WARNING!
Do not connect trailer brakes to your vehicle’s hy-
draulic brake lines. It can overload your brake sys-
tem and cause it to fail. You might not have brakes
when you need them and could have an accident.
Towing any trailer will increase your stopping dis-
tance. When towing you should allow for additional
space between your vehicle and the vehicle in front
of you. Failure to do so could result in an accident.
Towing Requirements — Trailer Lights & Wiring
Whenever you pull a trailer, regardless of the trailer size,
stop lights and turn signals on the trailer are required for
motoring safety.
The Trailer Tow Package may includea4and7pin
wiring harness. Use a factory approved trailer harness
and connector.NOTE:Do not cut or splice wiring into the vehicles
wiring harness.
The electrical connections are all complete to the vehicle
but you must mate the harness to a trailer connector.
Refer to the following illustrations.
4 - Pin Connector
STARTING AND OPERATING 335
5

HAZARD WARNING FLASHER
The flasher switch is on the top of the steering column,
just behind the steering wheel. Press the flasher switch
and all front and rear directional signals will flash
intermittently.
Press the switch a second time to turn off the emergency
flashers.This is an emergency warning system and should not be
used when the vehicle is in motion. Use it when your
vehicle is disabled and is creating a safety hazard for
other motorists.
If it is necessary to leave the vehicle to go for service, the
flasher system will continue to operate with the ignition
key removed and the vehicle locked.
346 WHAT TO DO IN EMERGENCIES

▫Power Steering — Fluid Check............377
▫Front Suspension Ball Joints..............377
▫Drive Shaft Constant Velocity Joints........378
▫Body Lubrication.....................378
▫Windshield Wiper Blades................378
▫Windshield Washers...................379
▫Exhaust System......................380
▫Cooling System.......................381
▫Emission Related Components............386
▫Brake System........................387
▫Automatic Transmission................389
▫Transfer Case........................391
▫Axles..............................392▫Selection Of Lubricating Grease...........392
▫Appearance Care And Protection From
Corrosion...........................393
Fuse Block............................398
▫Fuses (Interior).......................398
▫Fuses (Power Distribution Center).........401
▫Fuses (Integrated Power Module)..........404
Vehicle Storage........................406
Replacement Light Bulbs.................407
Bulb Replacement......................407
▫Headlights/Parking/Turn Signal..........407
▫Tail Lights, Turn Signals And Backup Lights —
Replacement.........................409
▫License Lights........................411
360 MAINTAINING YOUR VEHICLE

REPLACEMENT LIGHT BULBS
LIGHT BULBS — Interior Bulb No.
Dome Light........................WL212–2
Liftgate Lamp........................... 567
Overhead Console Lights............. PLW214–2A
Reading Light.......................WL212–2
Visor Vanity Lights............... NotServiceable
LIGHT BULBS — Outside Bulb No.
Headlight............................. H13
Front Park/Turn......................3457AK
Back-Up..............................3057
Center High Mounted Stoplight.............. 921
Front Side Marker........................ 168
Fog Lamp...........................9006LL
License Plate Light....................... 168
Rear Tail, Stop, Turn Signal and Side Marker....3057
BULB REPLACEMENT
Headlights/Parking/Turn Signal
1. Remove the two bolts attaching the headlight to the
upper fender reinforcement (hood must be opened to
access bolts).
MAINTAINING YOUR VEHICLE 407
7

Tail Lights, Turn Signals And Backup Lights —
Replacement
1. Remove the two push-pins from the tail light housing.2. Rotate the light to the outboard side of the vehicle and
remove.
MAINTAINING YOUR VEHICLE 409
7

Flashers
Hazard Warning....................... 346
Turn Signal.....................135,187,409
Flat Tire Stowage.....................348,354
Flexible Fuel Vehicles
Cruising Range........................ 320
Engine Oil........................... 320
Fuel Requirements..................318,319
Maintenance.......................... 321
Replacement Parts..................... 320
Starting............................. 320
Flooded Engine Starting................... 256
Floor Console.......................172,175
Fluid, Brake.........................387,416
Fluid Capacities......................... 414
Fluid Level Checks
Automatic Transmission................. 389
Brake............................... 387
Engine Oil........................... 368Power Steering........................ 377
Transfer Case......................... 391
Fluids, Lubricants and Genuine Parts.......... 415
Fog Lights..........................135,413
Folding Rear Seat..................... 117,120
Four Wheel Drive....................... 263
Operation........................... 263
Four-Way Hazard Flasher.................. 346
Freeing A Stuck Vehicle................... 288
Front Axle (Differential)................... 392
Fuel................................. 311
Filler Cap (Gas Cap).................... 316
Filter............................... 373
Gauge.............................. 187
Octane Rating...................... 311,415
Requirements...................... 311,414
Tank Capacity........................ 414
Fuel, Flexible.............See Flexible Fuel Vehicles
Fuel System Caution..................... 318
INDEX 455
10

Lane Change and Turn Signals.........135,187,409
Lap/Shoulder Belts.....................39,45
LATCH (Lower Anchors and Tether for CHildren) . 65
Life of Tires............................ 304
Liftgate................................ 34
Lights..............................74,131
Airbag............................59,196
Anti-Lock Warning..................... 190
Automatic Headlights................... 133
Back-Up............................. 409
Brake Warning........................ 193
Bulb Replacement...................... 407
Center Mounted Stop................... 412
Courtesy/Reading..................... 151
Cruise.............................. 196
Daytime Running...................... 134
Dome.............................. 151
Electronic Stability Program (ESP) Indicator . 193,283
Fog ..........................135,188,413Hazard Warning Flasher................. 346
Headlights........................... 134
High Beam........................... 137
High Beam/Low Beam Select............. 137
Instrument Cluster..................134,187
Interior..........................132,151
License............................. 411
Lights On Reminder.................... 135
Low Fuel.........................187,188
Malfunction Indicator (Check Engine)........ 194
Park............................... 134
Passing............................. 137
Reading............................. 151
Seat Belt Reminder..................... 188
Service.............................. 407
Tire Pressure Monitoring (TPMS)........... 195
Traction Control....................... 283
Turn Signal........................135,409
Warning (Instrument Cluster Description)..... 187
458 INDEX

Extender............................. 50
Front Seat............................ 39
Pretensioners.......................... 48
Reminder............................ 188
Seats................................. 108
Adjustment.......................... 108
Cleaning............................ 395
Fold and Tumble Rear................ 115,117
Heated.............................. 112
Lumbar Support....................... 110
Memory............................. 125
Rear Folding....................... 115,117
Reclining............................ 109
Security Alarm (Theft Alarm).............17,190
Selection of Coolant (Antifreeze)..........382,415
Selection of Oil......................... 370
Sentry Key (Immobilizer)................... 15
Service and Maintenance................367,418
Service Assistance....................... 442Service Contract......................... 444
Service Manuals........................ 446
Setting the Clock.............197,198,202,210,222
Settings, Personal........................ 155
Shifting
Automatic Transmission................. 258
Transfer Case......................... 263
Transfer Case, Shifting into Transfer Case
Neutral (N)............................ 340
Transfer Case, Shifting out of Transfer Case
Neutral (N)............................ 341
Shoulder Belt Upper Anchorage.............. 44
Shoulder Belts........................... 39
Signals, Turn.....................135,187,409
Snow Plow............................ 338
Snow Tires............................ 306
Spare Tire..........................301,302
Spark Plugs............................ 372
Speed Control (Cruise Control).............. 142
INDEX 463
