2007 DODGE CARAVAN windshield wipers

Lights ...............................150
▫ Interior Lights .......................151
▫ Park Lights ..........................151
▫ Headlights ..........................151
▫ Automatic Headlights — If Equipped .......153
▫ Daytime Running Lights (Canada/Fleet Vehicles
Only) ..............................153
▫ Lights-On Reminder ...................153
▫ Battery Protection .....................153
▫ Headlamp Delay — If Equipped ..........154
▫ Front Fog Lights — If Equipped ...........154

Multifunction Lever .....................155
▫ Turn Signals .........................155 ▫
Headlight Low/High Beam Selector Switch . . . 156
▫ Passing Light ........................156
▫ Windshield Wipers And Washers ..........156

Tilt Steering Column — If Equipped .........158

Traction Control Switch — If Equipped .......158

Rear Park Sense System — If Equipped .......159

Adjustable Pedals — If Equipped ...........163

Electronic Speed Control — If Equipped ......164
▫ To Activate ..........................165
▫ To Set At A Desired Speed ...............165
▫ To Deactivate ........................165
▫ To Resume Speed .....................165
▫ To Vary The Speed Setting ...............166
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93
3

Headlight Low/High Beam Selector Switch
Pull the multifunction lever toward the steering wheel to
switch the headlights between HIGH and LOW beam.
Passing Light
You can signal another vehicle with your headlights by
lightly pulling the multifunction lever toward the steer-
ing wheel. This will cause the headlights to turn on at
high beam and remain on until the lever is released.
Windshield Wipers and Washers
The wipers and washers are operated by a switch in the
multifunction lever. Rotate the end of the lever to select
the desired wiper speed.
NOTE: Always remove any build-up of snow that
prevents the windshield wiper blades from returning to
the OFF position. If the windshield wiper switch is
turned OFF and the blades cannot return to the OFF
position, damage to the wiper motor may occur. To use the washer, press the end of the multifunction
lever in when spray is desired, the washers will spray for
a maximum of 20 seconds or until the lever is released. If
another washer cycle is desired the end of the lever must
be pressed again to get another 20 second washer cycle. If
the lever is depressed while in the delay range, the
Windshield Wiper/Washer Control
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

wipers will operate for several seconds after the lever is
released, and then resume the intermittent interval pre-
viously selected.
If the end of the lever is depressed while in the OFF
position, the wipers will operate for approximately two
wipe cycles, then turn OFF.
WARNING!
Sudden loss of visibility through the windshield
could lead to an accident. You might not see other
vehicles or other obstacles. To avoid sudden icing of
the windshield during freezing weather, warm the
windshield with defroster before and during wind-
shield washer use.
Intermittent Wiper System
Use the intermittent wipers when weather conditions
make a single wiping cycle, with a variable pause be-
tween cycles, desirable.
Rotate the end of the lever to the first detent position,
then turn the end of the lever to select the desired delay
interval. The delay can be regulated from a maximum of
about 20 seconds between cycles, to a cycle every 2
seconds. The time delay will be doubled if the vehicle
speed is less than 10 mph (16 km/h).
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157
3

Rear Wiper Operation — Automatic Temperature
Control Only
Press this button to have the rear wiper have a
continuous wipe. When the ignition switch is in the
ON/RUN position, the rear wiper switch position as well
as an indicator light will show that the wiper is ON.
Intermittent Rear Wiper Operation — Automatic
Temperature Control Only
When this button is pressed and the ignition
switch is in the ON position, the rear wiper will
operate at a fixed interval of about 8 seconds. As
vehicle speed increases, the time delay will shorten. The
switch position as well as an indicator light will show
when the wiper is ON.
Rear Washer Operation — Automatic
Temperature Control Only
Press and hold the button as long as spray is
desired. If the switch is depressed while the wipers
are on, the wipers will operate for a few seconds
after the switch is released then resume the previously set
mode of intermittent wiper or continuous wipe. If the
switch is depressed when the wipers are off, the wipers
will operate for two cycles, then turn off.
NOTE: The washers will stop spraying if the switch is
pressed longer than 10 seconds.
Adding Washer Fluid
The fluid reservoir for the windshield washers and the
rear window washer is shared. It is located in the front of
the engine compartment on the passenger side and
should be checked for fluid level at regular intervals. Fill
UNDERSTANDING YOUR INSTRUMENT PANEL 303
4

The external lock cylinders should be lubricated twice a
year, preferably in the fall and spring. Apply a small
amount of a high quality lubricant such as Mopar Lock
Cylinder Lubricant directly into the lock cylinder.
Windshield Wiper Blades
The rubber edges of the wiper blades and the windshield
should be cleaned periodically with a sponge or soft cloth
and a mild nonabrasive cleaner. This will remove accu-
mulations of salt or road film.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield. Avoid using the wiper blades to remove frost or ice from
the windshield. Keep the blade rubber out of contact with
petroleum products such as engine oil, gasoline, etc.
Windshield and Rear Window Washers
The fluid reservoir for the windshield washers and the
rear window washer is shared. It is located in the engine
compartment and should be checked for fluid level at
regular intervals. Fill the reservoir with windshield
washer solvent (not radiator antifreeze) and operate the
system for a few seconds to flush out the residual water.
The washer fluid reservoir will hold a full gallon of fluid
when the Low Washer Fluid Light illuminates.
432 MAINTAINING YOUR VEHICLE

Wheel and Wheel Trim.................... 448
Wheel and Wheel Trim Care ................ 448
Wheel Bearings ......................... 446
Wind Buffeting ....................... 33,184
Window Fogging ........................ 300
Windows .............................. 31
Power ............................... 32
Rear Vent .......................... 31,32 Windshield Washers
................... 156,432
Windshield Wiper Blades .................. 432
Windshield Wipers ....................... 156
Wiper Blade Replacement .................. 432
Wiper, Rear ............................ 303
Wipers, Intermittent ...................... 157
Zone Control (Temperature Control) .......... 279
514 INDEX
