2007 HONDA ACCORD SEDAN service indicator

2007 Accord Sedan Online Reference Owner's Manual
Use these links (and links throughout this manual) to navigate through\
this reference.
For a printed owner's manual, click on authorized manuals or go to www.h\
elminc.com.
Contents

Owner's Identification Form
Introduction ........................................................................\
................................................................. i
A Few Words About Safe ty........................................................................\
........................................iii
Your Vehicle at a Glance ....................................................................................................................
Driver and Passenger Safety ........................................................................\
..................................... .7
Proper use and care of your vehicle's seat belts, and Supplemental Restr\
aint System.
Instruments and Control s........................................................................\
........................................ .55
Instrume nt panel indicator and gauge, and how to use dashboard and steering colu\
mn controls.
Comfort and Convenience Features ........................................................................\
..................... .101
How to operate the climate control system, the audio system, and other c\
onvenience features.
Before Driving........................................................................\
..........................................................153
What gasoline to use, how to break -in your new vehicle, and how to load luggage and other cargo.
Driving ........................................................................\
..................................................................... .167
The proper way to start the engine, shift the transmission, and park, pl\
us towing a trailer.
Maintenance........................................................................\
.............................................................191
The Maintenance Schedule shows you when you need to take you r vehicle to the dealer.
Taking Care of the Unexpected ...................................................................................................... 239
This section covers several problems motorists sometimes experience, an d how to handle them.
Technical Informatio n........................................................................\
............................................ .265
ID numbers, dimensions, capacities, and technical information.
Warranty and Customer Relations (U.S. and Canad a)................................................................279
A summary of the warranties covering your new Acura, and how to contact \
us.
Authorized Manu als (U.S. only)........................................................................\
..............................283
How to order manuals and other technical literature.
Index........................................................................\
........................................................................\
...... I
Service Information Summary
A summary of information you need when you pull up to the fuel pump.

Accord Value Package Audio System iv

This section gives you important
inf ormation about how to protect
yourself and your passengers. It
shows you how to use seat belts. It
explains how your airbags work. And
it tells you how to properly restrain
inf ants and children in your vehicle..........
Important Safety Precautions . 8
.......
Your Vehicle’s Saf ety Features . 9
.....................................
Seat Belts .10
.........................................
Airbags .11
.........
Protecting Adults and Teens . 13
.....
1. Close and Lock the Doors . 13
...........
2. Adjust the Front Seats . 13
............
3. Adjust the Seat-Backs . 14
...
4. Adjust the Head Restraints . 15
5. Fasten and Position the Seat .....................................
Belts .16
6. Maintain a Proper Sitting ................................
Position .17
.....
Advice f or Pregnant Women . 18
...
Additional Safety Precautions . 19Additional Inf ormation About Your
.................................
Seat Belts .20
..
Seat Belt System Components . 20
......................
Lap/Shoulder Belt .21
Automatic Seat Belt ...............................
Tensioners .21
...............
Seat Belt Maintenance . 22
Additional Inf ormation About Your .....................................
Airbags .23
......
Airbag System Components . 23
How Your Front Airbags .........................................
Work .25
...
How Your Side Airbags Work . 28
How Your Side Curtain Airbags .........................................
Work .30
..
How the SRS Indicator Works . 30
How the Side Airbag Of f ......................
Indicator Works .31
How the Passenger Airbag Of f ......................
Indicator Works .31
.............................
Airbag Service .32
...
Additional Safety Precautions . 33
Protecting Children General ................................
Guidelines .34
All Children Must Be ...............................
Restrained .34 All Children Should Sit in a
.................................
Back Seat .35
The Passenger’s Front Airbag ................
Poses Serious Risks . 35
If You Must Drive with Several ...................................
Children .37
If a Child Requires Close ..................................
Attention .37
...
Additional Safety Precautions . 38
Protecting Inf ants and .........................
Small Children .39
.......................
Protecting Inf ants .39
.........
Protecting Small Children . 41
.....................
Selecting a Child Seat .42
....................
Installing a Child Seat .43
...............................
With LATCH .44
...................................
With a Belt .46
..............................
With a Tether .48
...........
Protecting Larger Children . 49
..................
Using a Booster Seat . 50
When Can a Larger Child Sit in .........................................
Front .51
...
Additional Safety Precautions . 52
.............
Carbon Monoxide Hazard . 53
...................................
Saf ety Labels .54
Driver and Passenger Saf ety
Driver and Passenger Saf ety
7
µ

Be aware that objects placed on the
f ront seat can cause the indicator to
come on.
If no weight is detected on the f ront
seat, the airbag will be automatically
shut of f . However, the indicator will
not come on.
The passenger airbag of f indicator
maycomeonandoff repeatedlyif
the total weight on the seat is near
the airbag cutof f threshold.
If an adult or teenage passenger is
riding in f ront, move the seat as f ar
to the rear as possible, and have the
passenger sit upright and wear the
seat belt properly.Your airbag systems are virtually
maintenance f ree, and there are no
parts you can saf ely service.
However, you must have your
vehicle serviced if:
Any airbag
that has deployed must be
replaced along with the control
unit and other related parts. If a
f ront airbag inf lates, the seat belt
tensioners must also be replaced.
Do not try to remove or replace
anyairbagbyyourself.Thismust
be done by an authorized dealer or
a knowledgeable body shop.
If the indicator comes on with no
f ront seat passenger and no objects
on the seat, or with an adult riding
there, something may be interf ering
with the weight sensors. Look f or
and remove:
Any items under the f ront
passenger’s seat.
Any object hanging on the seat or
in the seat-back pocket.
Any object, such as a f olded-down
back seat, that is touching the rear
of the seat-back.
If no obstructions are f ound, have
your vehicle checked by a dealer as
soon as possible.
Additional Inf ormation About Your Airbags
Airbag Service
An airbag ever inf lates.
32

This indicator comes on for a few
seconds when you turn the ignition
switch to the ON (II) position. It will
gooffifyouhaveinserteda
properly-coded ignition key. If it is
not a properly-coded key, the
indicator will blink and the engine
will not start (see page ).
This indicator also blinks several
times when you turn the ignition
switch from the ON (II) position to
the ACCESSORY (I) or LOCK (0)
position.
This indicator comes on when the
washer fluid level is low. Add washer
fluidwhenyouseethisindicator
come on (see page ).
This
indicator comes on when you
turn on the cruise control master
button (see page ).
This indicator comes on when you
set the cruise control. See page
for information on operating the
cruise control. This
indicator comes on for a few
seconds when you turn the ignition
switch to the ON (II) position. It
remindsyouthatitistimetotake
your vehicle in for scheduled
maintenance. The maintenance main
items and sub items will be displayed
in the information display. See page
f or more inf ormation on the
maintenance minder.
This indicator goes of f when your
dealer resets it after completing the
required maintenance service. 75
145 193
145
210
Canadian models only
Immobilizer System
Indicator
Cruise Control Main
Indicator Maintenance Minder
Indicator
Washer Level Indicator
Cruise Control Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
63

This shows how much fuel you have.
It may show slightly more or less
th an the actual amount. The needle
returns to the bottom after you turn
off the ignition. The
information display in the
instrument panel shows you the
engine oil life and maintenance
service items when the ignition
switch is in the ON (II) position. This
information helps to keep you aware
of the periodic maintenance your
vehicle needs for continued trouble-
free driving. Refer to page for
more information.
If
your fuel cap is loose or missing, a
‘‘CHECK FUEL CAP’’ message will
appear in the information display. As
soon as it is safely possible, turn the
engine off and check that the fuel
cap is installed. If it is, loosen the cap
and tighten it to at least 1 click.
Al though you can use the select/
resetknobtocyclethefuelcap
warningo ffofthedisplay,itwillbe
displayedagai neachtimetheengine
isstarted.Itwillta keseveraldaysof
normaldrivingforthevehicletotu rn
thewarningoff.
Ifthevehicleonboarddiagnostic
systemcontinue stodetecta
problem,the mal function indicator
lamp(MIL)willilluminate.Ifthe
MILdoesnotgo off, have your
de aler inspect the vehicle. For more
info rmation, see page . 193
254
Fuel Gauge
Check Fuel Cap IndicatorMaintenance Minder Display
Gauges
66
Avoid driving with an extremely low
f uel level. Running out of f uel could
cause the engine to misf ire, damaging
the catalytic converter.

Help assure your vehicle’s f uture
reliability and perf ormance by paying
extra attention to how you drive
during the f irst 600 miles (1,000 km).
During this period:Avoid full-throttle starts and rapid
acceleration.
Do not change the oil until the
scheduled maintenance time.
Avoidhardbrakingforthefirst
200 miles (300 km).
Do not tow a trailer.
You should also f ollow these
recommendations with an
overhauled or exchanged engine, or
when the brakes are replaced. In addition, in order to maintain good
perf ormance, f uel economy, and
emissions control, we strongly
recommend, in areas where it is
available, the use of gasoline that
does NOT contain manganese-based
f uel additives such as MMT.
You may hear a knocking noise from
the engine if you drive the vehicle at
low engine speed (below about 1,000
rpm) in a higher gear. To stop this,
raise the engine speed by shif ting to
a lower gear. Your vehicle is designed to operate
on unleaded gasoline with a pump
octane number of 87 or higher. Use
of a lower octane gasoline can cause
a persistent, heavy, metallic rapping
noise that can lead to engine damage. We recommend using quality
gasolines containing detergent
additives that help prevent fuel
system and engine deposits.
Use of gasoline with these additives
may adversely af f ect perf ormance,
and cause the malfunction indicator
lamp on your instrument panel to
come on. If this happens, contact
your dealer f or service.
For vehicles with manual transmission
Break-in Period, Fuel Recommendation
Break-in Period
Fuel Recommendation
154

To Open the Hood:
Park the vehicle, and set the
parking brake. Pull the hood
release handle located under the
lower left corner of the dashboard.
The hood will pop up slightly. Put
your fingers under the front
edge of the hood near the center.
Slide your hand to the left until
you feel the hood latch handle.
Push this handle up to release it.
Li ft up the hood.
If the hood latch handle moves stiffly,
or if you can open the hood without
lifting the handle, the mechanism
should be cleaned and lubricated.
Push
the fuel fill door closed until
it latches.
Screw
the fuel fill cap back on
until it clicks at least once. If you
do not properly tighten the cap,
the malf unction indicator lamp
maycomeon(seepage ).You
will also see a ‘‘CHECK FUEL
CAP’’ message on the inf ormation
display.
1. 2.
5.
6.
254
CONT INUED
Opening and Closing the Hood
Bef ore Driving
157
HOOD RELEASE HANDLE
LATCH
Service Station Procedures

CONTINUED
Your vehicle displays engine oil life
and maintenance service items on
the information display to show you
when you should have your dealer do
engine oil replacement and indicated
maintenance service.
Based on the engine operating
conditions and accumulated engine
revolutions, the onboard computer in
your vehicle calculates the remaining
engine oil life and displays it as a
percentage.
To see the current engine oil life,
turn the ignition switch to the ON
(II) position, and push and release
th e select/reset knob repeatedly
until the engine oil lif e display
appears (see page ). The remaining engine oil lif e is
shownonthedisplayaccordingto
this table:
64
Maintenance Minder
Engine Oil L if e Indicator
Maint enance
193
SELECT/RESET KNOB
ENGINE OIL LIFE INDICATOR
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ µ
µ
Calculated Engine
Oil Lif e (%)
100 % 91 % 90 % 81 %
80 % 71 %
70 % 61 %
60 % 51 %
50 % 41 %
40 % 31 %
30 % 21 %
20 % 16 %
15 % 11 %10 % 6 % 5% 1% 0% Displayed
Engine Oil Lif e (%) 100 %90 %
80 %
70 %
60 %
50 %
40 %
30 %
20 %
15 %
10 %5%
0%
