Driver’s Side Temperature Knob
The driver’s side knob is used to adjust the
temperature of the air coming through the system
on the driver’s side. The temperature can be
adjusted even if the system is turned off. This is
possible since outside air will always ow through
the system as the vehicle is moving forward
unless it is set to recirculation mode. See
“Recirculation” later in this section.
Turn the knob counterclockwise or clockwise to
lower or increase the cabin temperature. The
display will show the temperature setting
decreasing or increasing and an arrow pointing to
the driver will be displayed under and to the
left of the temperature setting.
Passenger’s Side Temperature Knob
The passenger’s side knob can be used to change
the temperature of the air coming through the
system on the passenger’s side of the vehicle. The
temperature can be adjusted even if the system
is turned off. This is possible since outside air will
always ow through the system as the vehicle
is moving forward unless it is set to recirculation
mode. See “Recirculation” later in this section.
Turn the knob counterclockwise or clockwise
to lower or increase the cabin temperature. The
display will show the temperature setting
decreasing or increasing and an arrow pointing to
the passenger will be displayed under and to
the right of the temperature setting.
The passenger’s temperature setting can be set to
match the driver’s temperature setting by pressing
and holding the AUTO button for four seconds. Both
the driver and passenger arrows will be displayed.
198

Cassette Tape Messages
CHK TAPE (Check Tape):If this message
appears on the display, the tape does not play
due to one of the following errors:
The tape is tight and the player cannot turn
the tape hubs. Remove the tape. Hold the
tape with the open end down and try to turn
the right hub counterclockwise with a
pencil. Turn the tape over and repeat. If the
hubs do not turn easily, the tape could
be damaged and should not be used in the
player. Try a new tape to make sure your
player is working properly.
The tape is broken. Try a new tape.
The tape is wrapped around the tape head.
Attempt to get the cassette out. Try a new tape.
CLEAN:If this message displays, the cassette
tape player needs to be cleaned. It still plays tapes,
but it should be cleaned as soon as possible to
prevent damage to the tapes and player. SeeCare
of the Cassette Tape Player on page 297.
If the cassette tape is not playing correctly, for any
other reason, try a known good cassette.If any error occurs repeatedly or if an error cannot
be corrected, contact your dealer. If the radio
displays an error message, write it down and
provide it to your dealer when reporting the
problem.
CD Adapter Kits
It is possible to use a portable CD player with the
cassette tape player after activating the bypass
feature on your tape player.
To activate the bypass feature, perform the
following steps:
1. Turn the ignition on.
2. Turn the radio off.
3. Press and hold the TAPE DISC button for
ve seconds. READY displays and the tape
symbol on the display ashes, indicating
the feature is active.
4. Insert the adapter into the cassette tape slot.
It powers up the radio and begins playing.
The override feature remains active until the eject
button is pressed.
252

XM™ Satellite Radio Service
XM™ is a satellite radio service that is based in
the 48 contiguous United States and Canada.
XM™ offers a large variety of coast-to-coast
channels including music, news, sports, talk,
traffic/weather (U.S. subscribers), and children’s
programming. XM™ provides digital quality
audio and text information that includes song title
and artist name. A service fee is required in
order to receive the XM™ service. For more
information, contact XM™; In the U.S. at
www.xmradio.com or call 1-800-852-XMXM (9696)
or in Canada at www.xmradio.ca or call
1-877-GET-XMSR (438-9677).
Playing the Radio
PWR (Power):Push this knob to turn the system
on and off.
VOLUME:Turn this knob clockwise or
counterclockwise to increase or to decrease
the volume.
INFO (Information):When the ignition is off,
press this knob to display the time.For RDS, press the INFO knob to change what
displays while using RDS. The display options are
station name, RDS station frequency, PTY
(program type), and the name of the program
(if available).
For XM™ (if equipped), press the INFO knob
while in XM™ mode to retrieve four different
categories of information related to the current
song or channel: Artist, Song Title, Category
or PTY, Channel Number/Channel Name.
To change the default on the display, press the
INFO knob until the desired option displays,
then hold the knob until a beep sounds. The
selected display becomes the default.
AUTO VOL (Automatic Volume):With automatic
volume, the audio system adjusts automatically
to make up for road and wind noise as you drive
by increasing the volume as vehicle speed
increases.
Set the volume at the desired level. Press this
button to select MIN (minimum), MED (medium), or
MAX (maximum). AUTO VOL displays. Each higher
setting provides more volume compensation at
faster vehicle speeds. To turn automatic volume off,
press this button until AUTO VOL OFF displays.
257

3. Pull off the license plate holder from the
spare tire.
4. Attach the wheel wrench to the wheel wrench
extender to remove the wheel nuts. Turn the
wheel wrench with the wheel wrench
extender counterclockwise to loosen the
wheel nuts.5. Remove the three wheel nuts holding the
spare tire onto the tire carrier.
6. Pull off the spare tire and gently lower it to the
ground. Set it next to the at tire.
473

Release the jack by inserting the wheel wrench (A)
into the hole (B) and turn counterclockwise.
Before proceeding, be sure to set the wheel blocks
at the appropriate tires as previously shown.
Remove the wheel
blocks from the tool
bag. Then lift the wheel
block as shown to
lock it into place.
Removing the Spare Tire (SUT)
The spare tire is attached to the tire carrier.
To remove the spare tire, do the following:
1. Open the tire carrier. SeeTailgate/Spare Tire
Carrier on page 108for tire carrier operation.
2. Unscrew the wing nut on the back of the
tire carrier.
476

3. Pull off the license plate holder from the
spare tire.
4. Attach the wheel wrench to the wheel wrench
extender to remove the wheel nuts.
5. Turn the wheel wrench with the wheel wrench
extender counterclockwise to loosen the
wheel nuts.6. Remove the three wheel nuts holding the
spare tire onto the tire carrier.
7. Pull off the spare tire and gently lower to the
ground. Set it next to the at tire.
477
