MIRRORS
Inside Day/Night Mirror
Adjust the mirror to center on the view through the rear
window. A two-point pivot system allows for horizontal
and vertical mirror adjustment.
Annoying headlight glare can be reduced by moving the
small control under the mirror to the night position
(toward rear of vehicle). The mirror should be adjusted
while set in the day position (toward windshield).
Automatic Dimming Inside Mirror — If Equipped
This mirror automatically adjusts for annoying headlight
glare from vehicles behind you. You can turn the feature
on or off by pressing the button at the base of the mirror.
A light in the button will indicate when the dimming
feature is activated.
Adjusting Rearview MirrorAutomatic Dimming Mirror
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 67
3

CAUTION!
To avoid damage to the mirror during cleaning,
never spray any cleaning solution directly onto the
mirror. Apply the solution onto a clean cloth and
wipe the mirror clean.
Outside Mirrors
To receive maximum benefit, adjust the outside mirror(s)
to center on the adjacent lane of traffic and a slight
overlap of the view obtained from the inside mirror.
NOTE:The passenger side convex outside mirror will
give a much wider view to the rear, and especially of the
lane next to your vehicle.
WARNING!
Vehicles and other objects seen in the passenger side
convex mirror will look smaller and farther away
than they really are. Relying too much on your
passenger side convex mirror could cause you to
collide with another vehicle or other object. Use your
inside mirror when judging the size or distance of a
vehicle seen in the passenger side convex mirror.
Exterior Mirrors Folding Feature — If Equipped
Some models have exterior mirrors that are hinged. The
hinge allows the mirror to pivot forward and rearward to
resist damage. The hinge has three detent positions, full
forward, full rearward, and normal.
Driver’s Side Outside Mirror Auto Dimmer — If
Equipped
This mirror automatically adjusts for annoying headlight
glare from vehicles behind you. You can turn this feature
on or off by pressing the button at the base of the Inside
Rearview Mirror.
68 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

HANDS–FREE COMMUNICATION (UConnect™) —
IF EQUIPPED
UConnect™ is a voice-activated, hands-free, in- vehicle
communications system. UConnect™ allows you to dial
a phone number with your cellular phone using simple
voice commands (e.g.,Call”“Mike””WorkorDial”
“248-555-1212). Your cellular phone’s audio is trans-
mitted through your vehicle’s audio system; the system
will automatically mute your radio when using the
UConnect™ system.
NOTE:The UConnect™ system use requires a cellular
phone equipped with the BluetoothHands-Free Profile,
version 0.96 or higher. See www.chrysler.com/uconnect
for supported phones.
UConnect™ allows you to transfer calls between the
system and your cellular phone as you enter or exit your
vehicle, and enables you to mute the system’s micro-
phone for private conversation.
The UConnect™ phonebook enables you to store up to 32
names and four numbers per name. Each language has a
separate 32-name phonebook accessible only in thatlanguage. This system is driven through your Blue-
tooth™ Hands-Free profile cellular phone. UConnect™
features Bluetooth™ technology - the global standard
that enables different electronic devices to connect to
each other without wires or a docking station, so UCon-
nect works no matter where you stow your cellular
phone (be it your purse, pocket, or briefcase), as long as
your phone is turned on and has been paired to the
vehicle’s UConnect™ system. The UConnect™ system
allows up to seven cellular phones to be linked to system.
Only one linked (or paired) cellular phone can be used
with the system at a time. The system is available in
English, Spanish, or French languages (as equipped).
The rearview mirror contains the microphone for the
system and the control buttons that will enable you to
access the system.
70 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

and MoparTotal Clean or equivalent. Care should be
taken to avoid soaking your leather upholstery with any
liquid. Please do not use polishes, oils, cleaning fluids,
solvents, detergents, or ammonia-based cleaners to clean
your leather upholstery. Application of a leather condi-
tioner is not required to maintain the original condition.
WARNING!
Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in
closed areas they may cause respiratory harm.
Cleaning Headlights
Your vehicle has plastic headlights that are lighter and
less susceptible to stone breakage than glass headlights.
Plastic is not as scratch resistant as glass and therefore
different lens cleaning procedures must be followed.
To minimize the possibility of scratching the lenses and
reducing light output, avoid wiping with a dry cloth. To
remove road dirt, wash with a mild soap solution fol-
lowed by rinsing.Do not use abrasive cleaning components, solvents, steel
wool or other aggressive material to clean the lenses.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with MoparGlass Cleaner or any commercial
household-type glass cleaner. Never use an abrasive type
cleaner. Use caution when cleaning the inside rear win-
dow equipped with electric defrosters or the right rear
quarter window equipped with the radio antenna. Do
not use scrapers or other sharp instruments, which may
scratch the elements.
When cleaning the rear view mirror, spray cleaner on the
towel or rag that you are using. Do not spray cleaner
directly on the mirror.
Cleaning Plastic Instrument Cluster Lenses
The lenses in front of the instruments in this vehicle are
molded in clear plastic. When cleaning the lenses, care
must be taken to avoid scratching the plastic.
MAINTAINING YOUR VEHICLE 335
7

Cavity Car-
tridge
FuseMini
FuseDescription
33 — — —
34 — — —
35 — 5 Amp
OrangeAmplifier - if equipped/
Antenna/Ignition
Delay/Overhead
Console/Passenger Door
Lock & Express Power
Window Switch - if
equipped/Power Mir-
rors - if equipped/Rear
Defrost
36 — 20 Amp
YellowHands Free Phone - if
equipped/Media System
Monitor DVD - if
equipped/Radio/
Satellite Receiver - if
equipped
37 — 15 Amp
BlueTransmission - NAG1Cavity Car-
tridge
FuseMini
FuseDescription
38 — 5 Amp
OrangeOverhead Console
39 — 10 Amp
RedHeated Mirrors - if
equipped
40 — 5 Amp
OrangeHeated Seats - if
equipped/Inside Rear-
view Mirror
41 — 10 Amp
RedAC Heater Control/Tire
Pressure Monitoring - if
equipped
42 30 Amp
Pink— Front Blower Motor
43 30 Amp
Pink— Amplifier - if equipped/
Antenna/Rear Defrost
44 20 Amp
Blue— Amplifier - if equipped/
Front Control Module
(FCM)/Sunroof - if
equipped
342 MAINTAINING YOUR VEHICLE

Heater, Engine Block.................... 211
High Beam/Low Beam Select (Dimmer) Switch . 99
Hitches
TrailerTowing ....................... 273
Holder,Cup ........................... 121
HomeLink(Garage Door Opener) Transmitter . 110
Hood Release.......................... 95
Hoses............................... 327
Ignition............................... 11
Key ................................ 11
Ignition Key Removal.................... 11
IlluminatedEntry ....................... 17
Immobilizer (Sentry Key).................. 13
Infant Restraint......................... 51
Inflation Pressure Tires................... 145
Information Center, Vehicle............... 148
Inside Rearview Mirror................... 67
Instrument Cluster................138,139,140
Instrument Panel and Controls............. 137
Instrument Panel Lens Cleaning............ 335
Interior Appearance Care................. 334
Interior Fuses.......................... 337InteriorLights ......................... 100
Intermittent Wipers (Delay Wipers).......102,201
Introduction............................ 4
Jack Location.......................... 287
Jack Operation......................... 289
Jacking Instructions..................... 289
Jump Starting......................... 294
Key, Programming....................... 14
Key, Replacement....................... 14
Key, Sentry (Immobilizer).................. 13
Key-In Reminder........................ 12
Keyless Entry System..................... 17
Keys................................. 11
Knee Bolster........................... 41
Lane Change and Turn Signals.............. 99
Lap/Shoulder Belts...................... 33
LATCH (Lower Anchors and Tether for
CHildren) ........................... 54,55
LatchPlate ............................ 34
Latches............................... 61
388 INDEX

Load Leveling System................... 131
Loading Vehicle.....................267,268
Capacities........................... 268
Tires ............................... 240
Locks................................ 22
AutoUnlock ......................... 25
ChildProtection ....................... 25
Door............................... 22
Power Door.......................... 23
Low Tire Pressure System................ 254
Lower Anchors and Tether for CHildren
(LATCH)............................ 54,55
Lubrication, Body....................... 320
Luggage Rack (Roof Rack)................ 129
Lumbar Support........................ 92
Maintenance Free Battery................. 316
Maintenance Procedures.................. 309
Maintenance Schedule................... 354
Schedule “A”........................ 367
Schedule “B”........................ 357
Malfunction Indicator Light (Check Engine) . 147,307
Manual, Service........................ 377Methanol............................. 262
Mini-Trip Computer..................... 150
Mirrors ............................... 67
AutomaticDimming .................... 67
Electric Remote....................... 69
ExteriorFolding ....................... 68
Heated.............................. 69
Outside ............................. 68
Rearview............................ 67
Vanity .............................. 69
Modifications/Alterations, Vehicle............ 7
Monitor, Tire Pressure System............. 254
Mopar Parts........................308,376
MTBE/ETBE.......................... 262
Multi-Displacement Engine System.......... 230
Multi-Function Control Lever............... 99
Navigation Radio....................... 179
Navigation System...................... 179
NewVehicleBreak-InPeriod ............... 59
Occupant Restraints...................... 33
Octane Rating, Gasoline (Fuel)............. 261
390 INDEX

Odometer............................ 140
Trip ............................... 140
Oil, Engine.........................309,351
Capacity............................ 350
Change Interval...................... 311
Checking........................309,310
Dipstick .........................309,310
Disposal............................ 313
Filter...........................314,351
Filter Disposal....................... 313
Identification Logo.................... 312
Materials Added to.................... 313
Recommendation.................. 311,350
Synthetic........................... 313
Viscosity.........................312,350
Onboard Diagnostic System............306,307
Opener, Garage Door (HomeLink) ......... 110
Operating Precautions................... 306
Outside Rearview Mirrors................. 68
Overdrive............................ 216
Overhead Console...................... 109
Overheating, Engine..................141,284
Owner’s Manual (Operator Manual)......... 377Panic Alarm........................... 20
Parking Brake......................... 225
ParkingOnHill ........................ 225
Passing Light........................... 99
Pedals, Adjustable...................... 105
Personal Settings....................... 156
Pets .................................. 58
Phone, Cellular......................... 70
Phone, Hands-Free (UConnect™)............ 70
Placard, Tire and Loading Information....... 240
Power
Brakes............................. 226
Distribution Center (Fuses).............. 337
Door Locks.......................... 23
Mirrors ............................. 69
Outlet (Auxiliary Electrical Outlet)........ 118
Seats............................... 90
Steering .........................229,319
Steering, Checking.................... 319
Sunroof............................ 115
Windows............................ 27
Pregnant Women and Seat Belts............. 40
Preparation for Jacking................... 286
INDEX 391
10
