2007 DODGE CARAVAN fuses

WARNING!
•You need proper knee impact protection in a
collision. Do not mount or locate any aftermarket
equipment on or behind the knee bolsters.
•It is dangerous to try to repair any part of the
airbag system yourself. Be sure to tell anyone who
works on your vehicle that it has airbags.
NOTE: Perchlorate Material — special handling may
apply. See www.dtsc.ca.gov/hazardouswaste/
perchlorate
Airbag Light
You will want to have the airbags ready to
inflate for your protection in a collision. While
the airbag system is designed to be mainte-
nance free, if any of the following occurs, have
an authorized dealer service the system immediately.
•The AIRBAG light does not come on or flickers during
the 6 to 8 seconds when the ignition switch is first
turned on.
•The light remains on or flickers after the 6 to 8 second
interval.
•The light flickers or comes on and remains on while
driving.
NOTE: If the speedometer, tachometer or any engine
related gauges are not working, the airbag control mod-
ule may also be disabled. The airbags may not be ready
to inflate for your protection. Promptly check fuse block
for blown fuses. Refer to the label located on the inside of
the fuse block cover for the proper airbag fuses. See your
dealer if the fuse is good.
72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

▫Front Suspension Ball Joints ..............430
▫ Steering Shaft Seal ....................431
▫ Steering Linkage ......................431
▫ Drive Shaft Universal Joints ..............431
▫ Body Lubrication .....................431
▫ Windshield Wiper Blades ................432
▫ Windshield And Rear Window Washers .....432
▫ Exhaust System ......................433
▫ Cooling System .......................434
▫ Hoses And Vacuum/Vapor Harnesses .......439
▫ Brakes .............................439
▫ Master Cylinder — Brake Fluid Level Check . . 441
▫ Fuel System Hoses ....................442 ▫
Automatic Transmission ................442
▫ Front And Rear Wheel Bearings ...........446
▫ Appearance Care And Protection From
Corrosion ...........................446
▫ Cleaning The Instrument Panel And Underseat
Cup Holders ........................450

Fuses — Integrated Power Module ..........452

Vehicle Storage ........................455

Replacement Light Bulbs .................455

Bulb Replacement ......................456
▫ Headlights ..........................456
▫ Front Park/Turn Signal And Sidemarker
Lights .............................458
▫ Fog Lights ..........................459
412 MAINTAINING YOUR VEHICLE

FUSES — INTEGRATED POWER MODULE
An Integrated Power Module (IPM) located in the engine
compartment near the battery. This center contains car-
tridge fuses and mini fuses. A label that identifies each
component may be printed on the inside of the cover.
Refer to the graphic below for FUSES/IPM location.Cavity Cartridge Fuse Description
F4 30 Amp Pink Front Wipers
F9 40 Amp Green Anti-Lock Brake System
(ABS) Pump
F10 40 Amp Green Front Blower
F13 40 Amp Green Electronic Back Light (EBL)
F19 40 Amp Green Body Control Module
(BCM) Feed 1
F20 30 Amp Pink Central Amplifier
F22 30 Amp Pink Seats
F27 40 Amp Green Radiator Fan
Integrated Power module (IPM)
452 MAINTAINING YOUR VEHICLE

The Heated Mirrors, Lower Instrument Panel Power
Outlet and Removable Floor Console, when in the front
position are fused with self resetting fuses that are only
serviceable by an authorized dealer. The power seats are
fused by a 30 Amp circuit breaker located under the
driver’s seat. The Power Windows are fused by a 25 Amp
circuit breaker located under the instrument panel near
the steering column. If you experience temporary or
permanent loss of these systems see your authorized
dealer for service.
VEHICLE STORAGE
If you are leaving your vehicle dormant for more than 21
days you may want to take steps to protect your battery.
You may:
•Remove the 20 Amp mini fuse in the Integrated Power
Module labeled Ignition-Off Draw (IOD).
•Or, disconnect the negative cable from the battery.
•Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
insure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
REPLACEMENT LIGHT BULBS
LIGHT BULBS — Interior Bulb Number
Center & Rear Dome Light .................. 578
Center & Rear Reading Lights ............... 578
Front Door Courtesy Light .................. 578
Front Header Reading Lights — If Equipped ..... 578
Instrument Cluster Lights .................PC74
Liftgate Light(s) .......................... 578
Overhead Console Reading Lights ..........PC579
Removable Console Light — If Equipped ....... 194
Visor Vanity Lights .................... 6501966
MAINTAINING YOUR VEHICLE 455
7

Fold in Floor (Stown Go) Seating........... 129
Freeing A Stuck Vehicle ................... 407
Fuel ................................. 353
Adding ............................. 357
Additives ............................ 355
Clean Air ............................ 354
Filler Cap (Gas Cap) .................... 357
Gasoline ............................ 353
Gauge .............................. 211
Hoses .............................. 442
Light ............................... 212
Octane Rating ...................... 353,462
Requirements ...................... 353,461
Tank Capacity ........................ 461
Fuel, Flexible ............. See Flexible Fuel Vehicles
Fuel System Caution ..................... 356
Fueling ............................... 357
Fuses ................................ 452 Garage Door Opener (HomeLink
) ........... 177
Gas Cap (Fuel Filler Cap) ............357,359,416
Gasoline, Clean Air ...................... 354
Gasoline (Fuel) ......................... 353
Gasoline, Reformulated ................... 354
Gauges Coolant Temperature .................... 216
Fuel ................................ 211
Speedometer ......................... 213
Tachometer .......................... 215
Gearshift .............................. 317
General Information ...............18,25,123,353
Glass Cleaning .......................... 449
Grocery Bag Retainer ..................... 144
Gross Axle Weight Rating ...............364,368
Gross Vehicle Weight Rating .............364,368
Hands-Free Phone (UConnect™) ............. 100
Hazard Warning Flasher ................... 384
502 INDEX

Head Phones........................... 268
Head Restraints ......................... 125
Headlights ............................ 151
Bulb Replacement ...................... 456
High Beam/Low Beam Select Switch ........ 156
Lights On Reminder .................... 153
Replacing ............................ 456
Time Delay .......................... 154
Heated Seats ........................... 126
Heater ............................... 278
Heater, Engine Block ..................... 315
Hitches Trailer Towing ........................ 371
HomeLink (Garage Door Opener) Transmitter . . . 177
Hood Release .......................... 149
Hook, Coat ............................ 198
Hoses ............................. 439,442
Ignition ............................... 12 Key ................................. 12
Ignition Key Removal ..................... 12
Illuminated Entry ........................ 20
Immobilizer (Sentry Key) ................... 15
Indicator, Traction Control ................. 218
Infant Restraint ........................ 75,76
Information Center ...................... 172
Information Center, Vehicle ................. 172
Inside Rearview Mirror .................... 96
Instrument Cluster ................. 209,210,211
Instrument Panel and Controls .............. 208
Instrument Panel Lens Cleaning ............. 450
Integrated Child Seat ...................... 74
Integrated Power Module (Fuses) ............ 452
Interior Appearance Care .................. 448
Interior Lights ....................... 151,152
Intermittent Wipers (Delay Wipers) .....157,301,303
Introduction ............................. 4
INDEX 503
10

Filter............................ 423,462
Filter Disposal ........................ 423
Identification Logo ..................... 422
Materials Added to ..................... 423
Recommendation ................... 421,461
Synthetic ............................ 423
Viscosity .......................... 422,461
Onboard Diagnostic System ..............416,417
Opener, Garage Door (HomeLink ) ........... 177
Outside Rearview Mirrors ................96,97
Overdrive ............................. 318
Overhead Console ....................... 167
Overhead Travel Information Center .......... 167
Overheating, Engine ................... 216,385
Owner’s Manual (Operator Manual) .......... 490
Panic Alarm ............................ 23
Park Sense System, Rear ................... 159
Parking Brake .......................... 319 Parking On Hill
......................... 320
Passing Light ........................... 156
Pedals, Adjustable ....................... 163
Pets, Transporting ........................ 83
Phone, Cellular ......................... 100
Phone, Hands-Free (UConnect™) ............ 100
Placard, Tire and Loading Information ......... 332
Power Brakes .............................. 321
Distribution Center (Fuses) ............... 452
Door Locks ........................... 28
Lift Gate ............................. 41
Mirrors .............................. 98
Outlet (Auxiliary Electrical Outlet) .......... 185
Seats ............................... 124
Sliding Door .......................... 35
Steering ............................. 325
Steering, Checking ..................... 430
Sunroof ............................. 183
INDEX 507
