2007 FIAT GRANDE PUNTO technical specifications

228
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
SELENIA K P.E.
Contractual
Technical Reference
N° F603.C07
SELENIA WR
Contractual
Technical Reference
N° F515.D06According to
Service Schedule
According to
Service Schedule Synthetic-based oils, grade SAE 5W-40, ACEA C3.
FIAT 9.55535-S2qualification
Synthetic-based oils, grade SAE 5W-40.
FIAT 9.55535-N2qualification
FLUIDS AND LUBRICANTS
RECOMMENDED PRODUCTS AND THEIR SPECIFICATIONS
Use Fluid and lubricant specifications Original Change
for correct car operation fluids and
lubricants
Oil for
petrol engines
Oils for
diesel engines
For diesel engines, in the event of emergencies when genuine products are not available, lubricants providing at least ACEA B4
performance are allowed; in that case, engine best performance is not guaranteed; we recommend to have it replaced as soon as
possible with the recommended lubricants by the Fiat Dealership.
Use of products with low-quality properties than ACEA A3 and ACEA B4 could cause damages to the engine that are not covered
by the warranty.
For very cold climate conditions, ask Fiat Dealership for the appropriate Seleniaproduct to use.
211-231 Punto GDX GB 31-07-2007 11:15 Pagina 228

Lubricants and
greases
for transmission
Use Fluid and lubricant specifications Original fluids and Applications
for correct car operation lubricants
(*) IMPORTANT Do not top up or mix with fluids having characteristics different from those specified.(❒) When the vehicle is used under particularly harsh climate conditions, we recommend using a 60-40 mixture of PARAFLU UP and
demineralised water.LSynthetic-based oils, grade SAE 75W- 85
that passes API GL4 PLUS specifications.
Synthetic-based oil, grade SAE 75W-85
that passes API GL-4 specifications
Grease containing Molybdenum bisulphide for high
temperature appliances. N.L.G.I. 1-2 consistency.y
Specifc grease to be used for constant-velocity joints with
low friction coefficient. N.L.G.I. 0-1 consistency.
Poly-urea oil synthetic-based grease suitable for high
temperatures. NL.GI. 2 consistency
Synthetic fluid FMVSS no. 116 DOT 4, ISO 4925
SAE J1704, CUNA NC 956- 01
Red protective with antifreeze action, based on
inhibited monoethylen glycol with organic formula
based on O.A.T, that passes CUNA NC 956-16,
ASTM D 3306 specifications.
Mixture of alcohol, water and surfactants
CUNA NC 956-II
TUTELA CAR
TECHNYX
Contractual Technical
Reference N° F010.B05
TUTELA CAR
MATRYX
Contractual Technical
Reference N° F108.F02
TUTELA ALL
STAR Contractual
Technical Reference
N° F702.G07
TUTELA
STAR 700
Contractual Technical
Reference N° F701.C07
TUTELA STAR 325Contractual Technical
Reference N° F301.D03
TUTELA TOP 4Contractual Technical
Reference N° F001.A93
PARAFLU UP (*)Contractual Technical
Reference N° F101.M01
TUTELA PROFES-
SIONAL SC 35
Contractual Technical
Reference N° F201.D02
Mechanical gearbox
and differential (petrol
versions and 1.3 Multijet
75 HP versions)
Mechanical gearbox
and differential
(1.3 Multijet 90HP
versions and
1.9 Multijet versions)
CV joints
on wheel side
CV joints on differential
side (excluding 1.9
Multijet versions)
CV joints
on differential side
(1.9 Multijet versions)
Brake and clutch
hydraulic controls
Radiator antifreeze
proportion: 50% water
and 50% PARAFLU UP
(❒)
To be used diluted or
undiluted in windscreen/
rear window washer/
wiper systems
229
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
Brake fluids
Protective agent for
radiators
Windscreen/ rear
window washer fluid
211-231 Punto GDX GB 31-07-2007 11:15 Pagina 229

230
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
❒extra-urban cycle: frequent accelerat-
ing in all gears, simulating extraurban
use of the car: speed varies between 0
and 120 km/h;
❒combined consumption: is calculated
weighing about 37% of urban cycle con-
sumption and about 63% of extraurban
consumption.
FUEL
CONSUMPTION
The fuel consumption figures given in the
table below are determined on the basis
of the homologation tests set down by
specific European Directives.
The procedures below are followed for
measuring consumption:
❒urban cycle: cold starting followed by
driving that simulates urban use of the
car;IMPORTANT The type of route, traffic
situations, weather conditions, driving
style, general conditions of the car, trim
level/equipment/accessories, load, climate
control system, roof rack, other situations
that affect air drag may lead to different
fuel consumption levels than those mea-
sured.
Fuel consumption according to Directive 1999/100/EC (litres x 100 km)
Versions Urban Extra-urban Combined
1.27.5 4.9 5.9
1.47.5 5.0 5.9
1.4 16V8.4 4.6 6.0
1.4 T-JET8.7 5.4 6.6
1.3 Multijet 75 HP6.2 3.5 4.5
1.3 Multijet 90 HP (5 gears)5.9 4.0 4.7
1.3 Multijet 90 HP (6 gears)5.9 3.9 4.6
1.9 Multijet7.4 4.4 5.5
1.9 Multijet Sport7.8 4.7 5.8
211-231 Punto GDX GB 31-07-2007 11:15 Pagina 230

231
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
CO2EMISSIONS
The CO2emission levels at the exhaust given in the following tables refer to combined consumption.
Versions CO
2Emissions accordingto 1999/100/CE Directive (g/km)
1.2139
1.4139
1.4 16V142
1.4 T-JET155
1.3 Multijet 75 HP119
1.3 Multijet 90 HP (5 gears) 123
1.3 Multijet 90 HP (6 gears)122
1.9 Multijet145
1.9 Multijet Sport154
211-231 Punto GDX GB 31-07-2007 11:15 Pagina 231

232
WARNING
LIGHTS AND
MESSAGES
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
Bodywork
– maintenance .................................. 208
– version codes ............................... 214
Bonnet .................................................. 88
Boot ........................................................ 84
– extension........................................ 85
– tailgate opening/closing ............... 84
– emergency opening....................... 85
Boot light .............................................. 174
Brake Assist (brake assist
in an emergency)............................... 92
Brakes
– fluid level ........................................ 201
– technical data ................................ 218
Bulb (replacement)
– general instructions ..................... 166
– types of bulbs ................................ 166
Capacities ............................................ 106
Car inactivity ....................................... 138
Car maintenance
– periodical checks........................... 195
– scheduled servicing ...................... 190– service schedule ........................... 191
– use of the car under
heavy conditions............................ 195
Card box - CD box............................. 74
Carrying children safely ..................... 115
Ceiling lights
– boot light ....................................... 68
– courtesy ......................................... 68
– front ................................................ 66
– puddle/door .................................. 68
– rear ................................................. 67
Central console oddment
compartment..................................... 73
Chassis (marking) ............................... 213
Checking levels..................................... 197
Child lock.............................................. 80
Child restraint systems
– “Universal Isofix” ......................... 120
– Passenger’s seat compliance ...... 115
Cigar lighter.......................................... 74
Clutch ................................................... 217
CO
2emissions..................................... 231
Code Card ........................................... 7
ABS ...................................................... 91
Accessories purchased
by the owner .................................... 105
Additional heater................................. 58
Air bag
– front................................................. 121
– side .................................................. 124
Air filter ................................................ 202
Air vents ............................................... 43
Alarm...................................................... 11
Armrest................................................. 73
Ashtray................................................... 75
ASR ......................................................... 94
– activation/deactivation................. 94
At the filling station ............................ 106
Automatic two-zone climate
control system .................................. 52
Battery
– checking the charge ..................... 202
– jump starting ................................. 154
– recharging ...................................... 185
– replacing ......................................... 203
II I
N N
D D
E E
X X
232-240 Punto GDX GB 20-07-2007 9:44 Pagina 232

233
WARNING
LIGHTS AND
MESSAGES
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
– side bulb replacement ................. 170
Doors..................................................... 78
Electrical socket ................................ 75
Engine
– identification code ........................ 212
– marking ........................................... 213
– technical data ................................ 215
Engine compartment
– washing ........................................... 197
Engine coolant fluid level ..................200
Engine coolant temperature gauge .. 17
Engine oil
– consumption .................................. 196
– level check...............................196-199
– specifications ................................. 228
EOBD system ...................................... 95
ESP system............................................ 92
External lights ...................................... 59
Fiat CODE system............................. 7
Fix & Go automatic ............................ 161
Flashing the headlights ....................... 59
Fluid levels ............................................ 196
Fluids and lubricants ........................... 228Follow me home (device) ................. 60
Front ceiling lights
– bulb replacement........................... 173
– control ............................................ 66
Front fog lights
– bulb replacement .......................... 170
– control button .............................. 69
Fuel
– consumption................................... 230
– cut-off switch.................................. 71
– level gauge ....................................... 17
Fuel cut-off switch............................... 71
Fuel filler cap ....................................... 106
Fuel level gauge ................................... 17
Fuses (replacement) ........................... 175
Gearbox
– using manual gearbox .................. 132
Glass holder - can holder................... 74
Glove box/oddment compartment .. 72
Handbrake .......................................... 184
Hands free kit with voice recognition
and Bluetooth
®technology............. 104
Hazard lights ........................................ 69 Consumption
– engine oil ........................................ 196
– fuel ................................................... 230
Control buttons .................................. 69
Correct use of the car ...................... 127
Cruise Control..................................... 64
Courtesy light
– bulb replacement .......................... 174
– control button .............................. 68
Current outlet...................................... 75
Dashboard
– Left hand drive version ............... 5
– Right hand drive version ............. 6
Dashboard and controls..................... 4
Dead lock device................................. 79
Digital display ....................................... 18
Dimensions .......................................... 223
Dipped beam headlights
– bulb replacement........................... 169
– control ............................................ 59
Direction indicators
– control ............................................ 60
– front bulb replacement ............... 169
– rear bulb replacement ................. 170
232-240 Punto GDX GB 20-07-2007 9:44 Pagina 233

234
WARNING
LIGHTS AND
MESSAGES
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
Load limiters ...................................... 112
Main beam headlights
– bulb replacement .......................... 169
– control ............................................ 59
– flashing ............................................ 59
Manual climate control system ........ 46
Multifunction display........................... 23
Number plate light ............................ 172
Oddment compartments.................. 72
Paint ..................................................... 208
Parking .................................................. 131
Parking sensors.................................... 101
Performance ........................................ 224
Plates
– bodywork paint
identification plate ....................... 213
– model plate .................................... 212
Pollen filter ........................................... 202
Power socket ...................................... 75
Power steering .................................... 96
Power windows .................................. 81Presetting for mounting the
“Isofix Universal” child
restraint system................................. 120
Pretensioners ...................................... 112
Prolonged car inactivity...................... 138
Protecting the environment ............. 107
Puddle/door light
– bulb replacement .......................... 174
Radio transmitters and cellular
telephones ......................................... 105
Radionavigator presetting system .... 104
Rain sensor............................................ 62
Rear ceiling lights
– bulb replacement........................... 173
– control ............................................ 67
Rear doors emergency lock device .... 81
Rear fog lights
– bulb replacement .......................... 171
– control button .............................. 70
Rear window washer
– control ............................................ 63
– fluid level ........................................ 200 Head restraints
– front ................................................ 38
– rear................................................... 39
Headlight washer
– control ............................................ 63
– fluid level ........................................ 200
Headlights.............................................. 89
– beam adjustment .......................... 89
– headlight slant adjusting device . 89
Heated rear window ...............45-50-58
Heating and ventilation system ........ 42
Identification data .............................. 212
Ignition switch ..................................... 13
In an emergency .................................. 153
Instrument panel ................................. 14
Instruments .......................................... 16
Interior fittings .................................... 72
Interiors ................................................ 210
Isofix (child restraint system) .......... 120
Jack ........................................................ 156
Jacking the car ..................................... 186
Key with remote control ................ 8
Key without remote control ...........11
Keys ........................................................ 8
232-240 Punto GDX GB 20-07-2007 9:44 Pagina 234

235
WARNING
LIGHTS AND
MESSAGES
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
Side/taillights
– control ............................................ 59
– front bulb replacement................. 168
– rear bulb replacement.................. 170
Smart washing ..................................... 62
Snow chains ......................................... 137
Sound system ...................................... 103
Spark plugs
– type ................................................. 215
Speedometer ....................................... 16
Starting the engine
– bump starting ................................ 155
– diesel engines ................................ 129
– emergency start-up ...................... 154
– ignition switch ............................... 13
– jump starting .................................. 154
– petrol engines ............................... 128
– stopping the engine....................... 130
– warming up the engine ................ 130
Steering.................................................. 218
Steering column lock ......................... 13
Steering wheel (adjustment) ............ 40
Sunroof.................................................. 76
Sun visors ............................................. 75
Suspensions .......................................... 218Symbols ................................................. 7
Tailgate ................................................ 84
Technical specifications ..................... 211
Third brake light ................................. 172
Top speeds ........................................... 224
Towing the car .................................... 187
Towing trailers
– tow hook installation ................... 135
T.P.M.S. system.................................... 98
Transmission ........................................ 217
Trip computer ..................................... 34
Tyre pressure ...................................... 222
Tyres
– changing .......................................... 155
– maintenance .................................. 205
– standard tyres................................ 221
– understanding tyre marking ....... 219
Using the manual gearbox .............. 132
Ventilation .......................................... 42
Warning lights and messages ......... 139
Weights ................................................ 225 Rear window wiper
– blades .............................................. 207
– control ............................................ 63
– nozzles ............................................ 208
Rearview mirrors
– door mirrors ................................. 41
– driving mirror ................................ 40
Refuelling............................................... 106
Rev counter.......................................... 16
Reversing light ..................................... 171
Roof rack/ski rack .............................. 88
Rubber hoses ....................................... 206
Safety devices ..................................... 109
Seat adjustment ................................... 38
Seat belts
– general instructions ..................... 113
– load limiters ................................... 112
– maintenance .................................. 115
– use ................................................... 110
Seats
– adjustment ..................................... 38
– cleaning ........................................... 210
– tilting (rear seats).......................... 85
232-240 Punto GDX GB 20-07-2007 9:44 Pagina 235
