2007 CHEVROLET COLORADO warning

Seats and Restraint Systems
....................... 7
Front Seats
.............................................. 9
Rear Seats
............................................. 17
Safety Belts
............................................ 20
Child Restraints
...................................... 44
Airbag System
........................................ 77
Restraint System Check
......................... 96
Features and Controls
................................ 99
Keys
..................................................... 101
Doors and Locks
.................................. 106
Windows
............................................... 112
Theft-Deterrent Systems
....................... 115
Starting and Operating Your
Vehicle
.............................................. 118
Mirrors
.................................................. 141OnStar®System
................................... 149
Storage Areas
...................................... 153
Sunroof
................................................ 156
Instrument Panel
....................................... 157
Instrument Panel Overview
................... 160
Climate Controls
................................... 177
Warning Lights, Gages, and
Indicators
.......................................... 181
Driver Information Center (DIC)
............ 198
Audio System(s)
................................... 206
Driving Your Vehicle
................................. 245
Your Driving, the Road, and
Your Vehicle
..................................... 246
Towing
................................................. 299
2007 Chevrolet Colorado Owner ManualM
1

Index
A good place to quickly locate information about
the vehicle is the Index in the back of the manual.
It is an alphabetical list of what is in the manual
and the page number where it can be found.
Safety Warnings and Symbols
There are a number of safety cautions in this
book. We use a box and the word CAUTION to
tell about things that could hurt you if you were
to ignore the warning.
{CAUTION:
These mean there is something that could
hurt you or other people.In the caution area, we tell you what the hazard
is. Then we tell you what to do to help avoid
or reduce the hazard. Please read these cautions.
If you do not, you or others could be hurt.
You will also nd a
circle with a slash
through it in this book.
This safety symbol
means “Do Not,”
“Do Not do this” or
“Do Not let this happen.”
4

Vehicle Damage Warnings
Also, in this manual you will nd these notices:
Notice:These mean there is something
that could damage your vehicle.
A notice tells about something that can damage
the vehicle. Many times, this damage would not be
covered by your vehicle’s warranty, and it could
be costly. But the notice will tell what to do to help
avoid the damage.
When you read other manuals, you might see
CAUTION and NOTICE warnings in different colors
or in different words.
There are also warning labels on the vehicle.
They use the same words, CAUTION or NOTICE.
Vehicle Symbols
The vehicle has components and labels that use
symbols instead of text. Symbols are shown
along with the text describing the operation or
information relating to a specic component,
control, message, gage, or indicator.
If you need help guring out a specic name of
a component, gage, or indicator, reference
the following topics:
Seats and Restraint Systems in Section 1
Features and Controls in Section 2
Instrument Panel Overview in Section 3
Climate Controls in Section 3
Warning Lights, Gages, and Indicators in
Section 3
Audio System(s) in Section 3
Engine Compartment Overview in Section 5
5

Your vehicle has a feature that may automatically
unlock the doors (if your vehicle has power door
locks), turn the interior lamps on, ash the hazard
warning ashers, and turn off the radio when the
airbag inates. You can lock the doors again by
using the door lock. The interior lamps and hazard
warning ashers will deactivate after approximately
15 minutes. You can use the radio controls to
adjust the radio.
In many crashes severe enough to inate an airbag,
windshields are broken by vehicle deformation.
Additional windshield breakage may also occur
from the right front passenger airbag.
Airbags are designed to inate only once.
After an airbag inates, you will need some new
parts for the airbag system. If you do not get
them, the airbag system will not be there to help
protect you in another crash. A new system will
include airbag modules and possibly other
parts. The service manual for your vehicle
covers the need to replace other parts.
Your vehicle has a crash sensing and
diagnostic module which records information
after a crash. SeeVehicle Data Recording
and Privacy on page 478andEvent Data
Recorders on page 479.
Let only qualied technicians work on your
airbag system. Improper service can mean
that your airbag system will not work properly.
See your dealer/retailer for service.
87

ON (C):This is the position that the switch
returns to after you start your engine and release
the switch. The switch stays in ON when the
engine is running. But even when the engine is
not running, you can use ON to operate the
electrical accessories and to display some
instrument panel cluster warning and indicator
lights. The transmission is also unlocked in
this position on automatic transmission vehicles.
The battery could be drained if you leave the key in
the ACC or ON position with the engine off. You
may not be able to start your vehicle if the battery is
allowed to drain for an extended period of time.
START (D):This is the position that starts the
engine. When the engine starts, release the key.
The ignition switch returns to ON for driving.
When the engine is not running, ACC and ON
allows you to operate the electrical accessories,
such as the radio or items plugged into the
accessory power outlets.A warning tone will sound if you open the driver’s
door when the ignition is in ACC or LOCK and
the key is in the ignition.
Key In the Ignition
Never leave your vehicle with the keys inside, as it
is an easy target for joy riders or thieves. If you
leave the key in the ignition and park your vehicle,
a chime will sound, when you open the driver’s
door. Always remember to remove your key from
the ignition and take it with you. This will lock
your ignition and transmission. Also, always
remember to lock the doors.
The battery could be drained if you leave the
key in the ignition while your vehicle is parked.
You may not be able to start your vehicle after
it has been parked for an extended period
of time.
120

Shifting Out of NEUTRAL
After towing your vehicle, you will have to shift
out of NEUTRAL in order to drive. To shift out
of NEUTRAL, do the following:
1. Set the parking brake and apply the regular
brake pedal.
2. Start a vehicle with an automatic transmission
in PARK (P). Use FIRST (1) for vehicles with
a manual transmission.
3. Shift the transmission to NEUTRAL (N), or
press the clutch pedal for vehicles with a
manual transmission.
4. Press the button for the desired transfer case
shift position (Two-Wheel High, Four-Wheel
High, or Four-Wheel Low).
5. After the transfer case has shifted out of
NEUTRAL, the indicator light will go out.
6. Release the parking brake.
7. Shift the transmission to the desired position.
Parking Brake
The parking brake
pedal is located to
the left of the regular
brake pedal, near
the driver’s door.
To set the parking brake, hold the regular
brake pedal down with your right foot. Push the
parking brake pedal down to its fully-applied
position with your left foot.
A chime will activate and the brake warning
light, located on the instrument panel, will ash
when the parking brake is applied and the vehicle
is moving at least 3 mph (5 km/h) for at least
three seconds. The chime will deactivate and the
light will turn off when the parking brake is set
and the vehicle is moving below 3 mph (5 km/h).
SeeBrake System Warning Light on page 189.
133

To release the parking brake, hold the regular
brake pedal down. Pull the bottom edge of
the lever, located above the parking brake pedal,
with the parking brake symbol, directly rearward
to release the parking brake.If the ignition is on when the parking brake is
released, the brake system warning light will
go off.
Notice:Driving with the parking brake on
can overheat the brake system and cause
premature wear or damage to brake system
parts. Verify that the parking brake is fully
released and the brake warning light is
off before driving.
If you are towing a trailer and are parking on
any hill, seeTowing a Trailer on page 306.
134

Instrument Panel Overview........................ 160
Hazard Warning Flashers.......................... 162
Other Warning Devices............................. 162
Horn.......................................................... 162
Tilt Wheel.................................................. 162
Turn Signal/Multifunction Lever.................. 163
Turn and Lane-Change Signals................. 164
Headlamp High/Low-Beam Changer.......... 165
Flash-to-Pass............................................ 165
Windshield Wipers..................................... 165
Windshield Washer.................................... 166
Cruise Control........................................... 166
Exterior Lamps.......................................... 170
Headlamps on Reminder........................... 171
Daytime Running Lamps (DRL)................. 171
Automatic Headlamp System..................... 172
Fog Lamps................................................ 173
Exterior Cargo Lamps................................ 174
Interior Lamps........................................... 174
Instrument Panel Brightness...................... 174
Dome Lamp.............................................. 174Dome Lamp Override................................ 175
Exit Lighting.............................................. 175
Electric Power Management...................... 175
Battery Run-Down Protection..................... 175
Accessory Power Outlet(s)........................ 176
Ashtray(s) and Cigarette Lighter................ 177
Climate Controls......................................... 177
Climate Control System............................. 177
Outlet Adjustment...................................... 180
Warning Lights, Gages, and Indicators..... 181
Instrument Panel Cluster........................... 182
Speedometer and Odometer...................... 183
Trip Odometer........................................... 183
Tachometer............................................... 183
Safety Belt Reminder Light........................ 184
Passenger Safety Belt Reminder Light....... 184
Airbag Readiness Light............................. 185
Passenger Airbag Status Indicator............. 186
Battery Warning Light................................ 188
Up-Shift Light (Manual Transmission)........ 189
Section 3 Instrument Panel
157
