2007 MERCEDES-BENZ CL-CLASS technical data

685 Technical data
Fuels, coolants, lubricants, etc.
ModelCapacityFuels, coolants, lubricants, etc.
Power steeringCL 550approx. 1.06 US qt. (1.0 l)MB Power Steering Fluid
(Pentosin CHF 11S or, depending on
vehicle production date,
Chevron Texaco PSF 9109)
1
1For detailed information, please refer to the Factory Approved Service Products pamphlet (USA only) or contact an authorized Mercedes-Benz Center.
CL 600approx. 1.27 US qt. (1.2 l)
Front wheel hubsAll modelsapprox. 3.6 oz. (95 g) eachHigh-temperature roller bearing
grease
Brake systemAll modelsapprox. 0.53 US qt. (0.5 l)MB Brake Fluid (DOT 4 Plus)
Cooling systemCL 55012.15 US qt. (11.5 l)MB 325.0 Anticorrosion/Antifreeze
CL 60013 US qt. (12.3 l)
Low temperature cooling systemCL 6002.75 US qt. (2.6 l)
Fuel tankAll models23.78 US gal (90.0 l)Premium unleaded gasoline:
Minimum Posted Octane 91
(Avg. of 96 RON/86 MON)
including a reserve ofAll models 2.9 US gal (11.0 l)
Air conditioning systemAll modelsR-134a refrigerant and special PAG
lubricant oil (never R-12)
Windshield washerAll models6.87 US qt (6.5 l)MB Windshield Washer Concentrate2
2Use MB Windshield Washer Concentrate “MB SummerFit” and water for temperatures above freezing or MB Windshield Washer Concentrate “MB SummerFit” and
commercially available premixed windshield washer solvent/antifreeze for temperatures below freezing point. Follow suggested mixing ratios (page 691).
ProCarManuals.com

686 Technical data
Fuels, coolants, lubricants, etc.
Engine oils
Engine oils are specifically tested for their
suitability in our engines and durability for
our service intervals. Therefore, only use
approved engine oils and oil filters
required for vehicles with Maintenance
System (U.S. vehicles, Canada vehicles,
depending on vehicle production date) or
FSS PLUS (Canada vehicles, depending on
vehicle production date). For a listing of
approved engine oils and oil filters, refer to
the Factory Approved Service Products
pamphlet (USA only), or contact an autho-
rized Mercedes-Benz Center.Engine oil additives
Air conditioning refrigerant
R-134a (HFC) refrigerant and special PAG
lubricating oil are used in the air condition-
ing system.
!Using engine oils and oil filters of
specification other than those expressly
required for the Maintenance System
(U.S. vehicles, Canada vehicles, depending on
vehicle production date) or FSS PLUS (Canada
vehicles, depending on vehicle production date),
or changing of oil and oil filter at change intervals
longer than those called for by the Maintenance
System (U.S. vehicles, Canada vehicles, depend-
ing on vehicle production date) or FSS PLUS
(Canada vehicles, depending on vehicle produc-
tion date) will result in engine or emission control
system damage not covered by the
Mercedes-Benz Limited Warranty.
Please follow Maintenance System
(U.S. vehicles, Canada vehicles, depending on
vehicle production date) or FSS PLUS (Canada
vehicles, depending on vehicle production date)
recommendations for scheduled oil changes.
Failure to do so will result in engine or emission
control system damage not covered by the
Mercedes-Benz Limited Warranty.
!Do not blend oil additives with engine oil.
They may damage the engine.
Damage or malfunctions resulting from blending
oil additives are not covered by the
Mercedes-Benz Limited Warranty.
!Never use R-12 (CFC) or mineral-based
lubricating oil. Otherwise damage to the system
will occur.
ProCarManuals.com

687 Technical data
Fuels, coolants, lubricants, etc.
Brake fluid
Only brake fluid approved by
Mercedes-Benz is recommended. Your au-
thorized Mercedes-Benz Center will pro-
vide you with additional information.Premium unleaded gasoline
Warning!G
During vehicle operation, the boiling point of
the brake fluid is continuously reduced
through the absorption of moisture from the
atmosphere.
Under extremely strenuous operating condi-
tions, this moisture content can lead to the
formation of bubbles in the system, thus re-
ducing the system’s efficiency.
Therefore, the brake fluid must be replaced
regularly. Refer to your vehicle’s
Maintenance Booklet for replacement inter-
val.
Warning!G
Gasoline is highly flammable and poisonous.
It burns violently and can cause serious
personal injury.
Never allow sparks, flame or smoking mate-
rials near gasoline!
Turn off the engine before refueling.
Whenever you are around gasoline, avoid in-
haling fumes and skin or clothing contact,
extinguish all smoking materials.
Direct skin contact with fuels and the inha-
lation of fuel vapors are damaging to your
health.
!To maintain the engine’s durability and per-
formance, premium unleaded gasoline must be
used. If premium unleaded gasoline is not avail-
able and low octane fuel is used, follow these
precautions:

Have the fuel tank only partially filled with
unleaded regular gasoline and fill up with
premium unleaded gasoline as soon as
possible.

Avoid full throttle driving and abrupt acceler-
ation.

D o n o t e x c e e d a n e n g i n e s p e e d o f 3 0 0 0 r p m
if the vehicle is loaded with a light load such
as two persons and no luggage.

Do not exceed 2/3 of maximum accelerator
pedal position if the vehicle is fully loaded or
operating in mountainous terrain.
ProCarManuals.com

688 Technical data
Fuels, coolants, lubricants, etc.
Fuel requirements
Only use premium unleaded fuel:

The octane number (posted at the
pu m p) m us t b e 91 mi n. It is an a vera ge
of both the Research Octane Number
(RON) and the Motor Octane Number
(MON): (RON+MON)/2. This is also
known as the ANTI-KNOCK INDEX.
Unleaded gasoline containing oxygenates
such as ethanol, IPA, IBA and TBA can be
used provided the ratio of any one of these
oxygenates to gasoline does not
exceed 10%; MTBE must not exceed 15%.
The ratio of methanol to gasoline must not
exceed 3% plus additional co-solvents.
Using mixtures of ethanol and methanol is
not allowed. Gasohol, which contains
10% ethanol and 90% unleaded gasoline,
can be used.
These blends must also meet all other fuel
requirements, such as resistance to spark
knock, boiling range, vapor pressure, etc.
Gasoline additives
A major concern among engine manufac-
turers is carbon build-up caused by gaso-
line. Mercedes-Benz recommends only the
use of quality gasoline containing additives
that prevent the build-up of carbon depos-
its.
After an extended period of using fuels
without such additives, carbon deposits
can build up especially on the intake valves
and in the combustion area, leading to en-
gine performance problems such as:

Warm-up hesitation

Unstable idle

Knocking/pinging

Misfire

Power lossIn areas where carbon deposits may be en-
countered due to lack of availability of gas-
olines which contains these additives,
Mercedes-Benz recommends the use of
additives approved by us for use on
Mercedes-Benz vehicles. Refer to the
Factory Approved Service Products pam-
phlet (USA only) or contact an authorized
Mercedes-Benz Center of listing of ap-
proved product(s). Follow directions on
product label.
Do not blend other fuel additives with fuel.
This only results in unnecessary cost and
may be harmful to the engine operation.
!Damage or malfunction resulting from poor
fuel quality or from blending additional fuel addi-
tives other than those tested and approved by us
for use on Mercedes-Benz vehicles are not cov-
ered by the Mercedes-Benz Limited Warranty.
For a listing of approved products, refer to the
Factory Approved Service Products pamphlet
(USA only) or contact an authorized
Mercedes-Benz Center.
ProCarManuals.com

689 Technical data
Fuels, coolants, lubricants, etc.
Coolants
The engine coolant is a mixture of water
and anticorrosion/antifreeze, which pro-
vides:

Corrosion protection

Freeze protection

Boiling protection (by increasing the
boiling point)
The cooling system was filled at the factory
with a coolant providing freeze protection
to approximately -35°F (-37°C) and corro-
sion protection.
If the antifreeze mixture is effective to
-35°F (-37°C), the boiling point of the cool-
ant in the pressurized cooling system is
reached at approximately 266°F (130°C).The coolant solution must be used year
round to provide the necessary corrosion
protection and increase boil-over protec-
tion. Refer to Maintenance Booklet for re-
placement interval.
Coolant system design and coolant used
determine the replacement interval. The
replacement interval published in the
Maintenance Booklet is only applicable if
MB 325.0 Anticorrosion/Antifreeze solu-
tion or other Mercedes-Benz approved
products of equal specification are used to
renew the coolant concentration or bring it
back up to the proper level.
For information on other Mercedes-Benz
approved products of equal specification,
refer to the Factory Approved Service
Products pamphlet (USA only) or contact
an authorized Mercedes-Benz Center.To provide important corrosion protection,
the solution must be at least 50% anticor-
rosion/antifreeze (equivalent to freeze
protection to approximately -35°F
[-37°C]). If you use a solution that is more
than 55% anticorrosion/antifreeze (freeze
protection to approximately -49°F
[-45°C]), the engine temperature will in-
crease due to the lower heat transfer capa-
bility of the solution. Therefore, do not use
more than this amount of anticorrosion/
antifreeze.
If the coolant level is low, water and
MB 325.0 Anticorrosion/Antifreeze
should be used to bring it up to the proper
level (have cooling system checked for
signs of leakage).
The water in the cooling system must meet
minimum requirements, which are usually
satisfied by normal drinking water. If you
are not sure about the water quality, con-
sult an authorized Mercedes-Benz Center.
!Add premixed coolant solution only. Adding
water and MB 325.0 Anticorrosion/Antifreeze
separately from each other, could cause engine
damage not covered by the Mercedes-Benz Lim-
ited Warranty.
ProCarManuals.com

690 Technical data
Fuels, coolants, lubricants, etc.
Anticorrosion/antifreeze
Your vehicle contains a number of alumi-
num parts. The use of aluminum compo-
nents in motor vehicle engines
necessitates that anticorrosion/antifreeze
coolant used in such engines be specifical-
ly formulated to protect the aluminum parts. Failure to use such anticorrosion/
antifreeze coolant will result in a signifi-
cantly shortened service life.
Therefore, the following product is strongly
recommended for use in your vehicle:
MB 325.0 Anticorrosion/Antifreeze agent.Before the start of the winter season (or
once a year in hot southern regions), you
should have the anticorrosion/antifreeze
concentration checked. The coolant is also
regularly checked each time you bring your
vehicle to an authorized Mercedes-Benz
Center for service.
Anticorrosion/antifreeze quantity
ModelApproximate freeze protection
-35°F (-37°C)-49°F (-45°C)
CL 5506.08 US qt. (5.75 l)6.71 US qt. (6.35 l)
CL 600 (main cooling system)6.5 US qt. (6.15 l)7.14 US qt. (6.76 l)
CL 600 (low temperature cooling system)1.37 US qt. (1.3 l)1.51 US qt. (1.43 l)
ProCarManuals.com

691 Technical data
Fuels, coolants, lubricants, etc.
Windshield washer system and
headlamp cleaning system
Both the windshield washer system and
headlamp cleaning system are supplied
from the windshield washer reservoir.
The windshield washer reservoir has a ca-
pacity of approximately 6.87 US qt (6.5 l).
Refill the reservoir with MB Windshield
Washer Concentrate and water (or con-
centrate and commercially available
premixed windshield washer solvent/
antifreeze, depending on ambient tem-
peratures).Windshield and headlamp washer fluid
mixing ratio
For temperatures above freezing point, use
MB Windshield Washer Concentrate
“MB SummerFit” and water:

1 part “MB SummerFit” to 100 parts
water
(1.34 fl oz [40 ml] “MB SummerFit” to
1 gal [4.0 l] water).
For temperatures below freezing point, use
MB Windshield Washer Concentrate
“MB SummerFit” and commercially avail-
able premixed windshield washer sol-
vent/antifreeze:

1 part “MB SummerFit” to 100 parts
solvent
(1.34 fl oz [40 ml] “MB SummerFit” to
1 gal [4.0 l] solvent).
Warning!G
Washer solvent/antifreeze is highly flamma-
ble. Do not spill washer solvent/antifreeze
on hot engine parts, because it may ignite
and burn. You could be seriously burned.
ProCarManuals.com

699 Index
Driving systems 405
ABC 429
Cruise control 405
DISTRONIC Plus* 411
Driving safety systems 64
Dynamic Rear View Monitor* 439
Park Assist* 435
Parktronic system* 431
Vehicle level control (ABC) 429
Driving tips 396
Kickdown 396
DVD 107
Audio (COMAND) 107
Changer (COMAND) 111
Changer (Voice Control) 303
Ejecting (COMAND) 113
Loading (COMAND) 111
Playback options (COMAND) 119
Selecting a medium (COMAND) 117
Selecting a track (COMAND) 117
Setting
the audio format (COMAND) 119Dynamic Rear View Monitor* 439
Camera lens 560
Cleaning camera lens 560
Parallel parking 443
Reverse parking
(back-in parking) 441
Switching on 441
View through the camera 439E
Easy-entry/exit feature 344
COMAND menu 239
EBP 69
Electrical fuses see Fuses
Electrical system, Technical Data 682
Electronic Brake Proportioning see EBP
Electronic parking brake 384
Indicator lamp 31, 568
Mechanically releasing 637
Messages in display 599
Warning lamp 31, 568
Electronic Stability Program see ESP
®
Electronic traction system 71
Emergency call system 482
Emergency calls, Tele Aid 483
Emergency engine shut-down 670
Emergency operation
(Limp-Home Mode) 401
ProCarManuals.com
