Page 197 of 284
4
CORROSION PREVENTION AND APPEARANCE CARE
21
4
IN CASE OF EMERGENCY
21BLEEDING THE FUEL SYSTEM
CAUTION:
If overheating should occur when towing, (temperature gauge reads near red zone), taking the followingaction may reduce or eliminate the problem.
1. Turn off the air conditioner.
2. Reduce highway speed.
3. Select a lower gear when going uphill.
4. While in stop and go traffic, place
the gear selection in park or neu-tral and idle the engine at a higher speed.
! E090A01P-GAT (Diesel Motor) The fuel system should be bled to remove air as described in the illustra- tion if the fuel supply is exhaustedduring travel, when the fuel filter is replaced, or if the vehicle is not used for a long time.
1. Loosen the air plug at the top of the
fuel filter. E090A01P
13.Avoid holding the brake pedal down
too long or too frequently. This could cause the brakes to overheat, re- sulting in reduced braking efficiency.
14.When going down a hill, shift into a
lower gear and use the engine brak-ing effect. When ascending a long grade, downshift the transmissionto a lower gear and reduce speed to reduce chances of engine over- loading and/or overheating.
15.If you have to stop while going uphill, do not hold the vehicle inplace by pressing on the accelera-tor. This can cause the automatic transmission to overheat. Use the parking brake or footbrake.
NOTE: When towing, check transmission fluid more frequently.
Page 198 of 284
44IN CASE OF EMERGENCY
22
2. Pump the hand pump until there are
no more bubbles in the fuel coming out of the air plug. When doing this,place a cloth around the air plug to prevent the escaping fuel from spew- ing about.
3. Tighten the air plug when there are no more bubbles in the fuel.
4. Continue pumping until the hand pump becomes stiff.
5. Finally, check to be sure that there
is no leakage of fuel.If in doubt, consult your nearest authorized HYUNDAI dealer. E090A02P
REMOVAL OF WATER FROM THE FUEL FILTER
E100A02P-GAT (Diesel Motor) If the fuel filter warning lamp illumi- nates during driving, it indicates that water has accumulated in the fuel fil-ter. If this occurs, remove the water as described below.
1. Loosen the drain plug at the bottom
of the fuel filter. Drain plug
!WARNING:
o Do not smoke or have any other open flame near the vehicle while bleeding the fuel system.
o Be sure to carefully clean away
any fuel which spilled ontonearby parts coming out of the air plug, because such accumu- lations of fuel might ignite andcause a fire.
GS40310A
Page 199 of 284
4
CORROSION PREVENTION AND APPEARANCE CARE
23
4
IN CASE OF EMERGENCY
23IF THE ENGINE WILL NOT START
!WARNING:
o Do not smoke or have any other open flame near the vehicle while bleeding the fuel system.
o Be sure to carefully wipe away
any water drained out in thismanner, because the fuel mixed in the water might be ignited and result in a fire.
NOTE: It is recommended that water accu- mulated in the fuel filter should be removed by an authorized Hyundaidealer.
!
D010A01A-AAT
WARNING:
If the engine will not start, do not push or pull the car to start it. This could result in a collision or causeother damage. In addition, push or pull starting may cause the cata- lytic converter to be overloaded andcreate a fire hazard.
2. Operate the hand pump slowly 6 or 7 times in order to force the waterout through the drain plug.
3. Tighten the drain plug when water no longer comes out.
4. Loosen the air plug and bleed the air. (Refer to "Bleeding the fuel sys- tem".)
5. Check to be sure that the warning lamp illuminates when the ignitionkey is turned to "ON", and that itgoes off when the engine is started. If in doubt, consult your nearest authorized HYUNDAI dealer. Pump
GS40320A
Page 278 of 284
10INDEX
2
A ADJUSTABLE FRONT SEATS .................................. 1-32
AIR CONDITIONING CARE .......................................8-15
AIR CONDITI ONING SYSTEM .................................. 2-44
ALTIMETER ............................................................... 2-18
ANTENNA .................................................................. 2-73
ANTI-LOCK BRAKE SYSTEM ................................... 3-24
APPEARANCE CARE ................................................. 5-2
ASHTRAY .................................................................. 2-36
AUDIO FAULT CODE ................................................. 2-70
AUDIO SYSTEM Cassette Tape Player Operation (H240, H280)...................................................................... 2-54, 2-65
Compact Disc Player Operation (H260, H280) ...................................................................... 2-59, 2-67
Stereo Radio Operation (H240, H260, H280)
............................................................ 2-51, 2-56, 2-62
AUTOMATIC TRANSMISSION ..................................3-10
AUTOMATIC TRANSMISSION FLUID .......................8-18
AUXILIARY SEAT ...................................................... 1-38BBATTERY
................................................................... 8-13
BEFORE STARTING THE ENGINE ............................ 3-3
BI-LEVEL HEATING ................................................... 2-42
BLEEDING THE FUEL SYSTEM ............................. 4-21
BRAKE FLUID ............................................................ 8-17
BRAKE PEDAL .......................................................... 3-22
BRAKE SYSTEM ....................................................... 3-20
BULB WATTAGE ....................................................... 4-38
CCARE OF CASSETTE TAPES .................................. 2-72
CARE OF DI SC .......................................................... 2-71
CARRYING CHILDREN .............................................. 1-16
CATALYTIC CONVERTER ....... ................................... 7-3
CENTRAL DOOR LOCKS ..... .....................................1-15
CHANGING A FLAT TIRE ........................................... 4-7
CHANGING AND REPLACING FUSES .....................4-27
CHANGING THE CLIMATE CONTROL AIR FILTER . 8-16
CHECKING THE DRIVE BELTS ................................ 8-24
CHECKING THE FREEPLAY .....................................8-23
CHILD PROTECTION SLIDE DOOR ..........................1-16
CHILD RESTRAINT SYSTEM .................................... 1-46
CIGARETTE LIGHTER ............................................... 2-27
CLIMATE CONTROL AIR FILTER ............................. 2-47
CLUTCH FLUID .......................................................... 8-18
