2007 FIAT BRAVO fuse box

DASHBOARD
The presence and the position of the instruments and warning lights may vary according to the versions.
1.Side window air vent - 2.Adjustable and swivel air vent - 3.External light stalk - 4.Instrument panel - 5.Windscreen/rear win-
dow wiper/trip computer stalk - 6.Adjustable and swivel air vents - 7.Hazard light switch - 8.Front passenger air bag - 9.Glove-
box - 10.Set of switches for front/rear fog lights and menu opening/setting - 11.Sound system controls - 12.Controls for heat-
ing/ventilation/climate control - 13.Electric power steering/ASR system on/off switch unit (where fitted)/front parking sensors/boot
opening (where fitted) - 14.Ignition key and ignition device - 15.Driver’s knees air bag (where provided) - 16.Driver’s air bag -
17.Steering wheel locking/release stalk - 18.Fusebox access door - 19.Bonnet opening lever
5
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
F0Q0639mfig. 1
001-022 BRAVO GB 10-05-2007 8:57 Pagina 5

16
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
ALARM
(where provided)
The alarm function is provided in addition
to all remote control functions previous-
ly described and it is controlled by the re-
ceiver located under the dashboard, next
to the fuse box.WHEN THE ALARM
IS TRIGGERED
The alarm comes into action in the fol-
lowing cases:
❒unlawful opening of one of the doors,
bonnet or boot (perimetral protec-
tion);
❒attempt to start the engine (turning the
ignition key to MAR);
❒battery cable cutting;
❒presence of moving bodies in the pas-
senger’s compartment (volumetric pro-
tection);
❒abnormal raising/sloping of the car. Depending on the markets, the cutting in
of the alarm causes operation of the siren
and direction indicators (for about 26 sec-
onds). The ways of operating and the num-
ber of cycles may vary depending on the
markets.
A maximum number of sound/sight cycles
is however envisaged.
The volume sensing and anti-lift protec-
tions may be turned off by operating the
control on the front courtesy light (see
“Volume-sensing/anti-lift protection” para-
graph).
IMPORTANT The engine immobiliser
function is guaranteed by the Fiat CODE
system, which is automatically activated
when the ignition key is removed.
001-022 BRAVO GB 10-05-2007 8:57 Pagina 16

Before replacing a fuse, make
sure the ignition key has been
removed and that all the oth-
er services are switched off
and/or disengaged.
178
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
If a general fuse (MEGA-
FUSE, MIDI-FUSE, MAXI-
FUSE) cuts in, do not attempt any re-
pair and contact a Fiat Dealership.
WARNING
If a fuse blows again, contact
a Fiat Dealership.
WARNING
IF A FUSE BLOWS
GENERAL
The fuse is a protective device for the
electric system: it comes into action (i.e.
it cuts off) mainly due to a fault or im-
proper action on the system.
When a device does not work, check the
efficiency of its fuse: the conductor ele-
ment A-fig. 47must be intact. If not, re-
place the fuse with one of the same amp
rating (same colour).
B: undamaged fuse
C: fuse with damaged filament.
To replace a fuse, use the pliers Dhooked
to the fusebox on the dashboard.Never replace a fuse with
metal wires or anything else.
fig. 47F0Q0220m
Never replace a fuse with
another with a higher amp
rating, DANGER OF FIRE.
WARNING
155-190 BRAVO GB 10-05-2007 9:19 Pagina 178

179
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
FUSE LOCATION
The vehicle fuses are grouped in three
control units:
❒instrument dashboard fuse control
unit;
❒fuse control unit in engine compart-
ment;
❒fuse control unit in luggage compart-
ment;
fig. 49F0Q0266m
fig. 48F0Q0727m
Fuse box on the dashboard fig. 49
To gain access to the fuses in the fuse box
on the dashboard, loosen the three fas-
tening screw A-fig. 48and remove the
cover B.
155-190 BRAVO GB 10-05-2007 9:19 Pagina 179

180
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
Fuse box next to the battery fig. 51
To gain access to the fuse box next to the
battery, press the retainers A-fig. 50and
remove the protection cover B.
fig. 51F0Q0026m
fig. 50F0Q0498m
155-190 BRAVO GB 10-05-2007 9:19 Pagina 180

181
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
Fuse box in the boot
(where provided) fig. 52
To gain access to the fuses in the fuse box
on the left side of the boot, open lid
A-fig. 53.
fig. 52F0Q0747m
fig. 53F0Q0744m
155-190 BRAVO GB 10-05-2007 9:19 Pagina 181

184
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
COMPONENTS FUSE AMPERE FIGURE
Fuel motor pump on tank F21 15 51
Engine diagnosis system primary loads (injectors, ignition coils) F22 15 51
Engine diagnosis system primary loads
(injectors, ignition coils, engine control unit for diesel versions) F22 20 51
Braking system control unit (NFR) (electronic control unit, solenoid valves) F23 30 51
Electric steering control unit (NGE) F24 7.5 51
Remote switch coils on fuse box in engine compartment (CVM)/
Body Computer control unit (NBC) F31 5 49
Hi-Fi system subwoofer F32 15 49
Rear left power window F33 20 49
Rear right power window F34 20 49
Brake pedal control (normally closed contact NC)/
water in diesel fuel sensor/flow meter F35 5 49
155-190 BRAVO GB 10-05-2007 9:19 Pagina 184

234
RIGHT HAND DRIVE VERSIONS
DASHBOARD
The presence and the position of the instruments and warning lights may vary according to the versions.
1.Adjustable and swivel air vent - 2.Side window air vent - 3.Front passenger air bag - 4.Adjustable and swivel air vents - 5.Haz-
ard light switch - 6.External light stalk - 7.Instrument panel - 8.Windscreen/rear window wiper/trip computer stalk - 9.Bonnet
opening lever - 10.Fusebox access door - 11.Ignition key and ignition device - 12.Steering wheel locking/release stalk - 13.Dri-
ver’s air bag - 14.Driver’s knees air bag (where provided) - 15.Set of switches for front/rear fog lights and menu opening/setting
16.Controls for heating/ventilation/climate control - 17.Sound system controls - 18.Set of ON/OFF switches for electric power
steering and ASR system (where provided) - 19.Glovebox
F0Q0005mfig. 1
213-236 BRAVO GB 16-05-2007 10:11 Pagina 234
