2007 Lexus IS250 clock

TABLE OF CONTENTSIndex
iv
• Bottle holders/door
pockets ........................................... 218
3-5. Other interior features............ 219
Sun visors.......................................... 219
Vanity mirror .................................. 220
Clock .................................................. 221
Satellite switches .......................... 222
Ashtrays ........................................... 225
Cigarette lighter ........................... 226
Power outlet ................................... 227
Seat heaters.................................... 228
Seat heaters and ventilators ... 230
Armrest ............................................ 232
Rear sunshade ............................... 233
Extended trunk.............................. 235
Coat hooks ..................................... 236
Floor mat.......................................... 237
Trunk features............................... 238
Garage door opener................... 241
Compass........................................... 246
4-1. Maintenance and care............ 252
Cleaning and protecting
the vehicle exterior................... 252
Cleaning and protecting
the vehicle interior .................... 2544-2. Maintenance.............................. 257
Maintenance requirements ..... 257
General maintenance ................ 259
Emission inspection and
maintenance (I/M)
programs ...................................... 262
4-3. Do-it-yourself
maintenance............................ 263
Do-it-yourself service
precautions .................................. 263
Hood.................................................. 266
Positioning the jack ..................... 267
Engine compartment.................. 269
Tires .................................................. 283
Tire inflation pressure................. 293
Wheels.............................................. 297
Air conditioning filter.................. 299
Electronic key battery ............... 302
Checking and replacing
fuses ............................................... 304
Headlight aim.................................. 318
Light bulbs ........................................ 319
5-1. Essential information .............. 328
If your vehicle needs to
be towed ...................................... 328
If you think something is
wrong ............................................ 335
4Maintenance and care
5When trouble arises

xiii
Without navigation system
Navigation
system
*1
Clock

P. 221
Audio
system

P. 179
Air conditioning
system
P. 170
Rear window and out-
side rear view mirror
defoggers
P. 178
Security indicator
P. 54, 56
Emergency
flashers
Clock P. 221
Audio system*1
Security indicator
P. 54, 56
Emergency flashers Air conditioning
system
*1
With navigation system
: If equipped
*1: Refer to “Navigation System Owner's Manual”.
Rear window and
outside rear view
mirror defoggers
*1
A

Interior features3
169
3-1. Using the air conditioning
system and defogger ........... 170
Automatic air conditioning
system .......................................... 170
Rear window and outside rear
view mirror defoggers........... 178
3-2. Using the audio system ......... 179
Audio system type ..................... 179
Using the radio ............................ 182
Using the CD player ................. 189
Playing back MP3 and
WMA discs................................ 195
Optimal use of the audio
system ......................................... 203
Using the AUX adapter ......... 206
Using the steering wheel
audio switches ......................... 207
3-3. Using the interior lights ....... 209
Interior lights list........................ 209
• Interior lights and
personal lights............................. 211
3-4. Using the storage
features ................................... 213
List of storage features............. 213
• Glove box .................................. 213• Console boxes .......................... 214
• Overhead console ................. 215
• Cup holders ............................... 216
• Bottle holders/door
pockets ........................................ 218
3-5. Other interior features......... 219
Sun visors ...................................... 219
Vanity mirror ............................... 220
Clock................................................ 221
Satellite switches ....................... 222
Ashtrays ........................................ 225
Cigarette lighter........................ 226
Power outlet ................................ 227
Seat heaters ................................ 228
Seat heaters and
ventilators .................................. 230
Armrest ......................................... 232
Rear sunshade............................ 233
Extended trunk .......................... 235
Coat hooks .................................. 236
Floor mat ...................................... 237
Trunk features ............................. 238
Garage door opener................. 241
Compass ...................................... 246

221
3-5. Other interior features
3
Interior features
Clock
■The clock is displayed when
The engine switch is in ACC or IG-ON mode.
Adjusts the hour.
Adjusts the minutes.
Rounds to the nearest hour.
*
*: e.g. 1:00 to 1:29  1:00
1:30 to 1:59  2:00

273
4-3. Do-it-yourself maintenance
4
Maintenance and care
■Adding engine oil
If the oil level is below or near the
low level mark, add engine oil of
the same type as already in the
engine.
Make sure to check the oil type and prepare the items needed before
adding oil.
Remove the oil filler cap.
Add engine oil slowly, checking the dipstick.
Install the filler cap, turning it clockwise.
It takes about 1.6 qt. (1.5 L, 1.3 lmp. qt.) to raise the oil level from low to full on the
dipstick.
Oil gradeILSAC multi-grade engine oil
ItemsClean funnel
STEP1
STEP2
STEP3

315
4-3. Do-it-yourself maintenance
4
Maintenance and care
■Passenger’s side instrument panel
FuseAmpereCircuit
1FR P/SEAT RH30APo w e r s e a t
2DOOR DL15A
3OBD7. 5 AOn-board diagnosis system
4STOP SW7. 5 AStop lights
5TI & TE20AElectric tilt and telescopic steering
column
6RAD NO.310AAudio
7GAUGE7. 5 AMeter
8IGN10ASRS airbag system, cruise control,
steering lock system, fuel system
9ACC7. 5 A
Lexus link system, clock, air condition-
ing system, audio, display, outside rear
view mirrors, smart access system
with push-button start
10CIG15ACigarette lighter
11PWR OUTLET15APo w e r o u t l e t
12RR DOOR RH20APo w e r w i n d o w s

320
4-3. Do-it-yourself maintenance
Replacing light bulbs
■Headlight high beams
Release the lock and remove the
cover.
Turn the bulb base counterclock-
wise.
Unplug the connector while
depressing the lock release.
STEP1
STEP2
STEP3

321
4-3. Do-it-yourself maintenance
4
Maintenance and care
■Parking lights
Release the lock and remove the
cover.
Turn the bulb base counterclock-
wise.
Remove the light bulb.
■Back-up light
Open the trunk door and remove
the trunk panel cover clips.
STEP1
STEP2
STEP3
STEP1
