135TECHNICAL SPECIFICATIONS
UseOriginal fluids
and lubricants
TETELA CAR
TECHNYX
Contractual Technical
Reference N.° F010.B05
TUTELA ALL STAR
Contractual Technical
Reference N.° F702.G07
TUTELA TOP 4
Contractual Technical
Reference N.° F001.A93
PARAFLU UP
Contractual Technical
Reference N.° F101.M01
TUTELA
PROFESSIONAL
SC 35
Contractual Technical
Reference N.° F201.D02 Fluid and lubricant specifications
for correct car operation
Lubricant with synthetic basis complying with SAE 75W-85.
Performance exceeds by far the API GL-4 PLUS
and FIAT 9.55550 standards required.
Grease containing Molybdenum bisulphide for high
temperature appliances. NLGI 1-2 consistency.
Synthetic fluid, F.M.V.S.S. no. 116, DOT 4, ISO 4925,
SAE J-1704, CUNA NC 956-01
Anti-freezing safety liquid (red colour) containing
monoethylene glycol inhibited with organic formula.
Antifreeze complying with CUNA NC 956-16, ASTM D
3306 standards.
Mixture of alcohols, water and surfactants
(CUNA NC 956-11).Change
Mechanical gear and
differential gear.
Constant-velocity
joints on wheel side.
Hydraulic brakes
and clutch hydraulic
controls.
Radiator antifreeze
proportion:
50% water and 50%
PARAFLU UP (
❒)
To be used diluted
or undiluted in
windscreen/rear
window washer/
wiper systems
IMPORTANTDo not top up or mix with fluids having characteristics different from those specified.
(
❒) For particularly hard climate conditions, we recommend use of a 60% PARAFLU UP and 40% demineralized water mixture.
Lubricants and greases
for transmission
Brake fluids
Protective agent
for radiatore
Windscreen/
rear window
washer fluid
124-136 Seicento GB 22-11-2007 10:51 Pagina 135

136TECHNICAL SPECIFICATIONS
CO2EMISSIONS
The fuel consumption values shown
in the table below were defined ac-
cording to the type-approval specifi-
cations in European Directives.
Consumption values are defined by
means of the following procedures:
– an urban cycle: consisting of a
cold start and a simulated drive in city
streets;
– an extra-urban cycle: consisting
in frequent accelerations, in all gears,
simulating normal conditions of use.
Speed ranges from 0 to 120 km/h;
– average combined cyclecon-
sisting of 37% urban cycle and 63% ex-
tra-urban cycle.
FUEL CONSUMPTION
IMPORTANT Road and traffic
conditions, weather, general con-
ditions of the car, driving style,
fittings and accessories, use of
the climate control system, load,
roof racks and other situations
penalising aerodynamic penetra-
tion and effecting rolling resis-
tance will influence fuel con-
sumption rates which can be dif-
ferent from the values shown in
the table (see
CHEAP RUNNING
THAT RESPECTS THE ENVIRONMENT
in DRIVING YOUR CARchapter).
The maximum CO2emission values
shown in the following table refer to
the average combined cycle.
Consumption in accordance with Directive 1999/100/EC (litres x 100 km)
S - Active
Urban8.3
Extra-urban4.7
Combined6.0
CO2emission in
Versionsaccordance with
Directive 1999/100/EC
(g/km)
S - Active143
124-136 Seicento GB 22-11-2007 10:51 Pagina 136

138INDEX
– front bulb replacement ..... 93
– rear bulb replacement ....... 95
– side bulb replacement ....... 94
Display of fuel cut
off activated .............................. 22
Doors ........................................... 45
Driving style ................................ 74
Economical driving .................. 75
Electric power assisted
steering ...................................... 61
Electric windows ........................ 46
Electronic control units ............ 116
Engine
Engine compartment
(washing) ................................... 122
Engine coolant level ................. 111
Engine oil
Engine oil consumption ............ 111
Engine oil level ............................ 110
– consumption ......................... 111
– level check ............................. 110
– Technical specifications ...... 125
– cooling .................................... 111
– features .................................. 126
– fluid level check .................... 110
– identification code ............... 124
– on/power supply .................. 127
EOBD (System) ........................... 60
EOBD system ............................. 60
Fiat Code (The system) ......... 4
Fiat CODE system ..................... 4
Filling the tank ............................ 68
Fog lights
– control .................................... 40
– direction ................................. 54
Front air bags ............................ 56
– front air bags ......................... 56
– general information ............. 58
– passenger front air bag ....... 57
Front fog lights
– bulb replacement ................ 94
– on/off button ......................... 40
Fuel ................................................ 68
– consumption ......................... 136
– fuel cut off switch ............... 41
– gauge ....................................... 21
Fuel consumption ...................... 136
Fuel cut off switch .............. 22-41
Fuel gauge .................................... 21
Fuses ............................................. 100
Gearbox
– type ......................................... 127
– use of the gearbox ............... 72
Government homologation
(remote control) ............... 9-139
Handbrake ......................... 72-126
Hazard warning lights
– controls .................................. 40
Head restraints ........................... 30
Headlights
– angle compensation ............. 53
– light beam direction ............ 53
Heated rear window ................. 40
Heater controls .......................... 33
Heating ......................................... 33
Horn ............................................. 41
Identification data .................... 124
Ignition switch ............................ 18
In an emergency ......................... 83
Instrument panel ........................ 20
Jack
– usage ................................ 87-102
– warnings ................................. 86
Keys ........................................... 4
– duplication ............................. 7
Knowing your car ....................... 6
Lubricants (specifications) .... 136
Luggage compartment .............. 47
137-144 Seicento GB 28-11-2007 9:38 Pagina 138

140INDEX
– right lever .............................. 38
Storing the car ............................ 82
Sun roof
– electrically operated ........... 43
Sun visors .................................... 43
Suspension ................................... 127
Symbols ........................................ 4
Tank cap
Technical specifications ............ 124
Third brake lights ....................... 96
To the service station ................ 67
Tools ............................................. 86
Top speed .................................... 133
Towing the car .......................... 103
Towing trailers
– fitting diagram ........................ 78
– installation of tow hook ..... 77
– warnings ................................. 77
Transmission ............................... 126
Travelling safely and in harmony
with nature ............................... 4
Tyre inflation pressure ............. 130
Tyres
– changing a wheel ................... 87– inflation pressure ................ 130
– maintenance .......................... 117
– snow tyres ............................. 80
– types ....................................... 130
Usage conditions ..................... 75
Van ............................................. 62
Various controls ........................ 40
Vehicle inactivity ........................ 82
Ventilation ................................... 35
Warning lights ........................ 23
Weights ........................................ 132
Wheel
– maintenance .......................... 117
– replacement .......................... 87
– spare wheel ........................... 128
– types ....................................... 130
Wheel geometry ........................ 128
Windows (cleaning) .................. 122
Windscreen and rearscreen wiper
blades ......................................... 118
Windscreen washer
– controls .................................. 38– fluid level ................................ 112
Windscreen wiper
– blades ...................................... 118
– controls .................................. 38
– jets ........................................... 120
Windscreen/rearscreen
washer fluid level ..................... 112
