437 Controls in detail
Driving systems
Front sensors
Rear sensorsWarning indicators
Visual signals indicate to the driver the rel-
ative distance between the sensors and an
obstacle.
The warning indicator for the front area is
in the instrument cluster. The warning indi-
cator for the rear area is on the roof liner in
the rear.
1Left side of the vehicle
2Right side of the vehicle
3Readiness indicator
Each warning indicator is divided into five
yellow and two red distance segments for
either side of the vehicle.
If yellow readiness indicators 3 under the
distance segments are lit, Park Assist is
ready to measure.The position of the gear selector lever de-
termines which warning indicators will be
activated.
As your vehicle approaches an object, one
or more distance segments will illuminate,
depending on the distance. When the sev-
enth distance segment illuminates, you
have reached the minimum distance.
iDue to the sensors’ broad detection range,
it is possible that Park Assist also detects the fol-
lowing obstacles and issues a warning:

obstacles in the ground, e.g. sewer canal
covers, rails, bumps in the road or gutters

obstacles moving upward quickly, e.g. rolling
garage doors
Centerapprox. 40 in (100 cm)
Cornersapprox. 24 in (60 cm)
Centerapprox. 50 in (125 cm)
Cornersapprox. 24 in (60 cm)
!While parking, pay particular attention to ob-
jects over or underneath the sensors, e.g. flower
boxes, an elevated crossbar or a trailer tow
hitch. Park Assist does not detect such nearby
objects. You could otherwise damage the vehicle
or the objects.
Gear selector
lever positionWarning indicator
DFront area activated
RFront and rear area
activated
NWith the electronic
parking brake engaged:
neither activated.
With the electronic
parking brake released:
front and rear area acti-
vated.
PNeither activated
ProCarManuals.com

438 Controls in detail
Driving systems

Front area:
As soon as the first red distance seg-
ment comes on, you will hear an inter-
mittent warning tone for approximately
2 seconds. Once the second red dis-
tance segment comes on, you will hear
a continuous warning tone. You have
reached the minimum distance.

Rear area:
As soon as the first red distance seg-
ment comes on, you will hear an inter-
mittent warning tone for approximately
2 seconds. Once the second red dis-
tance segment comes on, you will hear
a continuous warning tone. You have
reached the minimum distance.Collision warning
Park Assist can detect obstacles from a
considerable distance. If you drive in re-
verse towards an obstacle, you will hear a
warning tone. You must then brake in or-
der to avoid a collision. The warning tone
for a collision will not sound when the vehi-
cle is at a standstill very close to the obsta-
cle. In this case, you will hear a
corresponding tone for the warning indica-
tor in the rear area.
Switching Park Assist system on/off
The Park Assist system can be switched off
manually.
The Park Assist button with the indicator
lamp is located on the control panel on the
right-hand side of the instrument cluster.1Park Assist button
2Indicator lamp
Switching off Park Assist system:
Press button 1.
Indicator lamp 2 comes on.
Switching on Park Assist system:
Press button 1 again.
Indicator lamp 2 goes out.iDuring strong rainfall, the warning indicators
and warning tones may be triggered, for exam-
ple, by water splashing into the area of the sen-
sors.
iDuring strong rainfall, the collision warning
may be triggered, for example, by water splash-
ing into the area of the sensors.
iWhen the indicator lamp is illuminated, the
Park Assist system is switched off.
iThe Park Assist system is automatically
switched on when the ignition (
page 336) and
radar sensors are switched on (
page 272).
ProCarManuals.com

496 Controls in detail
Useful features
Infrared reflecting windshield
Your vehicle is equipped with infrared re-
flecting glass, which reduces the amount
of radiated heat entering the vehicle interi-
or through the windows.
The infrared reflecting glass also prevents
the transmission of signals through the
glass by in-vehicle electronic devices
(e.g. electronic toll collection devices).
To allow the use of these devices in the ve-
hicle, transparent areas 1 and 3 are
placed in the windshield.
You can see them from certain angles
when ambient light condition permit.
Vehicles without Night View Assist*
1Transparent area (located left and right
to the cover of the rain light sensor)
2Cover of the rain light sensor
3Transparent area
Vehicles with Night View Assist*
1Transparent area (located left to the
cover of the rain light sensor)
2Cover of the rain light sensor
3Transparent area
ProCarManuals.com

507 Operation
Driving instructions
Catalytic converter
Your Mercedes-Benz is equipped with
monolithic-type catalytic converters, an
important element in conjunction with the
oxygen sensors to achieve substantial con-
trol of the pollutants in the exhaust emis-
sions. Keep your vehicle in proper
operating condition by following our rec-
ommended maintenance instructions as
outlined in your Maintenance Booklet.Emission control
Certain parts of the engine and the emis-
sion control system serve to keep the toxic
components of the exhaust gases within
permissible limits required by law.
These systems will function properly only
when maintained strictly according to fac-
tory specifications. Any adjustments on
the engine should, therefore, be carried
out only by qualified Mercedes-Benz Cen-
ter authorized technicians.
Engine adjustments should not be altered
in any way. The specified service proce-
dures must be carried out regularly accord-
ing to Mercedes-Benz servicing
requirements. For details please refer to
the Maintenance Booklet.
!To prevent damage to the catalytic convert-
ers, only use premium unleaded gasoline in this
vehicle.
Any noticeable irregularities in engine operation
should be repaired promptly. Otherwise, exces-
sive unburned fuel may reach the catalytic con-
verter, causing it to overheat and potentially
start a fire.
Warning!G
As with any vehicle, do not idle, park or op-
erate this vehicle in areas where combusti-
ble materials such as grass, hay or leaves
can come into contact with the hot exhaust
system, as these materials could be ignited
and cause a vehicle fire.
ProCarManuals.com

531 Operation
Tires and wheels
Checking tire pressure electronically
with the Advanced Tire Pressure
Monitoring System (Advanced TPMS)The Advanced TPMS only functions on
wheels that are equipped with the proper
electronic sensors. It monitors the tire in-
flation pressure, as selected by the driver,
in all four tires. A warning is issued to alert
you to a decrease in pressure in one or
more of the tires.
Tire inflation pressure inquiries are made
using the multifunction display. The
present inflation pressures are displayed
only after a few minutes of travel time.
iThe Advanced Tire Pressure Monitoring
System (Advanced TPMS) is equipped with a
combination low tire pressure/TPMS malfunc-
tion telltale in the instrument cluster
(
page 576). Depending on how the telltale illu-
minates, it indicates a low tire inflation pressure
condition or a malfunction in the Advanced
TPMS system itself:

If the telltale illuminates continuously, one
or more of your tires is significantly underin-
flated. There is no malfunction in the
Advanced TPMS.

If the telltale flashes for 60 seconds and
then stays illuminated, the Advanced TPMS
system itself is not operating properly.
iUSA only:
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
iCanada only:
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation of the device.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.iPossible differences between the readings
of a tire inflation pressure gauge of an air hose,
e.g. gas station equipment, and the vehicle’s
control system can occur. Usually the readings
issued by the control system are more precise.
iThe menu overview can be found on
(
page 258).
ProCarManuals.com

532 Operation
Tires and wheels
Switch on the ignition (page 336).
Press( or& to select the menu
“Service”.
Press$ or% to select “Tire
pressure”.
Press#.
iWhen the message “Tire pressures dis-
played after driving a few minutes” appears in
the display, the individual inflation pressure val-
ues are matched with the tires. The individual
values are displayed after a few minutes driving.
Warning!G
It is the driver’s responsibility to calibrate
the Advanced TPMS on the recommended
cold inflation pressure. Underinflated tires
affect the ability to steer or brake the vehi-
cle. You might lose control over the vehicle.
iWith a spare wheel without wheel sensor
mounted, the system may still indicate the tire
inflation pressure of the removed wheel for some
minutes. If this happens, keep in mind that the
indicated value where the spare wheel is mount-
ed does not reflect the actual spare tire inflation
pressure.
Warning!G
The Advanced TPMS does not indicate a
warning for wrongly selected inflation pres-
sures. Always adjust tire inflation pressure
according to the Tire and Loading Informa-
tion placard on the driver’s door B-pillar or,
if available, the supplemental tire inflation
pressure information on the inside of the
fuel filler flap.
The Advanced TPMS is not able to issue a
warning due to a sudden dramatic loss of
pressure (e.g. tire blowout caused by a for-
eign object). In this case bring the vehicle to
a halt by carefully applying the brakes and
avoiding abrupt steering maneuvers.

ProCarManuals.com

534 Operation
Tires and wheels
Reactivating Advanced TPMS
The Advanced TPMS must be reactivated
when you have adjusted the tire inflation
pressure to a new level (e.g. because of dif-
ferent load or driving conditions). The Ad-
vanced TPMS is then recalibrated to the
current tire inflation pressures.
Using the Tire and Loading Information
placard on the driver’s door B-pillar
(
page 523) or, if available, the sup-
plemental tire inflation pressure
information on the inside of the fuel fill-
er flap (
page 509), make sure the tire
inflation pressure of all four tires is
correct.
Switch on the ignition (page 336).
Press( or& to select the menu
“Service”.
Press$ or% to select
“Tire pressure”.
Press#.
You will see

the current inflation pressures for
each tire
or

the message
“Tire pressures
displayed after driving
a few minutes”
appear in the multifunction display.
Press%.
The message
“Use current pressure
values as new
reference values
To confirm press "OK"”
appears in the multifunction display.
Warning!G
It is the driver’s responsibility to calibrate
the Advanced TPMS on the recommended
cold inflation pressure. Underinflated tires
affect the ability to steer or brake the vehi-
cle. You might lose control over the vehicle.
iReactivate the Advanced TPMS after adjust-
ing the tire inflation pressure to the inflation
pressure recommended for the vehicle operating
condition. Tire inflation pressure should only be
adjusted on cold tires. Observe the recommend-
ed tire inflation pressure on the Tire and Loading
Information placard on the driver’s door B-pillar
(
page 523). Some vehicles may have supple-
mental tire inflation pressure information for
driving at high speeds (
page 529) or for vehi-
cle loads less than the maximum loaded vehicle
condition. If such information is provided, it can
be found on the inside of the fuel filler flap
(
page 509).
iAfter wheel rotation or sensor replacement,
the vehicle must be parked for 20 minutes be-
fore attempting to reactivate the Advanced
TPMS.
iThe menu overview can be found on
(
page 258).
ProCarManuals.com

556 Operation
Vehicle care
Engine cleaning
Prior to cleaning the engine compartment,
make sure to protect electrical compo-
nents and connectors from contact with
water and cleaning agents.
Corrosion protection, such as
MB Anticorrosion Wax, should be applied
to the engine compartment after every
engine cleaning. Before applying, all
control linkage bushings and joints should
be lubricated. The poly-V-belt and all pul-
leys should be protected from any wax.
Vehicle washing
In the winter, thoroughly remove all traces
of road salt as soon as possible.
When washing the vehicle underbody, do
not forget to clean the inner sides of the
wheels.Hand-wash
Do not use hot water or wash your vehicle
in direct sunlight.
Only use a mild car wash detergent,
such as Mercedes-Benz approved Car
Shampoo.
Thoroughly spray the vehicle with a dif-
fused jet of water.
Direct only a very weak spray towards
the ventilation intake.
Use plenty of water and rinse the
sponge and chamois frequently.
Rinse with clean water and thoroughly
dry with a chamois.
Do not allow cleaning agents to dry on
the finish.Automatic car wash
You can have your car washed in an auto-
matic car wash from the start.
To protect the filter system, switch the
automatic climate control to air recir-
culation mode (
page 458).
If the vehicle is very dirty, prewash it be-
fore running it through the automatic car
wash.
iVehicles with KEYLESS-GO*:
If a door handle is hit by a strong jet of water, and
a SmartKey with KEYLESS-GO* is in close prox-
imity, i.e. within approximately 3 ft (approxi-
mately 1 m), the vehicle could be inadvertently
locked or unlocked.
!Do not use scouring agents on these parts.
Never apply strong force and only use a soft,
non-scratching cloth when cleaning the vehicle.
Do not attempt to wipe the surface with a dry
cloth or sponge.
Otherwise you may scratch or damage the paint.
!Do not clean your vehicle in an automatic
touchless car wash which uses caustic spray.
Otherwise the caustic spray will damage the
paint or ornamental moldings.
!Make sure that the windshield wiper switch
is set to0 (
page 372). Otherwise, e.g. the rain
sensor could activate and cause the wipers to
move unintentionally. This may lead to vehicle
damage.
Due to the width of the vehicle, fold in exterior
rear view mirrors prior to running the vehicle
through an automatic car wash to prevent dam-
age to the mirrors.
ProCarManuals.com
