2007 CITROEN XSARA PICASSO service

2
successive presses on the end of the wiper control at the steering wheel).
Press for at least two seconds :display disappears.
One press on any button brings the display back.
Escape button: Esc
Short press: cancels the current operation or warning message and returns you to the previous menu.
Press for at least two seconds :return to the main menu.
This button can be used to exit from any menu.
Menu button: menu
This button gives access to the main menu.
It can be used at any time.
Introduction
The On-board Navigation system guides you to the destination of your choice, by means of voice messages and visual instructions.
The system uses a cartographic database and GPS satellite guidance, the latter enabling your position to be plotted by means of several satellites.On-board Navigation comprises the following components:
- the remote control,
- the control panel display,
- the electronic control unit,
- the CD Rom,
- the last voice message recall command,
- the satellite receiver aerial.
Speci c functions or services may vary depending on the CD ROM version or on the country where the system is to be used.
For safety reasons, drivers are recommended not to use the remote control when the vehicle is moving, but to park safely and legally before modifying parame-ters or inputting data.
The system may be affected by disturbance or interruption in certain conditions (for example under bridges or in underground car parks, etc.).
The remote control
When pointed towards the right hand screen, the remote control allows you to select the information contained in the different displays.
Direction arrows :
These allow you to move around the screen and thus to choose functions.
Validate button: VAL
Validates the function or letter chosen.
Enables you, during navigation , to access the Rapid Tools menu.
Mode button: MOD
Short press: each successive press allows you to select from the types of information permanently displayed on the right hand side of the screen: date, navigation, trip computer and audio system (trip computer infor-mation can also be accessed by
T H E O N - B O A R D N A V I G AT I O N S Y S T E M

5
Navigation is an electronic help system. It cannot replace the driver's decisions.All guidance instructions must be carefully checked by the user.Main menu
Configure display
Navigation options
Navigation/Guidance
Select a service
Select destination from memory Go back to current guidance
Main menu
Switch on the ignition.
Press the “MENU” button to access the main menu.
Select a function using the direc-tion arrows, then validate your choice (“VAL” button).
Navigation/guidance
Following the selection of “Navigation/guidance” the screen will warn you about the use of navi-gation. Respect the regulations in force and do not use the remote control when your vehicle is moving.
Press the “VAL” button to progress to the next menu.
The “Navigation/guidance” menu offers you several options:
- entering the address of a new destination,
- selecting a service (hotel, railway station, airport, etc.) at a specifi c town,
- selecting a stored address from one of the two directories,
- resuming a guidance that was previously interrupted or ending a guidance in progress.
Two messages may be displayed depending on previous actions: “Resume guidance” or “Stop guidance”.
A press on the “ESC” button allows you, after a validation, to suspend a guidance in progress and return to the main menu.
T H E O N - B O A R D N A V I G AT I O N S Y S T E M

8
Selecting a service
The last-entered address is displayed.There are 3 ways you can defi ne the area in which you wish to obtain a service:
- retain the last-entered address using the “Validate” function.
- enter a new address using the “Change” function.
- automatically enter the area you are in, using the “Current loca-tion” function.
When you have validated the address, choose a service from the list using the direction arrows.
Press the “VAL” button to select one of them.
The cursor on the left-hand side of the screen indicates your position in the total list of services.
The system provides a list of addresses in increasing order of distance.
The fi rst address for the desired service is displayed.
An indication on the right of the screen (e.g. 1/50) tells you if there are several establishments (maximum of 50) offering the same service within roughly a thirty mile (50 km) radius.
A signal in the top left of the screen (e.g. 280 m) tells you how far you are from the chosen establishment (280 metres).
Use “Next” or “Previous” function to consult the list.
When your chosen establishment is displayed, select the “Validate” function then press the “VAL” button. Select a navigation para-meter.
Guidance commences, follow the instructions.
Select a service
City Street
ChangeCurrent location
Conference centres Ferry terminalsGolf coursesHistorical monuments
Validate Previous Hotels
T H E O N - B O A R D N A V I G AT I O N S Y S T E M

19R D S S Y S T E M
TRAFFIC INFORMATION
Your system allows you to receive traffi c information broadcasts even while listening to another audio source.
Press the “TA” button (K).
While a traffi c information message is being broadcast :
- The radio or CD makes a pause.
Once the message has been broadcast, the system will revert to its original mode.
Note :
- When searching for or automatically pre-setting stations, with the “TA” function active, those stations which offer the traffi c information service will be found or memorised fi rst.
TRAFFIC INFORMATION VOLUME CONTROL
The traffi c information volume operates separately from that of the rest of the system, and can be adjusted independently.
Adjust by turning button (A) while a traffi c information message is being broadcast.
This new volume level is now memorised.

29R D S S Y S T E M
TRAFFIC INFORMATION
Your system allows you to receive traffi c information broadcasts even while listening to another audio source.
Press the “TA” button (C).
While a traffi c information message is being broadcast :
- The radio or cassette makes a pause.
Once the message has been broadcast, the system will revert to its original mode.
Note :
- When searching for or automatically pre-setting stations, with the “TA” function active, those stations which offer the traffi c information service will be found or memorised fi rst.
TRAFFIC INFORMATION VOLUME CONTROL
The traffi c information volume operates separately from that of the rest of the system, and can be adjusted independently.
Adjust by turning button (A) while a traffi c information message is being broadcast.
This new volume level is now memorised.
