflation
pressure 381
Inflation pressure 380, 382
Inspection 374
Load rating 392, 393, 403
Loading terminology 401
Loading the vehicle 376
Low tire pressure telltale 27, 428
Ply composition and material
used 403
Retreads 373
Rims and tires 532
Rotating 404
Run Flat Indicator (Canada only) 383
Service life 374
Sizes 532
Snow chains 406
Spare wheel, Collapsible tire 534
Speed rating 353, 393, 403
Storing 375
Temperature 381, 400
Terminology 401
TIN 396, 403
Tire Identification Number see TIN
Tire Pressure Monitoring System
(TPMS)*, (USA only) 385TPMS malfunction telltale (USA
only) 428
Traction 353, 399, 403
Tread depth 375, 405
Treadwear indicators 375
Vehicle maximum load on 403
Wear pattern 404
Winter tires 405
Tongue Weight Rating see TWR
Tools 472
Top tether
Children in the vehicle 84
Towing eye bolts 518
Towing the vehicle 517
Tow-starting 514, 517
TPMS (USA only) 385
Traction 403
4-ETS, Driving safety systems 100,
106
Transmission see Automatic transmission
Traveling abroad 356
Tread 403
Tread depth 375
Treadwear indicators 403
Trip computer 191
Trip odometer 157
Page 569 of 570
568 Index
W
Warning indicators
Parktronic* 293
Warning lamps see Lamps, Indicator and
warning
Warning sounds
Distance warning function* 284
Distronic* 275
Exterior lamps 68
Parking brake 58
Parktronic system* 293
Seat belt telltale 82, 426, 427
Warranty coverage 10, 525
Washer fluid see Windshield washer fluid
Washer reservoir level 372
Washing the vehicle 410
Wear pattern, Tires 404
Weights, Vehicle 537
Wheel
Bolts 500
Change 497
Removing 500
Spare 534
Tightening torque 504Wheels
Sizes 532
Wheels, Tires and 373
Window curtain air bags 78
Windows see Power windows
Windshield
Cleaning 415
Defogging 225, 240
Infrared reflecting* 344
Washer fluid 546
Windshield washer fluid 372
Messages in the multifunction
display 469
Mixing ratio 546
Refilling 372
Reservoir level 372
Windshield washer system 372, 546
Windshield wipers 60
Cleaning wiper blades 415
Fast continuous wiping 61
Fast intermittent wiping 61
Rear window wiper/washer 62
Replacing wiper blades 494
Slow continuous wiping 61
Slow intermittent wiping 61Winter driving
Snow chains 406
Tires 405
Winter driving instructions 354
Winter tires 405
Wiping and washing simultaneously 63
Wood trims, cleaning 418
