2007 CHRYSLER 300 LX hood open

Seats................................92
▫Power Seats..........................92
▫Power Reclining Seats...................93
▫Lumbar Support.......................94
▫Head Restraints.......................94
▫Heated Seats — If Equipped..............95
▫Folding Rear Seat......................97
Driver Memory Seat — If Equipped.........98
▫Programming The Memory Feature.........98
▫Linking & Unlinking The Remote Keyless
Transmitter To The Memory Feature.........99
▫Memory Position Recall.................100
▫Easy Entry/Exit Seat
(Available With Memory Seat Only)........100
To Open And Close The Hood............101
Lights..............................103▫Headlight Switch.....................103
▫Automatic Headlights – If Equipped........103
▫Headlights On With Wipers
(Available With Auto Headlights Only)......104
▫Smartbeams — If Equipped..............104
▫Headlight Time Delay..................105
▫Daytime Running Lights (Canada Only).....106
▫Lights-On Reminder...................106
▫Fog Lights — If Equipped...............106
▫Multi-Function Lever...................106
▫Overhead Console Map/Reading Lights.....108
▫Interior Lights.......................108
Windshield Wipers And Washers..........109
▫Intermittent Wiper System...............110
▫Mist Feature.........................110
▫Windshield Washers...................110
64 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
ProCarManuals.com

•When you remove the key from the ignition switch,
the driver seat will move to a position 1.2 inches (30
mm) forward of the rear stop if the driver seat position
is between 2.4 inches and 3.5 inches (60 mm and 90
mm) forward of the rear stop. The seat will return to its
previously set position when you insert the key into
the ignition switch and turn it out of the LOCK
position.
•The Easy Entry/Easy Exit feature is disabled when the
driver seat position is less than 2.4 inches (60 mm)
forward of the rear stop. At this position, there is no
benefit to the driver by moving the seat for Easy Exit
or Easy Entry.
Each stored memory setting will have an associated Easy
Entry and Easy Exit position.
NOTE:The Easy Entry/Easy Exit feature can be en-
abled or disabled through the programmable features in
the Electronic Vehicle Information Center (EVIC). For
details, refer to “Automatically Move Seat Back on Exit,”
under “Personal Settings (Customer Programmable Fea-
tures),” under “Electronic Vehicle Information Center
(EVIC)” in Section 4 of this manual.
TO OPEN AND CLOSE THE HOOD
Two latches must be released to open the hood. First, pull
the hood release lever located under the left side of the
instrument panel.
Hood Release Lever
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101
3
ProCarManuals.com

Next, move to the outside of the vehicle and push the
safety catch to the left. The safety catch is located under
the center front edge of the hood.
Use the hood prop rod (if equipped) to secure the hood in
the open position.To prevent possible damage, do not slam the hood to
close it. Lower the hood, until it is open approximately 6
inches (15 cm), and then drop it. This should secure both
latches. Never drive your vehicle unless the hood is fully
closed, with both latches engaged.
WARNING!
If the hood is not fully latched, it could fly up when
the vehicle is moving and block your forward vision.
You could have a collision. Be sure all hood latches
are fully latched before driving.
Hood Safety Catch
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
ProCarManuals.com

Cooling System
WARNING!
•When working near the radiator cooling fan, dis-
connect the fan motor lead or turn the ignition
switch to the OFF position. The fan is temperature
controlled and can start at any time the ignition
switch is in the ON position.
•You or others can be badly burned by hot coolant
or steam from your radiator. If you see or hear
steam coming from under the hood, don’t open
the hood until the radiator has had time to cool.
Never try to open a cooling system pressure cap
when the radiator is hot.
Coolant Checks
Check engine coolant (antifreeze) protection every 12
months (before the onset of freezing weather, where
applicable). If coolant is dirty or rusty in appearance, the
system should be drained, flushed and refilled with fresh
coolant. Check the front of the A/C condenser for any
accumulation of bugs, leaves, etc. If dirty, clean by gently
spraying water from a garden hose vertically down the
face of the condenser.
Check the coolant recovery bottle tubing for brittle rub-
ber, cracking, tears, cuts, and tightness of the connection
at the bottle and radiator. Inspect the entire system for
leaks.
With the engine at normal operating temperature (but
not running), check the cooling system pressure cap for
proper vacuum sealing by draining a small amount of
coolant from the radiator drain cock. If the cap is sealing
properly, the engine coolant (antifreeze) will begin to
drain from the coolant recovery bottle. DO NOT RE-
MOVE THE COOLANT PRESSURE CAP WHEN THE
COOLING SYSTEM IS HOT.
MAINTAINING YOUR VEHICLE 349
7
ProCarManuals.com

BULB REPLACEMENT
Low Beam Headlight, High Beam Headlight,
Park/Turn Light, Inner Park Light, and Outer Park
Light – 300 Models
1. Open the hood.
NOTE:Removal of the air cleaner filter housing may be
necessary prior to replacing bulbs in the headlight assem-
bly on the driver side of the vehicle.
2. Twist the appropriate bulb and socket assembly
counter-clockwise, and then pull it out of the headlight
assembly.
3. Pull the bulb out of the socket assembly.
4. Push the replacement bulb into the socket assembly.
5. Reinstall the bulb and socket assembly into the head-
light assembly, and then turn it clockwise.
1 — High Beam Headlight Bulb
2 — Low Beam Headlight Bulb 372 MAINTAINING YOUR VEHICLE
ProCarManuals.com

CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
Low Beam Headlight, High Beam Headlight, and
Park/Turn Light – 300C
High Intensity Discharge Headlights (HID) — If
Equipped
The headlights are a type of high voltage discharge tube.
High voltage can remain in the circuit even with the
headlight switch off and the key removed.Because of
this, you should not attempt to service a headlight bulb
yourself. If a headlight bulb fails, take your vehicle to
an authorized dealer for service.
WARNING!
A transient high tension occurs at the bulb sockets of
High Intensity Discharge (HID) headlights when the
headlight switch is turned ON. It may cause serious
electrical shock or electrocution if not serviced prop-
erly. See your authorized dealer for service.
NOTE:On vehicles equipped with High Intensity Dis-
charge Headlights (HID), when the headlights are turned
on, there is a blue hue to the lights. This diminishes and
becomes more white after approximately 10 seconds, as
the system charges.
1. Open the hood.
NOTE:Removal of the air cleaner filter housing may be
necessary prior to replacing bulbs in the headlight assem-
bly on the driver side of the vehicle.
2. Twist the appropriate bulb and socket assembly
counter-clockwise, and then pull it out of the headlight
assembly.
3. Pull the bulb out of the socket assembly.
374 MAINTAINING YOUR VEHICLE
ProCarManuals.com

High Beam/Low Beam Select (Dimmer)
Switch............................... 107
Hitches
Trailer Towing....................... 301
Holder, Cup........................... 151
HomeLink(Garage Door Opener)
Transmitter........................... 141
Hood Release.......................... 101
Hoses............................353,354
Ignition............................... 11
Key ................................ 11
Ignition Key Removal.................... 11
Illuminated Entry....................... 17
Immobilizer (Sentry Key).................. 13
Indicator, Traction Control................ 257
Infant Restraint.......................50,51
Inflation Pressure Tires................... 169
Information Center, Vehicle............... 171
Inside Rearview Mirror................... 68
Instrument Cluster................161,162,163
Instrument Panel and Controls............. 160
Instrument Panel Lens Cleaning............ 362Interior Appearance Care................. 361
Interior Fuses.......................... 363
Interior Lights......................... 108
Intermittent Wipers (Delay Wipers).......... 110
Introduction............................ 4
Jack Location.......................... 315
Jack Operation......................... 317
Jacking Instructions..................... 317
Jump Starting......................... 322
Key, Programming....................... 14
Key, Replacement....................... 14
Key, Sentry (Immobilizer).................. 13
Key-In Reminder........................ 12
Keyless Entry System..................... 17
Keys................................. 11
Knee Bolster........................... 41
Lane Change and Turn Signals............. 107
Lap/Shoulder Belts...................... 33
LATCH
(Lower Anchors and Tether for CHildren) . . . 54,55
420 INDEX
ProCarManuals.com
