2007 FIAT LINEA ESP

22
Calling a phone number using
call history (last calls)
LAST CALLSoption is a list of the re-
cent calls made or received. It can con-
sist of up to ten incoming calls, up to ten
outgoing calls and up to five missed calls.
?
To dial a phone number using
manual interaction, proceed as fol-
lows:
❒Press ß/MAINto open the Main
Menu.
❒Select LAST CALLSand then
press SRC/OKor
ß/MAIN.
❒The system will present a list of
phone numbers. Use NorOto
select the required phone num-
ber. Then press SRC/OKor
ß/MAINto start the call.
❒To end the phone call, press
ß/MAINfor longer than 1 sec-
ond.
}
Or, using voice interaction:
To call back the last incoming phone
number, press
‘and pronounce
“Callback”.The system will display information
about the last caller and ask if you
would like to call back this contact.
To respond with “yes”, pronounce
“Yes”, otherwise say “No”.
To redial the last phone number you
called, pronounce “Redial”. The
system will display information
about the last contact you called and
will ask if you would like to redial
this phone number. To redial the
last phone number called, say
“Yes”, otherwise say “No”. INCOMING CALLS
With the hands-free phone system you
can respond to incoming phone calls us-
ing steering wheel buttons. When a phone
call is received, the system will display in-
formation about the caller’s identity if
available.
The incoming phone call will have cus-
tomized ring tone (if this function is avail-
able on your mobile phone).
Answering a phone call
❒To answer the phone call, press
ß/MAIN.
❒To end the phone call, press ß/MAIN
for longer than 1 second.
Rejecting a phone call
❒To reject the phone call, press
ß/MAINfor longer than 1 second.
Ignoring a phone call
❒To ignore the phone call and mute the
phone call ring tone, press
&/ESC.

44
}
To set the GPRS code using voice
interaction, proceed as follows:
Press
‘, pronounce “Settings”
and then “Connection code”.
Blue&Me™will prompt “The cur-
rent GPRS connection code is value.
To change code say a number from
1 to 9 or say “Default”. To disable
the connection code say “Disable”.
To change the code, say a number
from 1 to 9 or say “Default”. To dis-
able the connection code say “Dis-
able”. (In previous text, valueis the
GPRS connection code set at that
moment).
After setting the new connection
code, Blue&Me™will say “The
Connection Code is set to value”
(here valuecorresponds to the new
GPRS code set). MEDIA PLAYER SETTINGS
Autoplay
When the Autoplay optionis on,
Blue&Me™will start to play the audio
files on your USB device as soon as you
turn the ignition key MAR. Once you ac-
tivate this option, the first time you use the
player, playback will start automatically.
The Autoplay optionshall be disabled
(when required) before connecting your
USB device to the USB port and building
or updating the media library.
?
To change Autoplay settingus-
ing manual interaction, proceed as
follows:
Open the Main Menu, select SET-
TINGS, MEDIA PLAYER, AU-
TOPLAYand then press
SRC/OKor
ß/MAIN.
To activate Autoplay, selectAU-
TOPLAY ONand press SRC/OK
or
ß/MAIN. To deactivate Auto-
play select AUTOPLAY OFFand
press SRC/OKor
ß/MAIN.

47
Due to the different marketed software
versions for mobile phones, certain auxil-
iary functions (e.g.: answering a second in-
coming phone call, transferring phone call
from hands-free phone system to mobile
phone and vice versa, etc.) could not ex-
actly correspond to what described in this
manual. In any case, phone conversation us-
ing the hands-free phone kit is not impaired.
“Pull” phones (phonebook
automatically downloaded)
“Pull” phone means that your mobile
phone supports phonebook automatic
download with Bluetooth
®wireless tech-
nology, your whole phonebook will be au-
tomatically downloaded to Blue&Me™
during phone pairing procedure. “Push” phones (phonebook not
automatically downloaded)
“Push” phone means that your mobile
phone supports the single contact down-
load with Bluetooth
®wireless technolo-
gy. During the pairing procedure you will
be required to send phonebook contacts
from your mobile phone (your phone-
book is not automatically downloaded
during the phone pairing procedure).Mobile phones with message
reader
If your mobile phone can send messages
through the Bluetooth
®wireless tech-
nology, it is possible to read incoming
messages through the Blue&Me™hands-
free kit, to store them in the dedicated in-
box or to delete them.

51
Supported playlist formats
The media player supports the following
playlist formats:
❒.m3u – file containing a list of tracks.
(release 1 and 2)
❒.wpl – Windows®-based file containing
a playlist. (playlist capacity limit for this
format is 300Kb). Playlists with exten-
sion .wpl can be built with Microsoft
®
Windows Media®Player.
The media player does not support nest-
ed or linked playlists. Playlist tracks rela-
tive and absolute paths are supported.
The media player does not support
playlists built by application software based
on specific criteria.
The media player will play playlists with
paths leading to digital audio files in fold-
ers.
For further details on how to build
playlists for Blue&Me™, refer to section
PRACTICAL HINTS FOR USING THE
MEDIA PLAYER.
Trade-marks
Microsoft®and Windows®are Microsoft Corporation registered trade-marks.
Sony®is a Sony Corporation registered trade-mark.
Ericsson®is a Telefonaktiebolaget LM Ericsson registered trade-mark.
Motorola®is a Motorola, Inc. registered trade-mark.
Nokia®is a Nokia Corporation registered trade-mark.
Siemens®is a Siemens AG registered trade-mark.
Orange
™is an Orange Personal Communications Services Limited registered trade-mark.
Audiovox®is an Audiovox Corporation registered trade-mark.
Bluetooth®is a Bluetooth®SIG, Inc registered trade-mark.
Lexar
™and JumpDrive®are Lexar Media, Inc. registered trade-marks.
SanDisk®and Cruzer™are SanDisk Corporation registered trade-marks.
The other trade-marks are proprietary of the respective Companies.

60
Problem Probable Cause Possible Solution
Display screen shows:
NO PHONEBOOK
Or the system says:
“As requested, the phonebook has not
been copied. To copy the phonebook
onto the system go to
SETTINGS menu and select
“USER DATA”. To dial a phone
number, say “Dial”.”
For “pull” phones
❒Use the option PHONEBOOKin the SETTINGSmenu to downloadthe phonebook again
❒Enter contact information in the
phonebook on your mobile phone
and then download the phonebook
again

SETTING FUNCTIONS -
MANAGING USER DATA AND
PHONEBOOK
For “push” phones
❒Use the option ADD
CONTACTSin the SETTINGS
menu to send contacts in the
phonebook on your mobile phone
to the system

SETTING FUNCTIONS -
MANAGING USER DATA AND
PHONEBOOK For “pull” phones
❒When the system asked “The data
from the phonebook will now be
copied onto the system. Continue?”,
you responded with “No”
❒You have not downloaded your
phonebook via the SETTINGS
menu
❒The downloaded phonebook was
deleted
For “push” phones
❒When the system asked “The data
from the phonebook will now be
copied onto the system. Continue?”,
you responded with “No”.
❒You have not sent contacts to the
system using the ADD
CONTACTSprocedure
❒The downloaded phonebook was
deleted
TROUBLESHOOTING
HANDS-FREE KIT
General - display screen

64
Problem Probable Cause Possible Solution
The system did not respond to voice
command or key press
❒Press ‘and pronounce the voice
command again
Make sure that you face forward and
speak clearly at a normal volume
❒Press ß/MAINand try the operation
again. Make sure to take action within
approximately eight seconds after
pressing
ß/MAIN
❒If you do not speak soon enough
after pressing
‘, the system
will interrupt voice interaction
❒If you are speaking too far from the in-car microphone (for example,if
you are sitting in the back seat), the
system may not hear your voice
command
❒If you don’t wait for the tone after
pressing
‘, the system will get
only a portion of the keyword
and will misrecognize it
❒If you don’t press ‘before
pronouncing a voice command,
the system will not activate voice
recognition and therefore recognize
your voice commands
❒If you don’t press ß/MAINto
enter the Main Menu, it will not be
possible to access manually the
Blue&Me™menu
❒If after pressing ß/MAIN, you
don’t take action within approx.
eight seconds, the system will not
respond to your key press

72
Problem Probable Cause Possible Solution
After receiving, answering and
ending a second call, the multifunction
display shows PRIVATE NUMBER,
instead of the phone number
corresponding to the first call
Models: Nokia®6600
Sometimes when trying to use this phone
with Blue&Me™, using the
ß/MAIN
button, the message SEARCHINGis
displayed before the connection
is implemented
Models: Nokia®6600
No ring tone is produced when receiving
a second incoming call
Models: Nokia®6820
Pressing
ß/MAINfor over 1 second to
reject a second incoming call, disconnects
also the current phone conversation
Models: Nokia®6820
When answering an incoming call using
the mobile phone keypad, sometimes the
mobile phone disconnects from
Blue&Me™and the phone conversation
has to be continued on the mobile phone
instead of the hands-free feature
Models: Nokia®7610
–
Wait for connection.
To prevent recurring of this problem,
reset the mobile phone by turning it
off and on again
The ring tone of the second incoming
call will always be lower than
normal. Try to turn up the ring tone
volume
–
Answer the incoming call by pressing
ß/MAIN In this specific case, the system is not
able to identify which phone call is
ended
The connection between this mobile
phone and Blue&Me™sometimes
may deactivate
On this mobile phone the ring tone of
the second incoming call is very low
This behavior depends on the specific
features of this mobile phone
For certain software versions of this
mobile phone, answering a call using
the keypad will automatically
disconnect the mobile phone from the
hands-free kit

84
– Additional Software/Services.The SOFTWARE may permit Fiat Auto S.p.A., Fiat Auto S.p.A.’s Software Suppliers, their affil-
iates and/or their designated agent to provide or make available to you SOFTWARE updates, supplements, add-on components,
or Internet-based services components of the SOFTWARE after the date you obtain your initial copy of the SOFTWARE (“Sup-
plemental Components”).
– If Fiat Auto S.p.A. provides or makes available to you Supplemental Components and no other EULA terms are provided along
with the Supplemental Components, then the terms of this EULA shall apply.
– If Fiat Auto S.p.A.’s Software Suppliers, their affiliates and/or their designated agent make available Supplemental Components,
and no other EULA terms are provided, then the terms of this EULA shall apply, except that the Fiat Auto S.p.A.’s Software
Suppliers or affiliate entity providing the Supplemental Component(s) shall be the licensor of the Supplemental Component(s).
– Fiat Auto S.p.A., Fiat Auto S.p.A.’s Software Suppliers, their affiliates and/or their designated agent reserve the right to discon-
tinue any Internet-based services provided to you or made available to you through the use of the SOFTWARE.
– Links to Third Party Sites.The SOFTWARE may provide you with the ability to link to third party sites through the use of
the SOFTWARE. The third party sites are not under the control of Fiat Auto S.p.A.’s Software Suppliers, their affiliates and/or
their designated agent. Neither Fiat Auto S.p.A.’s Software Suppliers nor their affiliates nor their designated agent are respon-
sible for (i) the contents of any third party sites, any links contained in third party sites, or any changes or updates to third par-
ty sites, or (ii) webcasting or any other form of transmission received from any third party sites. If the SOFTWARE provides
links to third party sites, those links are provided to you only as a convenience, and the inclusion of any link does not imply an
endorsement of the third party site by Fiat Auto S.p.A.’s Software Suppliers, their affiliates and/or their designated agent.
UPGRADES AND RECOVERY MEDIA
– If the SOFTWARE is provided by Fiat Auto S.p.A. separate from the DEVICE on media such as a ROM chip, CD ROM disk(s) or
via web download or other means, and is labeled “For Upgrade Purposes Only” you may install one (1) copy of such SOFT-
WARE onto the DEVICE as a replacement copy for the existing SOFTWARE, and use it in accordance with this EULA, including
any additional EULA terms accompanying the upgrade SOFTWARE.
