2007 CHEVROLET MONTE CARLO ECO mode

To return to the manual mode, press the EQ
button until Manual displays or start to manually
adjust the bass, midrange, or treble by pressing
the tune knob.
Adjusting the Speakers (Balance/Fade)
BAL/FADE (Balance/Fade):To adjust balance
or fade, press the tune knob until the speaker
control labels display. Continue pressing to
highlight the desired label, or press the pushbutton
positioned under the desired label. Turn the
tune knob clockwise or counterclockwise to adjust
the highlighted setting. The highlighted setting
can also be adjusted by pressing either the SEEK,
FWD (forward), or REV (reverse) button until
the desired levels are obtained.
To quickly adjust balance or fade to the middle
position, press the pushbutton positioned under the
BAL or FADE label for more than two seconds.
A beep sounds and the level adjusts to the middle
position.
To quickly adjust all speaker and tone controls to
the middle position, press the tune knob for
more than two seconds until a beep sounds.
Finding a Category (CAT) Station
CAT (Category):The CAT button is used to nd
XM™ stations while the radio is in the XM™
mode. To nd XM™ channels within a desired
category, perform the following:
1. Press the BAND button until the XM™
frequency displays. Press the CAT button to
display the category labels on the radio
display. Continue pressing the CAT button
until the desired category name displays.
2. Press either of the two buttons below the
desired category label to immediately tune
to the rst XM™ station associated with that
category.
3. Turn the tune knob, press the buttons below
the right or left arrows displayed, or press the
right or left SEEK buttons to go to the next
or previous XM™ station within the selected
category.
4. To exit the category search mode, press the
FAV button or BAND button to display your
favorites again.
225

No Folder
When the CD-R contains only compressed les,
the les are located under the root folder. The next
and previous folder functions do not function on
a CD-R that was recorded without folders or
playlists. When displaying the name of the folder
the radio displays ROOT.
When the CD-R contains only playlists and
compressed audio les, but no folders, all les are
located under the root folder. The folder down
and the folder up buttons searches playlists (Px)
rst and then goes to the root folder. When
the radio displays the name of the folder the radio
displays ROOT.
Order of Play
Tracks recorded to the CD-R are played in the
following order:
Play begins from the rst track in the rst
playlist and continues sequentially through
all tracks in each playlist. When the last track
of the last playlist has played, play continues
from the rst track of the rst playlist.
Play begins from the rst track in the rst
folder and continues sequentially through
all tracks in each folder. When the last track of
the last folder has played, play continues
from the rst track of the rst folder.
When play enters a new folder, the display does
not automatically show the new folder name unless
you have chosen the folder mode as the default
display. The new track name displays.
233

h(Music Navigator):Use the music navigator
feature to play MP3 les on the CD-R in order
by artist or album. Press the pushbutton located
below the music navigator label. The player scans
the disc to sort the les by artist and album ID3
tag information. It can take several minutes to scan
the disc depending on the number of MP3 les
recorded to the CD-R. The radio might begin
playing while it is scanning the disc in the
background. When the scan is nished, the
CD-R begins playing again.
Once the disc has scanned, the player defaults to
playing MP3 les in order by artist. The current
artist playing is shown on the second line of
the display between the arrows. Once all songs by
that artist are played, the player moves to the
next artist in alphabetical order on the CD-R and
begins playing MP3 les by that artist. If you
want to listen to MP3 les by another artist, press
the pushbutton located below either arrow
button. The CD goes to the next or previous artist
in alphabetical order. Continue pressing either
button until the desired artist displays.
To change from playback by artist to playback by
album, press the pushbutton located below the
Sort By label. From the sort screen, push one ofthe buttons below the album button. Press the
pushbutton below the back label to return to the
main music navigator screen. Now the album
name displays on the second line between
the arrows and songs from the current album
begins to play. Once all songs from that album
have played, the player moves to the next album in
alphabetical order on the CD-R and begins
playing MP3 les from that album.
To exit music navigator mode, press the
pushbutton below the Back label to return to
normal MP3 playback.
BAND:Press this button to listen to the radio
while a CD is playing. The CD remains inside the
radio for future listening.
CD/AUX (CD/Auxiliary):Press this button to play
a CD while listening to the radio. The CD icon and a
message showing disc and/or track number
displays while a CD is in the player. Press this
button again and the system automatically
searches for an auxiliary input device such as a
portable audio player. If a portable audio player is
not connected, No Aux Input Device Found
displays.
237

If there seems to be no leak, with the engine on,
check to see if the electric engine cooling fans
are running. If the engine is overheating, the fans
should be running. If the fans are not running,
your vehicle needs service.
Notice:Engine damage from running your
engine without coolant is not covered by your
warranty. SeeOverheated Engine Protection
Operating Mode on page 325for information
on driving to a safe place in an emergency.
Notice:Using coolant other than DEX-COOL
®
may cause premature engine, heater core,
or radiator corrosion. In addition, the engine
coolant could require changing sooner,
at 30,000 miles (50 000 km) or 24 months,
whichever occurs rst. Any repairs would
not be covered by your warranty. Always
use DEX-COOL
®(silicate-free) coolant in
your vehicle.
How to Add Coolant to the Coolant
Recovery Tank
{CAUTION:
Adding only plain water to your cooling
system can be dangerous. Plain water, or
some other liquid such as alcohol, can
boil before the proper coolant mixture will.
Your vehicle’s coolant warning system is
set for the proper coolant mixture. With
plain water or the wrong mixture, your
engine could get too hot but you would
not get the overheat warning. Your engine
could catch re and you or others could
be burned. Use a 50/50 mixture of clean,
drinkable water and DEX-COOL
®coolant.
328

For prompt and efficient assistance when calling,
please provide the following to the Roadside
Assistance Representative:
Your name, home address, and home
telephone number.
Telephone number of your location.
Location of the vehicle.
Model, year, color, and license plate number.
Odometer reading, Vehicle Identication
Number (VIN), and delivery date of the vehicle.
Description of the problem.
While we hope you never have the occasion to
use our service, it is added security while traveling
for you and your family. Remember, we are
only a phone call away. U.S. customers call
Chevrolet Roadside Assistance:1-800-CHEV-USA
(1-800-243-8872), text telephone (TTY) users,
call1-888-889-2438, Canadian customers
call1-800-268-6800.Chevrolet and General Motors of Canada Limited
reserve the right to limit services or reimbursement
to an owner or driver when, in their sole
discretion, the claims become excessive in
frequency or type of occurrence.
Roadside Assistance is not part of or included in
the coverage provided by the New Vehicle Limited
Warranty. Chevrolet and General Motors of
Canada Limited reserve the right to make any
changes or discontinue the Roadside Assistance
program at any time without notication.Towing and Road Service Exclusions
Specically excluded from Roadside Assistance
coverage are towing or services for vehicles
operated on a non-public roadway or highway,
nes, impound towing caused by a violation
of local, Municipal, State, Provincial, or Federal
law, and mounting, dismounting or changing
of snow tires, chains, or other traction devices.
431

Additional Program Information
All program options, such as shuttle service, may
not be available at every dealer. Please contact
your dealer for specic information about
availability. All Courtesy Transportation
arrangements will be administered by appropriate
dealer personnel.
General Motors reserves the right to unilaterally
modify, change or discontinue Courtesy
Transportation at any time and to resolve all
questions of claim eligibility pursuant to the
terms and conditions described herein at its
sole discretion.
Vehicle Data Collection and
Event Data Recorders
Your vehicle, like other modern motor vehicles, has
a number of sophisticated computer systems that
monitor and control several aspects of the vehicle’s
performance. Your vehicle uses on-board vehicle
computers to monitor emission control components
to optimize fuel economy, to monitor conditions for
airbag deployment and, if the vehicle has the
Anti-lock Brake System (ABS), to provide anti-lock
braking and to help the driver control the vehicle in
difficult driving situations. Some information may be
stored during regular operations to facilitate repair
of detected malfunctions; other information is
stored only in a crash event by computer systems,
such as those commonly called Event Data
Recorders (EDR).
In a crash event, computer systems, such as the
airbag Sensing and Diagnostic Module (SDM) in
your vehicle may record information about the
condition of the vehicle and how it was operated,
such as data related to engine speed, brake
application, throttle position, vehicle speed,
safety belt usage, airbag readiness, airbag
performance, and the severity of a collision.
434

E
Easy Entry Seat............................................ 15
Electric Power Management........................ 161
Electrical System
Add-On Equipment................................... 395
Fuses and Circuit Breakers...................... 395
Headlamp Wiring..................................... 395
Instrument Panel Fuse Block................... 396
Power Windows and Other Power
Options................................................. 395
Underhood Fuse Block............................. 397
Windshield Wiper Fuses........................... 395
Engine
Air Cleaner/Filter...................................... 316
Battery..................................................... 336
Check and Service Engine Soon Light..... 181
Coolant.................................................... 320
Coolant Heater......................................... 112
Coolant Temperature Gage...................... 180
Coolant Temperature Warning Light.......... 179
Drive Belt Routing.................................... 417
Engine Compartment Overview................ 308
Exhaust................................................... 121
Oil ........................................................... 311
Oil Life System........................................ 314
Overheated Protection Operating Mode.... 325Engine (cont.)
Overheating............................................. 323
Starting.................................................... 110
Entry Lighting.............................................. 160
Event Data Recorders (EDR)...................... 434
Extender, Safety Belt..................................... 40
Exterior Lamps............................................ 156
F
Filter
Engine Air Cleaner................................... 316
Finish Damage............................................ 392
Flashers, Hazard Warning........................... 148
Flash-to-Pass.............................................. 151
Flat Tire...................................................... 371
Flat Tire, Changing...................................... 372
Flat Tire, Storing......................................... 382
Fluid
Automatic Transaxle................................. 317
Power Steering........................................ 331
Windshield Washer.................................. 332
Fog Lamp Light........................................... 185
Fog Lamps.................................................. 158
Folding Rear Seat......................................... 16
447

Mirrors
Automatic Dimming Rearview with
OnStar
®................................................ 123
Manual Rearview Mirror........................... 123
Manual Rearview Mirror with OnStar
®...... 123
Outside Convex Mirror............................. 124
Outside Heated Mirrors............................ 124
Outside Power Mirrors............................. 124
MP3 ............................................................ 231
MyGMLink.com............................................ 425
N
New Vehicle Break-In.................................. 108
Normal Maintenance Replacement Parts..... 416
O
Odometer.................................................... 172
Off-Road Recovery...................................... 258
Oil
Engine..................................................... 311
Pressure Light.......................................... 184
Oil, Engine Oil Life System......................... 314
Older Children, Restraints............................. 41
Online Owner Center................................... 425
OnStar
®System, see OnStar®Manual........ 125Other Warning Devices................................ 148
Outlet Adjustment........................................ 168
Outlet(s), Accessory Power.......................... 162
Outside
Convex Mirror.......................................... 124
Heated Mirrors......................................... 124
Power Mirrors.......................................... 124
Overheated Engine Protection
Operating Mode....................................... 325
Owner Checks and Services....................... 412
Owners, Canadian.......................................... 3
P
Paint, Damage............................................ 392
Parade Dimming.......................................... 161
Park (P)
Shifting Into............................................. 118
Shifting Out of......................................... 120
Parking
Brake....................................................... 117
Over Things That Burn............................ 120
Passenger Airbag Status Indicator............... 175
Passenger Compartment Air Filter............... 169
Passenger Sensing System........................... 77
Passing....................................................... 258
PASS-Key
®III+........................................... 106
451
