These power distribution centers house new plug-in
“Cartridge” fuses which replace all the in-line fusible
links previously used. The power distribution centers
also contain “Mini”fuses and plug-in “ISO” relays. These
fuses and relays can be obtained from your dealer.
CavityCartridge
FuseMini
FuseDescription
1 Spare
2 40 Amp
GreenIgnition Accessory
(ACC)
3 30 Amp
PinkElectric Brake
4 50 Amp
RedPower Seat
5 40 Amp
GreenIgnition Run Only
6 20 Amp
YellowIgnition Off Draw (IOD)
Cabin Compartment
Node (CCN), Radio
CavityCartridge
FuseMini
FuseDescription
7 10 Amp
RedPowertrain Control Mod-
ule (PCM)/Fuel/
RAD/AC Coils
8 10 Amp
RedCabin Compartment
Node (CCN)/Mirror/4x4
9 10 Amp
RedAirbag System #3
10 Spare
11 10 Amp
RedAC Clutch
12 15 Amp
BlueT Tow Lt Stop/Turn
13 15 Amp
BlueTrailer Tow Rt Stop/
Turn
14 20 Amp
YellowIgnition Off Draw (IOD)
#2
15 25 Amp
NaturalTrans/Powertrain Con-
trol Module (PCM)
