146 Controls in detail
Control system
Standard display menu
In the standard display, the outside tem-
perature and the trip odometer are shown
in the multifunction display.1Outside temperature
2Trip odometer
If you see another display, press
buttonè orÿ repeatedly until the
standard display appears.
Press buttonk orjto select
the functions in the standard display
menu.
The following functions are available:Display digital speedometer
Press buttonj ork until the
digital speedometer appears in the
multifunction display.
The current vehicle speed is shown in
the multifunction display and the sta-
tus line appears.
1Digital Speedometer
2Status line with outside temperature
3Trip odometer
iThe headings used in the menus table are
designed to facilitate navigation within the sys-
tem and are not necessarily identical to those
shown in the control system displays.
The first function displayed in each menu will au-
tomatically show you which part of the system
you are in.
iYou can have the digital speedometer dis-
played instead of the outside temperature in the
standard display. You can select the setting in
the submenu
Instr. cluster via the function
Basic display (page 155).FunctionPage
Run Flat Indicator*324
Call up digital speedometer 146
Call up maintenance service
display345
iYou can have the digital speedometer dis-
played instead of the outside temperature in the
status line. You can select the setting in the sub-
menu
Instr. cluster via the function Status
line display
(page 155).

149 Controls in detail
Control system
1MP3 mode (vehicles with COMAND*)
2Current track
Press buttonk orj repeatedly
until the desired track is selected.
For more information on MP3, see “MP3
notes” (
page 224), and for operating,
see “MP3 playback” (
page 225)
NAV* menu
The
NAV menu contains the functions
needed to operate your navigation system.
Press buttonè orÿ repeatedly
until the message
NAV appears in the
multifunction display.

If COMAND* is switched off, the mes-
sage
Nav off appears in the multifunc-
tion display.

With COMAND* switched on but route
guidance not activated, the direction of
travel and, if available, the name of the
street currently traveld on appear in
the multifunction display.

With COMAND* switched on and route
guidance activated, the direction of
travel and maneuver instructions ap-
pear in the multifunction display.
Please refer to the COMAND* manual for
instructions on how to activate the route
guidance system*.
Vehicle status message memory menu
Use the vehicle status message memory
menu to scan malfunction and warning
messages that may be stored in the
system. Such messages appear in the
multifunction display and are based on
conditions or system status the vehicle’s
system recorded.
The vehicle status message memory menu
only appears if there are any messages
stored.
iLevel of information displayed will vary de-
pending on the information contained on the CD
with MP3 files insert in the single CD player of
the COMAND* system.
To select a CD from the CD changer* magazine,
press a number on the audio system or the
COMAND* system key pad located in the center
console.

284 Controls in detail
Useful features
Call priority
If other service calls such as a Roadside
Assistance call or Information call are ac-
tive, an Emergency call is still possible. In
this case, the Emergency call will take pri-
ority and override all other active calls.Remote door unlock
In case you have locked your vehicle unin-
tentionally (e.g. SmartKey inside vehicle),
and the reserve SmartKey is not handy:
Contact the Mercedes-Benz Response
Center at 1-800-756-9018 (in the USA)
or 1-888-923-8367 (in Canada).
You will be asked to provide your pass-
word which you provided when you
completed the subscriber agreement.
Then return to your vehicle and pull the
trunk recessed handle for a minimum
of 20 seconds until the SOS button is
flashing.
The message
Connecting call
appears in the multifunction display.
As an alternative, you may unlock the vehi-
cle via Internet using the ID and password
sent to you shortly after the completion of
your acquaintance call.
The Response Center will then unlock your
vehicle with the remote door unlocking
feature.
iThe indicator lamp in the respective button
flashes until the call is concluded. Calls can only
be terminated by a Response Center or Custom-
er Assistance Center representative except
Roadside Assistance and Information calls,
which can also be terminated by pressing
buttonton the multifunction steering wheel
or the respective button for ending a telephone
call on the audio system or the COMAND* head
unit.
!If the indicator lamp continues to flash or
the system does not reset, contact the Response
Center at 1-800-756-9018 (in the USA), or
1-888-923-8367 (in Canada), or Mercedes-Benz
Customer Assistance at 1-800-FOR-MERCedes
(1-800-367-6372) in the USA, or Customer Ser-
vice at 1-800-387-0100 in Canada.
iWhen a Tele Aid call has been initiated, the
audio system or the COMAND* system audio is
muted and the selected mode (radio or CD)
pauses. The optional cellular phone (if installed)
switches off. If you must use this phone, the ve-
hicle must be parked. Disconnect the coiled cord
and place the call. The COMAND* navigation
system (if engaged) will continue to run. The dis-
play in the instrument cluster is available for use,
and spoken commands are only available by
pressing the RPT button on the COMAND* head
unit. A pop-up window will appear in the
COMAND* display to indicate that a Tele Aid call
is in progress.

356 Practical hints
What to do if …?
Lamps in instrument clusterGeneral information:
If any of the following lamps in the instru-
ment cluster fails to come on during thebulb self-check when switching on the igni-
tion, have the respective bulb checked and
replaced if necessary.
ProblemPossible cause/consequenceSuggested solution
-The yellow ABS indicator lamp
comes on while the engine is
running.The ABS has detected a malfunction and has
switched off. The BAS and the ESP® are also
switched off (see messages in the multifunc-
tion display).
The brake system is still functioning normally
but without the systems specified above.
If the ABS control unit is malfunctioning,
other systems such as the navigation
system* or the automatic transmission may
also be malfunctioning.
Continue driving with added caution.
Wheels will lock during hard braking,
reducing steering capability.
Read and observe messages in the
multifunction display (
page 370).
Have the system checked at an autho-
rized Mercedes-Benz Center as soon
as possible.
Failure to follow these instructions in-
creases the risk of an accident.
The charging voltage has fallen below
10 volts. The ABS has switched off.
The battery might not be charged sufficiently.Switch off electrical consumers that
are currently not needed, e.g. seat
heating*.
If necessary, have the generator and
battery checked.
When the voltage is above this value
again, the ABS is operational again.

468 Index
Multifunction display messages 368
ABS 370
Battery 378
Brake fluid 379
Brake pads 379
Check engine 380
Coolant 380–382
Engine 380
Engine coolant 380–382
ESP
®370
Fog lamps 387
Front passenger
front air bag 372–375
Fuel cap 383
Fuel reserve tank 385
Gear selector lever 376
Headlamps 387–390
Key, SmartKey 385
KEYLESS-GO* 385
Lamps 388
Lamps, exterior 387–390
License plate lamp 388
Light sensor 386
Parking brake 379
Parking lamps 388
Power tilt/sliding sunroof* 393SRS 391
Steering gear oil 392
Tele Aid 393
Telephone* 393
Turn signals 387
Windshield washer fluid 393
Multifunction steering wheel 28, 142
Button operation 142
N
Navigation system* 149
See separate COMAND*
operating instructions
Net, Parcel 269
Neutral gear position,
Automatic transmission 168, 170
New vehicle break-in 292
Night security illumination 131
Normal occupant weight 338
Number, paintwork code 438
Number,
vehicle identification (VIN) 438, 439O
Occupant Classification System see OCS
Occupant distribution 338
Occupant safety 64
Active head restraints 79
Air bags 65
Children and air bags 80
Children in the vehicle 80
ETD 78
Fastening the seat belts 47
Front air bags 69
Front passenger front air bag off
indicator lamp 74, 366
Front side impact air bags 70
Infant and child restraint systems 80
LATCH-type child seat anchors 85
OCS 70
Rear side impact air bags* 70
Seat belts 47, 75
Seat belts, safety guidelines 68
SRS 64
Window curtain air bags 70
