Keep dismounted tires in a cool, dry place with as little
exposure to light as possible. Protect tires from contact
with oil, grease, and gasoline.
Replacement Tires
The tires on your new vehicle provide a balance of many
characteristics. They should be inspected regularly for
wear and correct cold tire inflation pressure. The manu-
facturer strongly recommends that you use tires equiva-
lent to the originals in size, quality and performance
when replacement is needed (refer to the paragraph on
ªTread Wear Indicatorsº). Refer to the ªTire and Loading
Informationº placard for the size designation of your tire.
The service description and load identification will be
found on the original equipment tire. Failure to use
equivalent replacement tires may adversely affect the
safety, handling, and ride of your vehicle. We recommend
that you contact your original equipment or an autho-
rized tire dealer with any questions you may have on tire
specifications or capability.
WARNING!
²Do not use a tire, wheel size or rating other than
that specified for your vehicle. Some combina-
tions of unapproved tires and wheels may
change suspension dimensions and performance
characteristics, resulting in changes to steering,
handling, and braking of your vehicle. This can
cause unpredictable handling and stress to steer-
ing and suspension components. You could lose
control and have an accident resulting in serious
injury or death. Use only the tire and wheel sizes
with load ratings approved for your vehicle.
²Never use a tire with a smaller load index or
capacity, other than what was originally
equipped on your vehicle. Using a tire with a
smaller load index could result in tire overload-
ing and failure. You could lose control and have
an accident.
²Failure to equip your vehicle with tires having
adequate speed capability can result in sudden
tire failure and loss of vehicle control.
318 STARTING AND OPERATING

HAZARD WARNING FLASHER
The flasher switch is located on the instrument
panel, below the radio. Depress the switch and
both cluster indicators and all front and rear
directional signals will flash. Depress the
switch again to turn Hazard Warning Flashers off.
Do not use this emergency warning system when the
vehicle is in motion. Use it when your vehicle is disabled
and is creating a safety hazard for other motorists.If it is necessary to leave the vehicle to go for service, the
flasher system will continue to operate with the ignition
key removed and the vehicle locked.
NOTE:With extended use, the flasher may wear down
your battery.
IF YOUR ENGINE OVERHEATS
In any of the following situations, you can reduce the
potential for overheating by taking the appropriate ac-
tion.
²On the highways Ð Slow down.
²In city traffic Ð While stopped, put transaxle in
neutral, but do not increase engine idle speed.
If the pointer rises to theH(red) mark, the instrument
cluster will sound a chime. Pull over and stop the vehicle
with the engine at idle, when safe. Turn off the air
conditioning and wait until the pointer drops back into
Hazard Warning Switch
342 WHAT TO DO IN EMERGENCIES

ONBOARD DIAGNOSTIC SYSTEM Ð OBD II
Your vehicle is equipped with a sophisticated onboard
diagnostic system called OBD II. This system monitors
the performance of the emissions, engine, and automatic
transmission control systems. When these systems are
operating properly, your vehicle will provide excellent
performance and fuel economy, as well as engine emis-
sions well within current government regulations.
If any of these systems require service, the OBD II system
will turn on the ªMalfunction Indicator Light.º It will
also store diagnostic codes and other information to
assist your service technician in making repairs. Al-
though your vehicle will usually be drivable and not
need towing, see your dealer for service as soon as
possible.CAUTION!
²Prolonged driving with the ªMalfunction Indica-
tor Lightº on could cause further damage to the
emission control system. It could also affect fuel
economy and driveability. The vehicle must be
serviced before any emissions tests can be per-
formed.
²If the ªMalfunction Indicator Lightº is flashing
while the engine is running, severe catalytic con-
verter damage and power loss will soon occur.
Immediate service is required.
Loose Fuel Filler Cap Message
After fuel is added, the vehicle diagnostic system can
determine if the fuel filler cap is loose, improperly
installed, or damaged. A gASCAP message will be dis-
played in the instrument cluster. Tighten the gas cap until
364 MAINTAINING YOUR VEHICLE

a9clicking9sound is heard. This is an indication that the
gas cap is properly tightened. Press the odometer reset
button to turn the message off. If the problem persists,
the message will appear the next time the vehicle is
started. This might indicate a damaged cap. If the prob-
lem is detected twice in a row, the system will turn on the
Malfunction Indicator Light (MIL). Resolving the prob-
lem will turn the MIL light off.
EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS
In some localities, it may be a legal requirement to pass
an inspection of your vehicle's emissions control system.
Failure to pass could prevent vehicle registration.
For states, which have an I/M (Inspection and
Maintenance) requirement, this check verifies the
following: the MIL (Malfunction Indicator Light)is functioning and is not on when the engine is running,
and that the OBD (On Board Diagnostic) system is ready
for testing.
Normally, the OBD system will be ready. The OBD
system maynotbe ready if your vehicle was recently
serviced, if you recently had a dead battery, or a battery
replacement. If the OBD system should be determined
not ready for the I/M test, your vehicle may fail the test.
Your vehicle has a simple ignition key actuated test,
which you can use prior to going to the test station. To
check if your vehicle's OBD system is ready, you must do
the following:
1. Insert your ignition key into the ignition switch.
2. Turn the ignition to the ON position, but do not crank
or start the engine.
3. If you crank or start the engine, you will have to start
this test over.
MAINTAINING YOUR VEHICLE 365
7

Caution, Exhaust Gas..................... 113
CD (Compact Disc) Player...............242,250
CD (Compact Disc) Player Maintenance........ 268
Cellular Phone.......................134,268
Center High Mounted Stop Light............ 409
Chains, Tire............................ 319
Changing A Flat Tire..................... 344
Chart, Tire Sizing........................ 303
Check Engine Light
(Malfunction Indicator Light)............... 365
Child Restraint.......................71,104
Child Restraint Tether Anchors............75,108
Child Restraint with Automatic Belts........... 74
Child Safety Locks........................ 22
Child Seat...........................77,110
Clean Air Gasoline....................... 322
Cleaning
Wheels............................. 395
Climate Control......................... 269Clock...........................240,244,252
Clutch............................... 388
Clutch Fluid........................... 388
Coin Holder........................... 205
Compact Disc (CD) Maintenance............. 268
Compact Spare Tire...................... 314
Compass.............................. 239
Compass Calibration..................... 239
Compass Variance....................... 238
Console.............................. 205
Contract, Service........................ 442
Convertible............................ 119
Convertible Boot.....................124,128
Convertible Top......................... 119
Convertible Top Maintenance............... 398
Convertible Top Manual Override.........130,356
Cool Down, Turbo....................... 282
Coolant (Antifreeze)...................410,411
Cooling System......................... 381
452 INDEX

Dimmer Switch, Headlight............... 181
Engine Temperature Warning.............. 228
Fog ..........................183,229,407
Front Replacement..................... 406
Headlight Switch...................... 182
Headlights........................... 182
High Beam Indicator.................... 230
Instrument Cluster..................... 182
Lights On Reminder.................... 183
Low Fuel............................ 229
Malfunction Indicator (Check Engine)........ 226
Map Reading......................180,181
Oil Pressure.......................... 229
Rear Servicing........................ 407
Seat Belt Reminder..................... 228
Security Alarm (Theft Alarm).............. 36
Service.............................. 406
Theft Alarm (Security Alarm).............. 228
Traction Control....................... 301Turn Signal..................181,184,226,407
Voltage............................. 228
Warning (Instrument Cluster Description)..... 224
Loading Vehicle......................... 328
Tires ............................... 306
Locks
Child Protection........................ 22
Door................................ 18
Power Door........................... 20
Steering Wheel......................... 18
Lubrication, Body....................... 379
Luggage Rack (Roof Rack)................. 213
Lumbar Support........................ 162
Maintenance Free Battery.................. 375
Maintenance, General..................... 367
Maintenance Procedures................... 367
Maintenance Schedule
Schedule ªAº-Non Turbo................. 428
458 INDEX

Schedule ªAº-Turbo.................... 433
Schedule ªBº......................... 417
Schedule ªBº-All Engines................ 417
Maintenance Schedules.................... 414
Malfunction Indicator Light (Check Engine) . . 226,365
Manual Override, Convertible Top.........130,356
Manual, Service......................... 444
Manual Transaxle..................281,290,393
Downshifting......................... 293
Fluid Level Check...................... 393
Frequency of Fluid Change............... 393
Lubricant Selection..................... 393
Map/Reading Lights..................180,181
Master Cylinder (Brakes).................. 388
Mirrors............................... 131
Electric Remote....................... 133
Outside............................. 132
Rearview............................ 131
Vanity.............................. 133Modifications/Alterations, Vehicle............. 7
Mopar Parts.........................366,443
Multi-Function Control Lever............... 181
New Vehicle Break-In Period................ 112
Occupant Classification System (OCS).......... 60
Occupant Restraints (Convertible)............. 80
Occupant Restraints (Sedan)................. 45
Octane Rating, Gasoline (Fuel).............. 321
Odometer............................. 225
Trip .............................225,230
Oil, Engine.........................368,410
Capacity............................ 410
Change Interval....................... 369
Checking............................ 368
Disposal............................ 371
Filter............................... 371
Identification Logo..................... 370
INDEX 459
10

Weight.............................. 332
Traction.............................. 352
Traction Control......................... 300
Traction Control Switch................... 300
Trailer Towing.......................... 328
Cooling System Tips.................... 340
Hitches............................. 331
Minimum Requirements................. 334
Trailer and Tongue Weight................ 333
Wiring.............................. 338
Trailer Towing Guide..................... 332
Trailer Weight.......................... 332
Transaxle............................. 283
Automatic....................13,280,283,390
Autostick............................ 288
Manual........................14,281,290
Operation........................... 283
Overdrive........................... 287
Selection of Lubricant................... 390Transmission
Range Indicator....................... 225
Transmitter Battery Service
(Remote Keyless Entry)..................28,34
Transmitter, Garage Door Opener (HomeLinkt) . . 193
Transmitter Programming
(Remote Keyless Entry)..................26,33
Transporting Pets......................79,112
Tread Wear Indicators.................... 316
Trip Odometer.......................... 225
Trip Odometer Reset Button................ 230
Trunk Lid, Deck Lid (Convertible)............. 39
Tumbling Rear Seat (Convertible)............ 172
Tumbling Rear Seat (Sedan)................ 170
Turbo Cool Down....................... 282
Turn Signals.........................184,226
UConnectŸ (Hands-Free Phone)............. 134
Understanding Your Instrument Panel......... 220
INDEX 465
10
