370
5-2. Steps to take in an emergency
Starting the engine
For vehicles with an automatic transmission: Put the shift lever in P
and apply the brakes.
For vehicles with a manual transmission: Depress the clutch
pedal.
Hold the electronic key close to
the engine switch (within 0.4 in.
[10 mm]). Make sure that the but-
ton side of the key is facing away
from the engine switch.
An alarm will sound to indicate that
the start function cannot detect the
key with the depleted battery if any
of the doors will be opened and
closed while this operation.
For vehicles with an automatic transmission: Press the engine
switch within 5 seconds [after the buzzer sounds], keeping the
brake pedal depressed.
For vehicles with a manual transmission: Press the engine switch
within 5 seconds [after the buzzer sounds], keeping the clutch
pedal depressed.
In the event that the engine still cannot be started, contact your Lexus
dealer.
STEP1
STEP2
STEP3

5
When trouble arises
371
5-2. Steps to take in an emergency
■Replacing the key battery
As this procedure is the temporary measure, it is recommended that the electronic
battery be replaced immediately. (P. 3 0 2 )

386
6-1. Specifications
Electrical system
Differential
Battery
Specific gravity reading at
68F (20C):12.6 12.8 V Fully charged
12.2 
12.4 V Half charged
11.8 
12.0 V Discharged
(Voltage checked 20 minutes after the
key is removed with all the lights turned
off)
Charging rates5A max.
Oil capacity
Front0.74 qt. (0.70 L, 0.61 lmp.qt.)
Rear
IS350:
1.42 qt. (1.35 L, 1.19 lmp.qt.)
IS250 (2WD models):
1.20 qt. (1.15 L, 1.01 lmp.qt.)
IS250 (AWD models):
1.10 qt. (1.05 L, 0.92 lmp.qt.)
Oil type and
viscosity
IS250 (AWD)
Hypoid gear oil API GL-5
Above 0F (-18C): SAE90
Below 0F (-18C): SAE80W
or SAE80W-90
Others
Toyota Genuine Differential
Gear Oil LT 75W-85 GL-5,
Toyota Genuine Differential
Synthetic Gear Oil or equivalent

408
6-2. Customization
Door lock
(
P. 1 9 )
Unlocking using a key
Driver's door
unlocked in one
step, all doors
unlocked in two
steps
All doors
unlocked in one
step
Speed-detecting auto-
matic door lock function
(Manual transmissions)
ONOFF
Speed-detecting auto-
matic door lock function
(Automatic transmissions)
OFFON
Opening driver's door
unlocks all doors (Manual
transmissions)
ONOFF
Opening driver's door
unlocks all doors (Auto-
matic transmissions)
OFFON
Shifting gears to P
unlocks all doors.ONOFF
Shifting gears to position
other than P locks all
doors.
ONOFF
ItemFunctionDefault settingCustomized
setting

409
6-2. Customization
6
Vehicle specifications
ItemFunctionDefault settingCustomized
setting
Po w e r w i n -
dows
(
P. 4 5 )
Linked door lock opera-
tionONOFF
Linked door key opera-
tionOpen and closeOpen only
Close only
Wireless remote control
linked operationONOFF
Moon roof
(
P. 4 8 )
Linked door lock opera-
tionONOFF
Linked door key opera-
tionOpen and closeOpen only
Close only
Linked operation of com-
ponents when door key is
used
Slide onlyTilt only
Wireless remote control
linked operationONOFF
Linked operation of com-
ponents when wireless
remote control used
Slide onlyTilt only
Automatic
light control
system
(
P. 122)
Light sensor sensitivityLevel 3Level 1 to 5
Time elapsed before
headlights automatically
turn off after doors are
closed
30 seconds
0 seconds
60 seconds
90 seconds

417
Alphabetical index
Care
Exterior ................................................... 252
Interior..................................................... 254
Seat belts ............................................... 255
Cargo capacity ....................................... 157
Cargo hooks .......................................... 238
CD changer .............................................189
CD player..................................................189
Chains.......................................................... 161
Child restraint system (CRS)
Booster seats, definition..................... 77
Booster seats, installation ................... 81
Convertible seats, definition ............ 77
Convertible seats, installation .......... 81
Front passenger occupant
classification system ......................... 72
Infant seats, definition .......................... 77
Infant seats, installation......................... 81
Installing CRS with lower
anchorages .......................................... 84
Installing CRS with seatbelts ............ 81
Installing CRS with top straps ........ 85
Child safety
Airbag precautions ..............................67
Battery precautions................ 281, 374
Child restraint system ......................... 77
Child-protectors................................... 20
How your child should wear
the seatbelt ............................................ 37
Installing child restraints .................... 80
Moon roof precautions ..................... 50
Power window lock switch ............. 45
Power window precautions............. 47
Removed electronic key battery
precautions ....................................... 303
Seat belt comfort guide..................... 35
Seat belt extender precautions ..... 39Seat belt precautions ..........................38
Seat heater precautions........229, 231
Trunk precautions................................. 25
Child-protectors ...................................... 20
Cigarette lighter.................................... 226
Cleaning
Exterior.................................................... 252
Interior ..................................................... 254
Seat belts ................................................255
Clock ...........................................................221
Coat hooks .............................................. 236
Compass .................................................. 246
Condenser .............................................. 278
Console box ............................................ 214
Cooling system
Engine overheating...........................375
Cornering assist sensors .................... 142
Cruise control
Cruise control....................................... 130
Dynamic radar cruise control....... 133
Cup holder ............................................... 216
Curtain shield airbags..............................61
Customizable features .......................406
Daytime running light system ........... 123
Defogger
Rear window ......................................... 178
Side mirror.............................................. 178
Dimension............................................... 380
Dinghy towing ................................166, 167
Display
Dynamic radar cruise control....... 133
Satellite switch mode ....................... 222
Trip information ..................................... 119
Warning message ............................. 344
Do-it-yourself maintenance ............. 263C
D

418
Alphabetical index
Door courtesy lights
Door courtesy lights.........................209
Wattage.................................................. 394
Door pockets........................................... 218
Doors
Door glasses ........................................... 45
Door lock.................................................... 19
Side mirrors ............................................. 43
Driver's seat belt reminder light ...... 341
Driving
Correct posture .................................... 59
Procedures .............................................. 90
Driving position memory ......................28
Electric power steering (EPS) .......... 148
Electronic key
If your electronic key battery
is discharged .................................... 369
Emergency, in case of
If the engine will not start ............... 366
If the shift lever cannot be
shifted from P ................................... 367
If the vehicle has discharged
battery .................................................. 372
If the warning buzzer sounds ...... 339
If the warning light turns on .......... 339
If the warning message is
displayed ............................................ 344
If you have a flat tire .........................358
If you lose your keys.........................368
If you think something is
wrong ................................................... 335
If your electronic key battery
is discharged .................................... 369
If your vehicle becomes stuck......377If your vehicle needs to be
towed ................................................... 328
If your vehicle overheats.................375
Engine
Compartment ..................................... 269
Engine switch ......................................... 98
Hood ....................................................... 266
How to start the engine .................... 98
Identification number ........................ 381
If the engine will not start ............... 366
Overheating .........................................375
Engine compartment cover ............... 271
Engine coolant
Capacity ................................................ 385
Checking................................................276
Preparing and checking
before winter........................................ 161
Engine coolant temperature
gauge ...................................................... 109
Engine immobilizer system ................. 54
Engine oil
Capacity ................................................ 384
Checking................................................ 272
Preparing and checking
before winter........................................ 161
Engine oil maintenance data ........... 275
EPS (Electric power steering) ......... 148
Event data recorder ............................ 337
First-aid kit storage belt ..................... 238
Floor mat .................................................. 237
Fluid
Brake ........................................................278
Washer................................................... 282
E
F

420
Alphabetical index
Keys
Electronic key ............................................. 2
Engine switch.......................................... 98
If you lose your keys.........................368
If your electronic key battery
is discharged .................................... 369
Key number ................................................. 2
Keys ................................................................. 2
Mechanical key.......................................... 2
Wireless remote control..................... 16
Light bulbs
Replacing .................................................319
Wattage.................................................. 394
Lights
Door courtesy lights.........................209
Fog light switch..................................... 125
Headlights switch ................................ 122
Interior light switch................................ 211
Outer foot lights ................................. 209
Overhead courtesy light................209
Personal light switch ............................211
Replacing light bulbs..........................319
Scuff lighting .........................................209
Shift lever lighting .............................. 209
Turn signal lever ................................... 107
Vanity lights .......................................... 220
Wattage.................................................. 394
Load capacity .......................................... 160
Maintenance
Do-it-yourself maintenance ......... 263
General maintenance ..................... 259
Maintenance data............................. 380
Maintenance requirements .......... 257
Manual transmission............................. 105Meter
Instrument panel light control .........110
Meters.......................................................109
Mirrors
Inside rear view mirror ....................... 42
Side mirror heater............................... 178
Side mirrors.............................................. 43
Vanity mirrors ..................................... 220
Moon roof................................................... 48
MP3 disc........................................................ 195
Multi-information display........................118
Odometer ................................................ 109
Oil
Engine oil................................................ 272
Opener
Fuel filler door .......................................... 51
Hood ....................................................... 266
Trunk............................................................ 23
Outer foot lights
Outer foot lights................................. 209
Wattage ................................................. 394
Outside rear view mirrors
Adjusting and folding .......................... 43
Driving position memory ..................28
Outside temperature display ............. 119
Overhead console .................................215
Overhead courtesy lights
Overhead courtesy lights ............. 209
Wattage ................................................. 394
Overheating, Engine..............................375
Parking assist sensors........................... 142
Parking brake.......................................... 108K
L
M
O
P
