2007 FIAT LINEA gearbox

13
TOWING THE CAR
Make sure that the gearbox is in neutral
(N) (checking that the car moves if
pushed) and tow as for a car with tradi-
tional mechanical gearbox (see Owner
Handbook).
Should it be impossible to set to neutral,
do not tow the car and contact Fiat
Dealership.
IF A FUSE BLOWS
For fuse location see pictures in paragraph “If a fuse blows” in section “In an emergency”
in the Owner Handbook.
FUSE AMPERE
Dualogic gear control power unit and gear lever
selector (fuel supply and key) 20 30
Dualogic gearbox fuse box (power supply + key) 16 7,5

14
CHECKING OIL LEVEL
DUALOGIC GEARBOX HYDRAULIC SYSTEM OIL
For the transmission control oil level check and for clutch actuation system oil check/replacement get in touch only with the Fiat
Dealerships.
Waste gearbox oil contains dangerous substances for the environment. For chang-
ing the oil we advise contacting Fiat Dealerships who are equipped for disposing
of used oil respecting nature and the law.WARNING
SERVICE SCHEDULE
1.3 Multijet 90 HP
Check the transmission Every
control oil level 30.000 km
Check level for the clutch Every
actuation hydraulic system 30.000 km
Replace oil for the clutch Every
actuation hydraulic system 60.000 km (or every 2 years)
AIR CLEANER
To have the air cleaner replaced contact Fiat Dealership.

16
TRANSMISSION
1.3 Multijet 90HP
Gearbox with Six forward gears and reverse electrohydraulic system
with electronic control
Clutch Single-disk, dry with electric-hydraulic control
DriveFront

18
1.3 Multijet 90HP
kg
0,43
0,040
CO2 EMISSIONS
CO2emissions according to 199/100/EC Directive (gr x 100 km).
CO
2emission value referred to combined consumption is 123 (gr x 100 km).litres
0,505
0,038Specified fuels
Recommended products
TUTELA CAR CS SPEED -
Special oil with “ATF DEXRON III”
additive
TUTELA TOP4
Synthetic fluid FMVSS no. 116
DOT 4, ISO 4925 SAE J1704,
CUNA NC 956- 01
CAPACITIES
Dualogic gearbox
hydraulic system
Clutch hydraulic system
