2007 DODGE RAM 2500 DIESEL automatic transmission

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
CONTENTS

A Word About Your Keys ..................12
▫ Ignition Key Removal ...................12
▫ Locking Doors With The Key ..............14

Steering Wheel Lock — If Equipped ..........15
▫ If You Wish To Manually Lock The
Steering Wheel ........................15
▫ To Release The Steering Wheel Lock .........15
▫ Automatic Transmission Ignition Interlock
System ..............................15

Sentry Key — If Equipped .................15 ▫
Replacement Keys ......................16
▫ Customer Key Programming ..............17
▫ General Information ....................18

Security Alarm System — If Equipped .........18
▫ Rearming Of The System .................18
▫ To Set The Alarm ......................18
▫ To Disarm The System ...................19

Illuminated Entry System — If Equipped .......19

Remote Keyless Entry — If Equipped .........20
2

A WORD ABOUT YOUR KEYS
The dealer that sold you your new vehicle has the key
code numbers for your vehicle locks. These numbers can
be used to order duplicate keys from your dealer. Ask
your dealer for these numbers and keep them in a safe
place.
Ignition Key Removal
Automatic Transmission
Place the shift lever in PARK. Turn the ignition switch to
the ACC position, push the key and cylinder inward,
rotate the key to the LOCK position, and remove the key.
Ignition KeyIgnition Switch Positions
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

STEERING WHEEL LOCK — IF EQUIPPED
Your vehicle may be equipped with a passive steering
wheel lock. This lock prevents steering the vehicle with-
out the ignition key. If the steering wheel is moved no
more than 1/2 turn in either direction and the key is not
in the ignition switch, the steering wheel will lock.
If You Wish To Manually Lock The Steering
Wheel:
With the engine running, turn the steering wheel upside
down, turn off the engine and remove the key. Turn the
steering wheel slightly in either direction until the lock
engages.
To Release The Steering Wheel Lock:
Insert the key in the ignition switch and start the engine.
If the key is difficult to turn, move the wheel slightly to
the right or left to disengage the lock.
NOTE: If you turned the wheel to the right to engage
the lock, you must turn the wheel slightly to the right to disengage it. If you turned the wheel to the left to engage
the lock, turn the wheel slightly to the left to disengage it.
Automatic Transmission Ignition Interlock System
This system prevents the key from being removed unless
the shift lever is in PARK. It also prevents shifting out of
PARK unless the key is in the ON positions, and the
brake pedal is depressed.
SENTRY KEY — IF EQUIPPED
The Sentry Key Immobilizer System prevents unautho-
rized vehicle operation by disabling the engine. The
system does not need to be armed or activated. Operation
is automatic, regardless of whether the vehicle is locked
or unlocked.
The system uses ignition keys, which have an embedded
electronic chip (transponder), to prevent unauthorized
vehicle operation. Therefore, only keys that are pro-
grammed to the vehicle can be used to start and operate
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15
2

▫Canadian Programming/Gate Programming . . 147
▫ Using HomeLink .....................148
▫ Erasing HomeLink Buttons ..............148
▫ Reprogramming a Single HomeLink Button . . . 148
▫ Security ............................149

Power Sunroof — If Equipped .............149
▫ Open Sunroof - Express Mode ............150
▫ Comfort Stop ........................150
▫ Closing Sunroof - Express ...............151
▫ Pinch Protect Feature ...................151
▫ Pinch Protect Override .................151
▫ Venting Sunroof - Express ...............151
▫ Sunshade Operation ...................151
▫ Wind Buffeting .......................152 ▫
Sunroof Maintenance ...................152
▫ Sunroof Fully Closed ...................152

Electrical Power Outlets ..................152

Cigar Lighter And Ash Receiver ............154

Cupholders ...........................155
▫ Front Instrument Panel Cupholders (40–20–40
Seats) — Automatic Transmission ..........155
▫ Front Instrument Panel Cupholders (Bucket Seats)
— Automatic Transmission ..............157
▫ Front Instrument Panel Cupholders — Manual
Transmission ........................157
▫ Rear Cupholder — Quad Cab —
If Equipped .........................158
▫ Rear Cupholder — Mega Cab ............158
80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

To decrease speed while the speed control is on, press
and hold the DECEL button. Release the button when the
desired speed is reached, and the new speed will be set.
To Accelerate For Passing
Depress the accelerator as you would normally. When the
pedal is released, the vehicle will return to the set speed.
NOTE: When driving uphill, at elevations above 2,000
ft. (610 meters), or when the vehicle is heavily loaded
(especially when towing) the vehicle may slow below the
SET speed. If the vehicle speed drops below 35 mph (56
km/h), the speed control will automatically disengage. If
this happens, you can push down on the accelerator
pedal to maintain the desired speed.
Vehicles equipped with a 6–speed manual transmission
should be operated in 4th or 5th gear under the above
conditions. Vehicles equipped with a 4–speed automatic transmis-
sion may exhibit several 4-3 downshifts under the above
conditions. To reduce the frequency of the downshifts
and to improve vehicle performance, it is advisable to
lock out overdrive by pressing the O/D OFF button
located at the end of the gear shifter.
WARNING!
Speed Control can be dangerous where the system
can’t maintain a constant speed. Your vehicle could
go too fast for the conditions, and you could lose
control. An accident could be the result. Don’t use
Speed Control in heavy traffic or on roads that are
winding, icy, snow-covered, or slippery.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135
3

CIGAR LIGHTER AND ASH RECEIVER
The removable ash receiver is located in the instrument
panel cup holder tray.
The cigar lighter is located on the instrument panel,
above and to the left of the ash receiver.
As a child safety precaution, the lighter only operates
with the ignition switch ON. It heats when pushed in and
pops out automatically when ready for use. To preserve
the heating element, do not hold the lighter in the
heating position.
Ash Tray Automatic Transmission
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CUPHOLDERS
Front Instrument Panel Cupholders (40–20–40
Seats) — Automatic Transmission
Your new Ram truck is equipped with two adjustable
cupholders. The cupholder is opened by pulling on the
cup holder door handle, on the front surface. Each
opening in the cupholder is adjustable and will hold cups
and mugs of various sizes.
To secure the cup, place the cup to be held into one of the
cup wells and then push the cupholder arm toward the
cup until it is held stable.
Ash Tray Manual Transmission
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155
3

Cup Holder Door HandleCup Holders Automatic Transmission
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
