2007 GMC YUKON XL DENALI fuses

Fuses Usage
AUX PWR2 Rear Cargo Area Power Outlets
SWC BKLT Steering Wheel Controls Backlight
DDM Driver Door Module
CTSYDome Lamps, Driver’s Side
Turn Signal
LT STOP TRN Driver’s Side Turn Signal, Stoplamp
DIM Instrument Panel Back Lighting
RT STOP TRNPassenger’s Side Turn Signal,
Stoplamp
BCM Body Control Module
UNLCK2 Power Door Lock 2 (Unlock Feature)
LCK2 Power Door Lock 2 (Lock Feature)
STOP LAMPSStoplamps, Center-High Mounted
Stoplamp
REAR HVAC Rear Climate Controls
PDMPassenger Door Module, Universal
Home Remote SystemFuses Usage
AUX PWR Accessory Power Outlets
IS LPS Interior Lamps
UNLCK1 Power Door Lock 1 (Unlock Feature)
OBS DETUltrasonic Rear Parking Assist,
Power Liftgate
LCK1 Power Door Lock 1 (Lock Feature)
REAR WPR Rear Wiper
COOLED
SEATSNot Used
DSMDriver Seat Module, Remote
Keyless Entry System
Harness
Connector Usage
LT DR Driver’s Door Harness Connection
BODY Harness Connector
BODY Harness Connector
539

Underhood Fuse BlockThe underhood fuse block is located in the engine
compartment, on the driver’s side of the vehicle.
Lift the cover for access to the fuse/relay block.
To remove fuses, hold the end of the fuse between
your thumb and index nger and pull straight out.
541

Fuses Usage
1 Not Used
2Electronic Stability Suspension
Control, Automatic Level Control
Exhaust
3 Left Trailer Stop/Turn Lamp
4 Engine Controls
5Engine Control Module,
Throttle Control
6 Right Trailer Stop/Turn Lamp
7 Front Washer
8 Oxygen Sensors
9 Anti-lock Brakes System 2
10 Trailer Back-up Lamps
11 Driver’s Side Low-Beam Headlamp
12 Engine Control Module (Battery)
13Fuel Injectors, Ignition Coils
(Right Side)
14Transmission Control Module
(Battery)
15 Vehicle Back-up LampsFuses Usage
16Passenger’s Side Low-Beam
Headlamp
17 Air Conditioning Compressor
18 Oxygen Sensors
19 Transmission Controls (Ignition)
20 Fuel Pump
21 Not Used
22 Rear Washer
23Fuel Injectors, Ignition Coils
(Left Side)
24 Trailer Park Lamps
25 Driver’s Side Park Lamps
26 Passenger’s Side Park Lamps
27 Fog Lamps
28 Horn
29Passenger’s Side High-Beam
Headlamp
30 Daytime Running Lamps
31 Driver’s Side High-Beam Headlamp
543

Fuses Usage
32 Daytime Running Lamps 2
33 Sunroof
34Key Ignition System, Theft
Deterrent System
35 Windshield Wiper
36 SEO B2 Uptter Usage (Battery)
37 Electric Adjustable Pedals
38 Climate Controls (Battery)
39 Airbag System (Ignition)
40 Amplier
41 Audio System
42 Four-Wheel Drive
43Miscellaneous (Ignition),
Rear Vision Camera (If Equipped),
Cruise Control
44 Liftgate ReleaseFuses Usage
45OnStar
®, Rear Seat
Entertainment Display
46 Instrument Panel Cluster
47 Not Used
48 Heated Steering Wheel
49Auxiliary Climate Control (Ignition),
Compass-Temperature Mirror
50 Rear Defogger
51 Airbag System (Battery)
52 SEO B1 Uptter Usage (Battery)
53Cigarette Lighter, Auxiliary
Power Outlet
54Automatic Level Control Compressor
Relay, SEO Uptter Usage
55 Climate Controls (Ignition)
56Engine Control Module,
Secondary Fuel Pump (Ignition)
544

J-Case Fuses Usage
60 Cooling Fan 1
61 Automatic Level Control Compressor
62 Heavy Duty Anti-lock Brake System
63 Cooling Fan 2
64 Anti-lock Brake System 1
65 Starter
66 Stud 2 (Trailer Brakes)
67 Left Bussed Electrical Center 1
68 Electric Running Boards
69 Heated Windshield Washer System
70 Not Used
71Stud 1 (Trailer Connector
Battery Power)
72 Mid-Bussed Electrical Center 1
73 Climate Control Blower
74 Power Liftgate Module
75 Left Bussed Electrical Center 2Relays Usage
FAN HI Cooling Fan High Speed
FAN LO Cooling Fan Low Speed
ENG EXH VLV Not Used
FAN CNTRL Cooling Fan Control
HDLP LO/HID Low-Beam Headlamps
FOG LAMP Front Fog Lamps
A/C CMPRSR Air Conditioning Compressor
STRTR Starter
PWR/TRN Powertrain
FUEL PMP Fuel Pump
PRK LAMP Parking Lamps
REAR DEFOG Rear Defogger
RUN/CRANK Switched Power
545

D
Daytime Running Lamps............................. 205
Defensive Driving........................................ 342
Delayed Locking.......................................... 123
Differential, Locking..................................... 349
Doing Your Own Service Work.................... 422
Dome Lamp Override.................................. 207
Dome Lamps............................................... 207
Door
Delayed Locking...................................... 123
Locks....................................................... 122
Power Door Locks................................... 123
Programmable Automatic Door Locks....... 124
Rear Door Security Locks........................ 124
Driver
Position, Safety Belt................................... 43
Driver Information Center (DIC)................... 244
DIC Operation and Displays............245, 250
DIC Vehicle Customization....................... 262
DIC Warnings and Messages................... 252
Driving
At Night................................................... 375
City.......................................................... 380
Defensive................................................. 342Driving (cont.)
Drunken................................................... 343
Freeway................................................... 381
Hill and Mountain Roads.......................... 384
In Rain and on Wet Roads...................... 376
Off-Road.................................................. 359
Recovery Hooks....................................... 391
Rocking Your Vehicle to Get it Out.......... 390
Winter...................................................... 386
Dual Automatic Climate Control System....... 214
DVD
Rear Seat Entertainment System............. 321
E
Electrical System
Add-On Equipment................................... 537
Center Instrument Panel Fuse Block........ 540
Fuses and Circuit Breakers...................... 538
Instrument Panel Fuse Block................... 538
Power Windows and Other Power
Options................................................. 537
Underhood Fuse Block............................. 541
Windshield Wiper Fuses........................... 537
597

Fuel (cont.)
Gasoline Specications............................ 424
Low Warning Light................................... 244
Fuses
Center Instrument Panel Fuse Block........ 540
Fuses and Circuit Breakers...................... 538
Instrument Panel Fuse Block................... 538
Underhood Fuse Block............................. 541
Windshield Wiper..................................... 537
G
Gage
Engine Coolant Temperature.................... 236
Fuel......................................................... 243
Oil Pressure............................................. 240
Speedometer........................................... 227
Tachometer.............................................. 227
Voltmeter Gage........................................ 232
Garage Door Opener..........................166, 167
Gasoline
Octane..................................................... 423
Specications........................................... 424
Glove Box................................................... 178
GM Mobility Reimbursement Program.......... 575
H
Hazard Warning Flashers............................ 192
Head Restraints............................................ 16
Headlamp
Aiming..................................................... 473
Headlamps
Automatic Headlamp System.................... 205
Bulb Replacement.................................... 476
Daytime Running Lamps.......................... 205
Flash-to-Pass........................................... 195
Halogen Bulbs......................................... 476
High/Low Beam Changer......................... 195
On Reminder........................................... 205
Heated Seats................................................ 11
Heater......................................................... 214
Highbeam On Light..................................... 242
High-Speed Operation, Tires........................ 490
Highway Hypnosis....................................... 383
Hill and Mountain Roads............................. 384
Hood
Checking Things Under............................ 428
Release................................................... 429
Horn............................................................ 192
How to Use This Manual................................ 3
How to Wear Safety Belts Properly............... 43
599

Windows..................................................... 132
