2007 GMC CANYON warning

Instrument Panel Overview........................ 156
Hazard Warning Flashers.......................... 158
Other Warning Devices............................. 158
Horn.......................................................... 158
Tilt Wheel.................................................. 158
Turn Signal/Multifunction Lever.................. 159
Turn and Lane-Change Signals................. 160
Headlamp High/Low-Beam Changer.......... 161
Flash-to-Pass............................................ 161
Windshield Wipers..................................... 161
Windshield Washer.................................... 162
Cruise Control........................................... 163
Exterior Lamps.......................................... 166
Headlamps on Reminder........................... 167
Daytime Running Lamps (DRL)................. 167
Automatic Headlamp System..................... 168
Fog Lamps................................................ 169
Exterior Cargo Lamps................................ 169
Interior Lamps........................................... 170
Instrument Panel Brightness...................... 170
Dome Lamp.............................................. 170
Dome Lamp Override................................ 170
Exit Lighting.............................................. 171
Electric Power Management...................... 171
Battery Run-Down Protection..................... 171Accessory Power Outlet(s)........................ 172
Ashtray(s) and Cigarette Lighter................ 173
Climate Controls......................................... 173
Climate Control System............................. 173
Outlet Adjustment...................................... 176
Warning Lights, Gages, and Indicators..... 177
Instrument Panel Cluster........................... 178
Speedometer and Odometer...................... 179
Trip Odometer........................................... 179
Tachometer............................................... 179
Safety Belt Reminder Light........................ 180
Passenger Safety Belt Reminder Light....... 180
Airbag Readiness Light............................. 181
Passenger Airbag Status Indicator............. 182
Battery Warning Light................................ 184
Up-Shift Light (Manual Transmission)........ 185
Brake System Warning Light..................... 185
Anti-Lock Brake System Warning Light...... 186
Engine Coolant Temperature Gage............ 187
Tire Pressure Light.................................... 187
Malfunction Indicator Lamp........................ 188
Oil Pressure Light..................................... 191
Security Light............................................ 192
Cruise Control Light.................................. 192
Section 3 Instrument Panel
153

Highbeam On Light................................... 192
Daytime Running Lamps (DRL)
Indicator Light........................................ 193
Fuel Gage................................................. 193
Driver Information Center (DIC).................. 194
DIC Controls and Displays........................ 194
DIC Warnings and Messages.................... 198
Audio System(s)......................................... 203
Setting the Time for Radios without
Radio Data Systems (RDS).................... 204
Setting the Time for Radios with
Radio Data Systems (RDS).................... 205
AM-FM Radio............................................ 205Radio with CD (MP3)................................ 208
Radio with Six-Disc CD............................. 217
Using an MP3........................................... 230
XM Radio Messages................................. 236
Theft-Deterrent Feature
(Non-RDS Radios)................................. 237
Theft-Deterrent Feature (RDS Radios)....... 238
Radio Reception........................................ 238
Care of Your CDs..................................... 239
Care of the CD Player.............................. 239
Fixed Mast Antenna.................................. 239
XM™ Satellite Radio Antenna System....... 240
Chime Level Adjustment............................ 240
Section 3 Instrument Panel
154

The main components of your vehicle’s instrument panel are the following:
A. Air Outlets. SeeOutlet Adjustment on
page 176.
B. Turn Signal/Multifunction Lever. SeeTurn
Signal/Multifunction Lever on page 159.
C. Instrument Panel Cluster. SeeInstrument Panel
Cluster on page 178.
D. Hazard Warning Flasher Button. SeeHazard
Warning Flashers on page 158.
E. Passenger Side Airbag. SeeAirbag System on
page 76.
F. Exterior Lamp Controls. SeeExterior Lamps on
page 166. Fog Lamps (If Equipped). SeeFog
Lamps on page 169. Exterior Cargo Lamps.
SeeExterior Cargo Lamps on page 169.
G. Parking Brake Release. SeeParking Brake
on page 130.H. Horn. SeeHorn on page 158.
I. Traction Control Button or Four-Wheel Drive
Buttons. SeeTraction Control System (TCS) on
page 249andFour-Wheel Drive on page 126.
J. Audio System. SeeAudio System(s) on
page 203.
K. Cigarette Lighter (If Equipped). SeeAshtray(s)
and Cigarette Lighter on page 173.
L. Climate Control System. SeeClimate Control
System on page 173.
M. Accessory Power Outlet. SeeAccessory Power
Outlet(s) on page 172.
N. Passenger Air Bag Status Indicator. See
Passenger Airbag Status Indicator on page 182.
O. Glove Box. SeeGlove Box on page 150.
157

Hazard Warning Flashers
The hazard warning ashers let you warn the
police and others that you have a problem.
The front and rear turn signal lamps will ash
on and off.
The hazard warning
asher button is located
on the instrument
panel, between the
two air vents in
the center.
The hazard warning ashers work no matter what
position the key is in, and even if the key is not
in the ignition.
Press the button to make the front and rear turn
signal lamps ash on and off. Press the button
again to turn the ashers off.
When the hazard warning ashers are on, the turn
signals will not work.
Other Warning Devices
If you carry reective triangles, you can set one up
at the side of the road about 300 feet (100 m)
behind your vehicle.
Horn
To sound the horn, press the horn symbol on the
steering wheel pad.
Tilt Wheel
A tilt wheel allows you to adjust the steering wheel
before you drive. The tilt steering wheel can be
raised to the highest level to allow more room for
the driver to enter and exit the vehicle.
158

Turn Signal On Chime
If a turn signal is left on for more than 3/4 of
a mile (1.2 km), a chime will sound at each ash
of the turn signal and the message TURN SIGNAL
will also appear in the DIC. To turn the chime
and message off, move the turn signal lever to
the off position.
See “TURN SIGNAL” underDIC Warnings and
Messages on page 198for more information.
Headlamp High/Low-Beam Changer
53(Headlamp High/Low Beam Changer):
To change the headlamps from low to high beam,
push the lever toward the instrument panel.
To return to low-beam headlamps, pull the
multifunction lever toward you. Then release it.
When the high beams
are on, this indicator light
on the instrument panel
cluster will also be on.
Flash-to-Pass
This feature lets you use the high-beam
headlamps to signal a driver in front of you that
you want to pass. It works even if the headlamps
are in the automatic position.
To use it, pull the turn signal lever toward you,
then release it.
If your headlamps are in the automatic position or
on low beam, your high-beam headlamps will
turn on. They will stay on as long as you hold the
lever toward you. The high-beam indicator on
the instrument panel cluster will come on. Release
the lever to return to normal operation.
Windshield Wipers
You control the windshield wipers by turning the
band with the wiper symbol on it.
The windshield wipers work in all ignition positions,
except off. This includes the Retained Access
Power mode. SeeRetained Accessory
Power (RAP) on page 117.
8(Mist):For a single wiping cycle, turn the band
to mist. Hold it there until the wipers start. Then let
go. The wipers will stop after one wipe. If you want
more wipes, hold the band on mist longer.
161

Warning Lights, Gages, and
Indicators
This part describes the warning lights and gages
that may be on your vehicle. The pictures will
help you locate them.
Warning lights and gages can signal that
something is wrong before it becomes serious
enough to cause an expensive repair or
replacement. Paying attention to your warning
lights and gages could also save you or others
from injury.
Warning lights come on when there may be or
is a problem with one of your vehicle’s functions.
As you will see in the details on the next few
pages, some warning lights come on briey when
you start the engine just to let you know they
are working. If you are familiar with this section,
you should not be alarmed when this happens.Gages can indicate when there may be or is a
problem with one of your vehicle’s functions.
Often gages and warning lights work together to
let you know when there is a problem with
your vehicle.
When one of the warning lights comes on and
stays on when you are driving, or when one of
the gages shows there may be a problem, check
the section that tells you what to do about it.
Please follow this manual’s advice. Waiting to
do repairs can be costly — and even dangerous.
So please get to know your warning lights and
gages. They are a big help.
Your vehicle has a DIC that works along with the
warning lights and gages. SeeDriver Information
Center (DIC) on page 194for more information.
177

Speedometer and Odometer
Your speedometer lets you see your speed
in both miles per hour (mph) and kilometers
per hour (km/h).
Your odometer shows how far your vehicle
has been driven, in either miles (used in the
United States) or kilometers (used in Canada).
The odometer mileage can be checked without the
vehicle running. Simply press the trip information
stem. See “Odometer” underDIC Controls
and Displays on page 194for more information.
You may wonder what happens if your vehicle
needs a new odometer installed. If the new one
can be set to the mileage total of the old odometer,
then it must be. But if it cannot, then it is set at
zero, and a label must be put on the driver’s door
to show the old mileage reading when the new
odometer was installed.
Trip Odometer
Your vehicle has a trip odometer that can tell you
how far your vehicle has been driven since
you last set the trip odometer to zero.
See “Trip Odometer” underDIC Controls and
Displays on page 194for more information.
Tachometer
The tachometer displays the engine speed in
revolutions per minute (rpm).
Notice:If you operate the engine with the
tachometer in the shaded warning area, your
vehicle could be damaged, and the damages
would not be covered by your warranty. Do not
operate the engine with the tachometer in
the shaded warning area.
179

If, after several seconds, all status indicator lights
remain on, or if there are no lights at all, there
may be a problem with the lights or the passenger
sensing system. See your dealer for service.
{CAUTION:
If the off indicator and the airbag
readiness light ever come on together,
it means that something may be wrong
with the airbag system. If this ever
happens, have the vehicle serviced
promptly, because an adult-size person
sitting in the right front passenger seat
may not have the protection of the frontal
airbag. SeeAirbag Readiness Light
on page 181.
Battery Warning Light
This light will come on
briey when you start
the vehicle, as a
check to show you it is
working; then it
should go out.
If it stays on, or comes on while you are driving,
you may have a problem with the electrical
charging system. Have it checked right away.
Driving while this light is on could drain your
battery and result in a vehicle that may stall. See
DIC Warnings and Messages on page 198for
more information.
If you must drive a short distance with the light on,
be certain to turn off all your accessories, such
as the radio and climate control system.
184
