2007 HUMMER H2 Owners Manual

Other Warning Devices
If you carry reective triangles, you can set them up
at the side of the road about 300 feet (100 m)
behind your vehicle.
Horn
Press on or near the horn symbols on the steering
wheel pad to sound the horn.
Tilt Wheel
The tilt steering wheel allows you to adjust the
steering wheel before you drive. You can raise it to
the highest level to give your legs more room
when you enter and exit the vehicle.The tilt lever is located on the driver’s side of the
steering column under the turn signal lever.
To tilt the wheel, hold the steering wheel and pull
the lever. Move the steering wheel to a
comfortable level, then release the lever to lock
the wheel in place.
177

Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes the following:
GTurn and Lane Change Signals.Turn and
Lane-Change Signals on page 178.
53Headlamp High/Low-Beam Changer.
Headlamp High/Low-Beam Changer on
page 179.
Flash-to-Pass Feature. SeeFlash-to-Pass on
page 180.
NWindshield Wipers. SeeWindshield
Wipers on page 180.
LWindshield Washer. SeeWindshield
Washer on page 181.
ICruise Control.Cruise Control on
page 183.
For information on the exterior lamps, seeExterior
Lamps on page 186later in this section.
Turn and Lane-Change Signals
The turn signal has two upward (for right) and
two downward (for left) positions. These positions
allow you to signal a turn or a lane change.
To signal a turn, move the lever all the way up or
down. When the turn is nished, the lever will
return automatically.
To signal a lane change, raise or lower the lever for
less than one second until the arrow starts to ash.
This will cause the turn signals to automatically
ash three times. It will ash six times if the
tow-haul mode is active. Holding the turn signal
lever for more than one second will cause the turn
signals to ash until you release the lever. The lever
will return by itself when it is released.
178

An arrow on the
instrument panel
cluster will ash in the
direction of the turn
or lane change.
As you signal a turn or a lane change, if the
arrows ash more quickly than normal, a signal
bulb may be burned out and other drivers will not
see your turn signal.
If a bulb is burned out, replace it to help avoid an
accident. If the arrows do not go on at all when you
signal a turn, check for burned-out bulbs and a
blown fuse. SeeInstrument Panel Fuse Block on
page 504andUnderhood Fuse Block on page 507.Turn Signal On Chime
If your turn signal is left on for more than 3/4 of a
mile (1.2 km), a chime will sound at each ash
of the turn signal and the message TURN SIGNAL
ON will also appear in the DIC. SeeDIC
Warnings and Messages on page 226. To turn the
chime and message off, move the turn signal
lever to the off position.
Headlamp High/Low-Beam Changer
53(Headlamp High/Low Beam Changer):
To change the headlamps from low to high beam,
push the lever toward the instrument panel. To
return to low-beam headlamps, pull the
multifunction lever toward you. Then release it.
When the high beams
are on, this indicator light
on the instrument panel
cluster will also be on.
179

Flash-to-Pass
This feature lets you use your high-beam
headlamps to signal a driver in front of you that
you want to pass. It works even if your headlamps
are in the automatic position.
To use it, pull the turn signal lever toward you,
then release it.
If your headlamps are in the automatic position or
on low beam, your high-beam headlamps will
turn on. They will stay on as long as you hold the
lever toward you. The high-beam indicator on
the instrument panel cluster will come on. Release
the lever to return to normal operation.
Windshield Wipers
You control the windshield wipers by turning the
band with the wiper symbol on it.
8(Mist):For a single wiping cycle, turn the
band to mist. Hold it there until the wipers
start. Then let go. The wipers will stop after
one wipe. If you want more wipes, hold the
band on mist longer.
6(Delay):You can set the wiper speed for a long
or short delay between wipes. This can be very
useful in light rain or snow. Turn the band to
choose the delay time. The closer to the top of the
lever, the shorter the delay.
6(Low Speed):For steady wiping at low
speed, turn the band away from you to the
rst solid band past the delay settings.
1(High Speed):For high-speed wiping, turn
the band further, to the second solid band past the
delay settings.
9(Off):To stop the wipers, move the band
to off.
Be sure to clear ice and snow from the wiper
blades before using them. If they are frozen to the
windshield, carefully loosen or thaw them. If
your blades do become worn or damaged, get
new blades or blade inserts.
180

Windshield Washer
{CAUTION:
In freezing weather, do not use your
washer until the windshield is warmed.
Otherwise the washer uid can form ice
on the windshield, blocking your vision.
LQ(Washer Fluid):There is a paddle marked
with the windshield washer symbol at the top of
the multifunction lever. Push the paddle to
spray washer uid on the windshield. The wipers
will clear the window and then either stop or
return to the preset speed.
_(Heated Washer Fluid):If your vehicle has
the heated windshield washer uid system, it
is used to help clear ice, snow, tree sap, or bugs
from your windshield.To activate Automatic mode for de-icing, press the
heated washer button located above the
headlamp switch on the left side of the dash.
Pushing the heated washer uid button will
activate the heated windshield washer uid
system. This activation will initiate four heated
wash/wipe cycles. The rst heated wash/wipe
cycle may take up to 40 seconds to occur,
depending on outside temperature. After the rst
wash/wipe cycle, it may take up to 20 seconds
for each of the remaining cycles. The heated
windshield washer uid system may be turned off
at any time by pushing the button again prior
to the completion of 4 wash/wipe cycles.
When the heated windshield washer uid system
is activated under certain outside temperature
conditions, steam may ow out of the washer
nozzles for a short period of time before washer
uid is sprayed. This is a normal condition.
A message will be displayed on the Driver
Information Center (DIC) when the washer uid is
low. SeeDIC Warnings and Messages on
page 226.
181

Rear Window Wiper/Washer (SUV)
If your vehicle has a
rear window
washer/wiper, the
control knob is located
on the instrument
panel to the left of the
steering wheel.
{CAUTION:
In freezing weather, do not use your
washer until the windshield is warmed.
Otherwise the washer uid can form ice
on the windshield, blocking your vision.To turn the rear wiper on, turn the knob to either
1 or 2. For long delayed wiping, turn the knob to 1.
For short delayed wiping, turn the knob to 2.
9(Off):To turn the wiper off, turn the knob to
this symbol.
=(Washer Fluid):To wash the window, press
the knob with this symbol.
The rear window washer uses the same uid
reservoir as the windshield washer. However, the
rear window washer will run out of uid before
the windshield washer. If you can wash your
windshield but not your rear windows, check the
uid level.
182

Cruise Control
9(Off):This position
turns the system off.
R(On):This position activates the system.
+ (Resume/Accelerate):Push the lever to this
symbol to make the vehicle accelerate or resume
to a previously set speed.
T(Set):Press this button to set the speed.
With cruise control, you can maintain a speed of
about 25 mph (40 km/h) or more without
keeping your foot on the accelerator. This can
really help on long trips. Cruise control does not
work at speeds below about 25 mph (40 km/h).If you apply your brakes, the cruise control will
shut off.
{CAUTION:
Cruise control can be dangerous where
you cannot drive safely at a steady speed.
So, do not use your cruise control on
winding roads or in heavy traffic.
Cruise control can be dangerous on
slippery roads. On such roads, fast
changes in tire traction can cause
excessive wheel slip, and you could lose
control. Do not use cruise control on
slippery roads.
183

Setting Cruise Control
{CAUTION:
If you leave your cruise control on when
you are not using cruise, you might hit a
button and go into cruise when you do not
want to. You could be startled and even
lose control. Keep the cruise control switch
off until you want to use cruise control.
1. Move the cruise control switch to on.
2. Get up to the speed you want.
3. Press in the set button at the end of the lever
and release it.
4. Take your foot off the accelerator pedal.
The cruise symbol on
the instrument panel will
illuminate when the
cruise control is
engaged.
Resuming a Set Speed
Suppose you set your cruise control at a desired
speed and then you apply the brake. This, of
course, disengages the cruise control. But
you don’t need to reset it.
Once you’re going about 25 mph (40 km/h) or
more, you can move the cruise control switch
briey from on to resume/accelerate.
You’ll go right back up to your chosen speed and
stay there.
If you hold the switch at resume/accelerate the
vehicle will keep going faster until you release the
switch or apply the brake. So unless you want
to go faster, don’t hold the switch at
resume/accelerate.
184
