2007 FIAT BRAVO sensor

101
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
FAILURE INDICATIONS
In the event of sensor failures, when en-
gaging the reverse gear the driver is
warned by the turning on of warning light
èon the instrument panel or by symbol
t, together with the message on the dis-
play (see section “Warning lights and mes-
sages”).
GENERAL WARNINGS
When parking, take the utmost care to
obstacles set above or under the sensors.
Objects set close to the car front or rear
part, under certain circumstances are not
detected and could therefore cause dam-
ages to the car.
Parking sensors regular operation could
be affected by the following conditions:
❒Indications sent by the sensors can be
altered by dirt, snow or ice deposited
on the sensors or by multiple painting.
❒Sensors detect non-existing objects,
“echo disturbances” due to: car washing,
rain (with very strong wind), hail, etc.
❒Indications sent by the sensors can al-
so be altered by ultrasound systems
(e.g.: truck pneumatic brakes or pneu-
matic hammers) set nearby the car.
❒Parking sensors performance can also
be affected by sensor position; for ex-
ample changes to the car set-up due to
shock-absorber wear, suspensions,
changing tyres, loading the car too
much, implementing special tuning to
lower the car.
❒Presence of obstacles at the upper side
of the car not be detected since the sys-
tem detects obstacles that could knock
into the lower side of the car. SENSOR DETECTION RANGE
Sensors enable the system to monitor the
front part (versions with 8 sensors) and
the rear part of the car.
Actually their position covers the central
and side areas of the front and rear part
of the car.
An obstacle positioned at central area is
detected at a distance less than 0.9 m
(front) and 1.40 m (rear).
An obstacle positioned at side area is de-
tected at a distance less than 0.6 m.
OPERATION WITH TRAILER
Parking sensor operation is deactivated
automatically when the trailer electric ca-
ble plug is fitted into the car tow hook
socket.
Sensors are reactivated when removing
the trailer cable plug.
IMPORTANT If you wish to leave the
tow-hook fitted without a trailer attached,
contact your Fiat Dealership to update the
system because the tow-hook will be de-
tected as an obstacle by the central sen-
sors.
083-104 BRAVO GB 10-05-2007 9:10 Pagina 101

103
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
FUEL FILLER CAP fig. 108
To carry out fuelling, open flap Aand un-
screw cap B: the cap is fitted with an an-
tiloss device Cwhich fastens it to the flap
so it cannot be mislaid.
The cap Bis fitted with key-lock: open the
lid A, then, turn the ignition key in the lock
and open the cap.
When refuelling, secure the cap to the de-
vice inside the lid as shown in the figure. IMPORTANT The sealing of the tank may
cause light pressurising in the tank. A lit-
tle breathing off, while slackening the cap,
is absolutely normal.
After refuelling, turn the cap clockwise un-
til it clicks, then turn the key clockwise,
remove it and close the flap.
fig. 108F0Q0695m
Keep naked flames or light-
ed cigarettes away from the
fuel filler hole as there is a danger of
fire. Do not bend too close to the hole
either so as not to breathe in harmful
vapours.
WARNING
PROTECTING THE
ENVIRONMENT
The devices for curtailing petrol engine
emissions are the following:
❒three-way catalytic converter;
❒Lambda sensor;
❒fuel evaporation system.
In addition, do not let the engine run, even
for a test, with one or more spark plugs
disconnected.
The devices for curtailing diesel fuel en-
gine emissions are the following:
❒oxidising catalytic converter;
❒exhaust gas recirculation system
(E.G.R.);
❒Lambda sensors;
❒diesel particulate filter (DPF) (where
provided it is fitted instead of the Lamb-
da sensor).
083-104 BRAVO GB 10-05-2007 9:10 Pagina 103

142
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
WARNING
LIGHTS AND
MESSAGES
WARNING LIGHTS
AND MESSAGES
GENERAL WARNINGS
Turning on of warning light and/or symbol
is accompanied by specific message and/or
by buzzer sound where provided by in-
strument panel. These indications are
concise and cautionaryand shall not be
considered as exhaustive and/or as an al-
ternative to the specifications contained
in this Owner Handbook which shall al-
ways be read through carefully and thor-
oughly. In case of failure indication always
refer to the specifications contained
in this section.
IMPORTANT Failure indications displayed
are divided into two categories: very se-
riousand less seriousfailures.
Very seriousfailures are indicated by a
repeated and prolonged warning “cycle”.
Less seriousfailures are indicated by a
limited warning “cycle”.
The warning cycle of both failure classes
can be stopped by pressing button
MODE. The warning light (or symbol on
the display) will stay on until eliminating
the fault.Handbrake on
The warning light turns on when the hand-
brake is on.
If the car is moving, a buzzer will also
sound.
IMPORTANT If the warning light turns on
when travelling, check that the handbrake
is not engaged. LOW BRAKE FLUID
LEVEL (red)
HANDBRAKE ON (red)
Turning the ignition key to MARthe
warning light turns on, but it should go off
after few seconds.
Low brake fluid level
The warning light turns on when the lev-
el of the brake fluid in the reservoir falls
below the minimum level, due to possi-
ble leak in the circuit.
The display will show the dedicated mes-
sage.BRAKE PAD
WEAR (amber)
The warning light (or the symbol on the
display) turns on if the front brake pads
are worn; in this case have them changed
as soon as possible.
The display will show the dedicated mes-
sage.
IMPORTANT Since the car is fitted with
wear sensors for the front brake pads,
when changing them, check also the rear
brake pads.
x
If the xwarning light turns
on when travelling (together
with the message on the display) stop
the car immediately and contact Fiat
Dealership.
WARNING
d
141-154 BRAVO GB 10-05-2007 9:17 Pagina 142

147
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
WARNING
LIGHTS AND
MESSAGES
GENERIC FAILURE
INDICATION
(amber)
Inertial fuel cut-off switch
intervened
The warning light (or the symbol on dis-
play) comes on when the inertial fuel cut-
off switch is triggered.
The display will show the dedicated mes-
sage.
Engine oil pressure sensor failure
The warning light (or the symbol on the
display) turns on when a fault is detected
to engine oil pressure sensor.
Twilight sensor failure
The warning light (or the symbol on dis-
play) turns on when a fault is detected to
the twilight sensor.
The display will show the dedicated mes-
sage.
Speed limit exceeded
(only for Arabic countries)
The warning light (amber), or symbol on
the display (red), comes on when a speed
of 120 km/h is exceeded.
è
DIESEL PARTICULATE
FILTER CLOGGED
(amber)
(Multijet versions)
Turning the ignition key to MARthe
warning light turns on, but it should go off
after few seconds.
The warning light turns on when the diesel
particulate filter is clogged and the driving
conditions do not enable to activate au-
tomatically the reclaiming procedure.
To enable the cleaning procedure, keep
the car running until the warning light
turns off.
The display will show the dedicated mes-
sage.
h
Rain sensor failure
The warning light (or the symbol on the
display) on the dial turns on when the rain
sensor is faulty. Contact Fiat Dealership.
The display will show the dedicated mes-
sage.
Parking sensors failure
(where provided)
The warning light (or the symbol on the
display) when a fault is detected to park-
ing sensors.
Tyre pressure monitoring
system failure (where provided)
The warning light (or the symbol on the
display) turns on when a failure is detect-
ed in the T.P.M.S. system (where provid-
ed).
Should one or more wheels without sen-
sor be fitted, the instrument panel warn-
ing light will come on and stay on until
restoring initial conditions.
The display will show the dedicated mes-
sage.
NOTE When one of the above faults oc-
curs, contact your Fiat Dealership as soon
as possible.
141-154 BRAVO GB 10-05-2007 9:17 Pagina 147

183
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
COMPONENTS FUSE AMPERE FIGURE
Single-tone horn F10 10 51
Engine diagnosis system secondary loads
(lambda sensor, canister solenoid valve, PDA system solenoid valve,
EGR solenoid valve, throttle solenoid valve, VGT solenoid valve,
glow plug warming control unit) F11 15 51
Headlamp alignment correction system
(versions with gas discharge headlights) F13 15 49
Headlight alignment correction system
(versions with halogen headlights) F13 7.5 49
Engine control unit (NCM) F16 7.5 51
Engine control unit (NCM) F17 10 51
Engine control unit (NCM) F18 10 51
Conditioner compressor F19 7.5 51
Headlight washer motor pump F20 20 51
155-190 BRAVO GB 10-05-2007 9:19 Pagina 183

184
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
COMPONENTS FUSE AMPERE FIGURE
Fuel motor pump on tank F21 15 51
Engine diagnosis system primary loads (injectors, ignition coils) F22 15 51
Engine diagnosis system primary loads
(injectors, ignition coils, engine control unit for diesel versions) F22 20 51
Braking system control unit (NFR) (electronic control unit, solenoid valves) F23 30 51
Electric steering control unit (NGE) F24 7.5 51
Remote switch coils on fuse box in engine compartment (CVM)/
Body Computer control unit (NBC) F31 5 49
Hi-Fi system subwoofer F32 15 49
Rear left power window F33 20 49
Rear right power window F34 20 49
Brake pedal control (normally closed contact NC)/
water in diesel fuel sensor/flow meter F35 5 49
155-190 BRAVO GB 10-05-2007 9:19 Pagina 184

185
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
COMPONENTS FUSE AMPERE FIGURE
Door opening system control unit (CGP)
(door opening/closing, safe lock, tailgate release) F36 20 49
Brake pedal control (normally closed contact NA)/
Instrument panel (NQS)/gas-discharge lamp control units
on front headlights F37 7.5 49
Sound system/Sound system presetting/Connect Nav +/Blu&Me System/
Alarm siren (CSA)/Alarm system on ceiling light/Internal cooling unit
system/Tyre pressure monitoring control unit
(CPP)/Diagnostic socket connector/Rear ceiling lights F39 10 49
Heated rear window F40 30 49
Electric door mirror defrosters/Defrosters on front nozzles F41 7.5 49
Braking system control unit (NFR)/Yaw sensor (YRS) F42 5 49
Windscreen wiper/Windscreen/rear window washer bidirectional
motor pump system on steering column stalk F43 30 49
Current outlet/Cigar lighter F44 15 49
155-190 BRAVO GB 10-05-2007 9:19 Pagina 185

186
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
COMPONENTS FUSE AMPERE FIGURE
Power sunroof motor F46 20 49
Front power window (left side) F47 20 49
Front power window (right side) F48 20 49
Emergency control panel (illumination)/Central right and left branch
control panel (illumination, ASR switch)/
Controls on steering wheel (illumination)/Control panel on front
ceiling light (illumination)/Volumetric protection alarm system control
unit (deactivation)/Power sunroof (control unit,
control illumination)/rain sensor/daylight sensor on
driving mirror/Front seat warming activation controls F49 5 49
Air bag control unit (NAB) F50 7.5 49
Internal cooling unit system/Sound system presetting/
Connect Nav +/Blu&Me system control unit/Parking sensor
control unit (NSP)/Air quality sensor (AQS)/Automatic
air-conditioner/Electric door mirrors (moving, folding)/
Tyre pressure monitoring control unit (CPP) F51 5 49
Rear window wiper F52 15 49
155-190 BRAVO GB 10-05-2007 9:19 Pagina 186
