In addition to proper inf lation,
correct wheel alignment helps to
decrease tire wear. If you f ind a tire
is worn unevenly, have your dealer
check the wheel alignment.
Have your dealer check the tires if
you f eel a consistent vibration while
driving. A tire should always be
rebalanced if it is removed f rom the
wheel. When you have new tires
installed, make sure they are
balanced. This increases riding
comf ort and tire lif e. For best results,
have the installer perform a dynamic
balance.
Your tires have wear indicators
molded into the tread. When the
tread wears down, you will see a
band 1/2 inch (12.7 mm) wide band
across the tread. This shows there is
less than 1/16 inch (1.6 mm) of tread
lef t on the tire.
A tire this worn gives very little
traction on wet roads. You should
replace the tire if you can see three
or more tread wear indicators. To help increase tire lif e and
distribute wear more evenly, rotate
the tires according to the
maintenance messages displayed on
the information display. Move the
tires to the positions shown in the
diagram each time they are rotated.
If you purchase directional tires,
rotate only front-to-back.
T ire Maintenance T ire Rotation
Tires
Maint enance
267
Front
(For Non-directional
Tires and Wheels) Front
(For Directional
Tires and Wheels)
TREAD WEAR INDICATORS INDICATOR LOCATION MARKS
On vehicles with aluminum wheels,
improper wheel weights can damage
your vehicle’s wheels. Use only Honda
wheel weights f or balancing.

The vehicle’s fuses are contained in
threefuseboxes. The
primary under-hood fuse box is
on the passenger’s side. The
secondary fuse box is next to the
brake fluid reservoir. To open them,
pushthetabsasshown.
The
interior fuse box is on the
driver’s lower left side. To remove
the fuse box lid, put your finger in
the notch on the lid, and pull it
outward slightly, then pull it toward
you and take it out of its hinges. If
something electrical in your
vehicle stops working, check for a
blown f use f irst. Determine f rom the
chart on pages and , or the
diagram on the f use box lid, which
f use or f uses control that device.
Check those f uses f irst, but check all
the f uses bef ore deciding that a
blown f use is the cause. Replace any
blown f uses, and check if the device
works. 294 295
CONT INUED
Checking and Replacing Fuses
Fuses
T aking Care of t he Unexpect ed
291
UNDER-HOOD (SECONDARY)
UNDER-HOOD (PRIMARY)
INTERIOR
NOTCH

Thediagramsinthissectiongive
you the dimensions and capacities of
your vehicle and the locations of the
identif ication numbers. It also
includes inf ormation you should
know about your vehicle’s tires and
