▫Anti-Lock Brake System — If Equipped.....214
Power Steering........................217
Multi Displacement System (MDS) -
5.7L Engine Only
......................218
Traction Control System (TCS) — If Equipped....218
Brake Assist System (BAS) — If Equipped....220
Electronic Stability Program (ESP) —
If Equipped
..........................221
▫Synchronizing ESP....................223
▫ESP/BAS Malfunction Indicator And ESP/TCS
Indicator Lights......................223
Tire Safety Information..................224
▫Tire Markings........................224
▫Tire Identification Number (TIN)..........227
▫Tire Loading And Tire Pressure...........228
Tires — General Information..............232
▫Tire Pressure.........................232▫Tire Inflation Pressures.................233
▫Radial-Ply Tires......................235
▫Compact Spare Tire — If Equipped.........235
▫Limited Use Spare — If Equipped.........236
▫Tire Spinning........................236
▫Tread Wear Indicators..................237
▫Life Of Tire.........................238
▫Replacement Tires.....................238
▫Alignment And Balance.................239
Self–Sealing Tires — If Equipped..........240
Tire Chains...........................240
Snow Tires...........................241
Tire Rotation Recommendations...........241
Tire Pressure Monitor System (TPMS) —
If Equipped
..........................242
▫Base System — If Equipped..............245
192 STARTING AND OPERATING

acceleration, ease up on the accelerator and apply as little
throttle as possible. Be sure to adapt your speed and
driving to the prevailing road conditions.
The TCS OFF button is located in the center of the
instrument panel. To turn OFF the TCS, momentarily
press the button and the TCS Indicator Light will illumi-
nate. To turn the system ON again, momentarily press
the TCS OFF button and the indicator light will turn OFF.NOTE:To improve the vehicle’s traction when driving
with snow chains, or starting off in deep snow, sand, or
gravel, switch off the TCS by pressing the TCS OFF
button.
CAUTION!
When the TCS Indicator Light is illuminated con-
tinuously, the TCS is switched off. Avoid spinning
one drive wheel. This may cause serious damage to
the drive train.
NOTE:
•
The Traction Control System comes on each time the
ignition switch is turned ON. This will occur even if
you used the Traction Control Button to turn OFF the
system.
•The Traction Control System will make buzzing or
clicking sounds when in operation.
STARTING AND OPERATING 219
5

The ESP OFF button is located in the center of the
instrument panel. To turn OFF the ESP, momentarily
press the ESP OFF button and the ESP/TCS Indicator
Light will illuminate. To turn the system ON again,
momentarily press the ESP OFF button and the indicator
light will turn OFF.
NOTE:To improve the vehicle’s traction when driving
with snow chains, or starting off in deep snow, sand, or
gravel, switch off the ESP by pressing the ESP OFF
button.When ESP is switched off, the engine torque reduction
feature is cancelled. Therefore, the enhanced vehicle
stability offered by ESP is unavailable. However, a fea-
ture of the system remains active. This feature controls
wheel spin across an axle quite similarly to a limited slip
differential. If one wheel on an axle is spinning faster
than the other, the system will apply the brake of the
spinning wheel and allow more engine torque to be
applied to the wheel that is not spinning. This wheel slip
control is active at vehicle speeds between approximately
24 mph (40 km/h) and 50 mph (80 km/h).
CAUTION!
When the ESP/TCS Indicator Light is illuminated
continuously, the ESP is switched off. Avoid spin-
ning one drive wheel. This may cause serious dam-
age to the drive train.
222 STARTING AND OPERATING

NOTE:In order to avoid damage to tires, chains, and
your vehicle do not drive for a prolonged period of time
on dry pavement. Observe the tire chain manufacturer’s
instructions on method of installation, operating speed,
and conditions for usage.
Always use the lower suggested operating speed if both
the chain manufacturer and vehicle manufacture suggest
a maximum speed. This notice applies to all chain
traction devices, including link and cable (radial) chains.
SNOW TIRES
Some areas of the country require the use of snow tires
during winter. Standard tires are of the all season type
and satisfy this requirement as indicated by the M+S
designation on the tire sidewall.
If you need snow tires, select tires equivalent in size and
type to the original equipment tires. Use snow tires only
in sets of 4, failure to do so may adversely affect the
safety and handling of your vehicle.Snow tires generally have lower speed ratings than what
was originally equipped with your vehicle and should
not be operated at sustained speeds over 75 mph (120
km/h).
TIRE ROTATION RECOMMENDATIONS
Tires on the front and rear axles of vehicles operate at
different loads and perform different steering, driving,
and braking functions. For these reasons, they wear at
unequal rates, and tend to develop irregular wear pat-
terns.
These effects can be reduced by timely rotation of tires.
The benefits of rotation are especially worthwhile with
aggressive tread designs such as those on all season type
tires. Rotation will increase tread life, help to maintain
mud, snow, and wet traction levels, and contribute to a
smooth, quiet ride.
STARTING AND OPERATING 241
5

Untwisting Procedure................... 39
Seats................................. 88
Adjustment.......................... 88
Heated.............................. 91
Lumbar Support....................... 90
Power.............................. 89
Rear Folding......................... 93
Reclining............................ 90
Security Alarm (Theft Alarm)............15,135
Selection of Coolant (Antifreeze).........309,338
Self-Sealing Tires....................... 240
Sentry Key (Immobilizer).................. 13
Service Assistance...................... 362
Service Contract........................ 364
Service Engine Soon Light
(Malfunction Indicator).................. 136
Service Manuals........................ 365
Setting the Clock.................152,158,169
Settings, Personal....................... 146
Shifting.............................. 197
Automatic Transmission..........197,200,205
Shoulder Belt Upper Anchorage............. 38
Shoulder Belts.......................... 34Side Airbag............................ 47
Signals, Turn........................98,131
Slippery Surfaces, Driving On............. 212
Snow Chains (Tire Chains)................ 240
Snow Tires............................ 241
Spare Tire.......................235,236,275
Spark Plugs........................... 300
Speed Control (Cruise Control)............. 105
Speedometer.......................... 129
Starting.............................. 194
Automatic Transmission................ 195
Engine Fails to Start................... 195
Starting and Operating................... 194
Starting Procedures..................... 194
Steering
Column Controls...................... 98
Linkage............................ 306
Power...........................217,305
Tilt Column......................... 103
Wheel, Tilt.......................... 103
Steering Wheel Mounted Sound
System Controls........................ 176
Storage...........................120,329
INDEX 381
10

Storage, Vehicle.....................188,329
Storing Your Vehicle..................... 329
Sun Roof............................. 114
Sunglasses Storage...................... 109
Supplemental Restraint System - Airbag....... 42
Synthetic Engine Oil..................... 299
System, Navigation..................... 168
Tachometer........................... 129
Telescoping Steering Column.............. 103
Temperature Control, Automatic (ATC)....... 182
Temperature Gauge, Engine Coolant......130,273
Tether Anchor, Child Restraint.............. 54
Theft Alarm (Security Alarm)............... 15
Theft System (Security Alarm).............. 15
Tilt Steering Column.................... 103
Tire and Loading Information Placard....... 228
Tire Identification Number (TIN)........... 227
Tire Markings......................... 224
Tire Safety Information................... 224
Tires ...........................61,232,366
Aging (Life of Tires)................... 238
Air Pressure......................... 232Alignment.......................... 239
Chains............................. 240
Changing........................274,277
Compact Spare....................... 235
Flat Changing........................ 274
General Information................... 232
High Speed......................... 234
Inflation Pressures.................... 233
Jacking..........................274,277
Life of Tires......................... 238
Load Capacity....................228,229
Pressure Monitor System (TPMS)......... 242
Quality Grading...................... 366
Radial............................. 235
Replacement......................... 238
Rotation............................ 241
Safety...........................224,232
Self-Sealing.......................... 240
Sizes............................... 225
Snow Tires.......................... 241
Spare Tire........................... 275
Spinning............................ 236
Tread Wear Indicators.................. 237
382 INDEX
