Automatic Dimming Rearview Mirror with
Compass and Temperature Display......... 148
Outside Power Mirrors............................... 152
Outside Power Foldaway Mirrors............... 153
OnStar
®System.......................................... 156
Universal Home Remote System................ 159
Universal Home Remote System
(With Three Round LED)....................... 159
Universal Home Remote System
(With One Triangular LED)..................... 160
Universal Home Remote
System Operation
(With Three Round LED)....................... 161
Universal Home Remote
System Operation
(With One Triangular LED)..................... 166Storage Areas............................................. 170
Glove Box................................................. 170
Cupholder(s).............................................. 170
Center Overhead Console......................... 171
Front Armrest Storage Area....................... 171
Center Console Storage Area.................... 171
Luggage Carrier........................................ 171
Rear Storage Area.................................... 173
Cargo Cover Panels.................................. 173
All-Weather Cargo Area............................. 186
Top-Box Storage....................................... 191
Tonneau Cover......................................... 192
Sunroof....................................................... 199
Section 2 Features and Controls
92

OnStar®System
OnStar®uses several innovative technologies and
live advisors to provide you with a wide range
of safety, security, information, and convenience
services. If your airbags deploy, the system is
designed to make an automatic call to OnStar
®
Emergency advisors who can request emergency
services be sent to your location. If you lock
your keys in the vehicle, call OnStar
®at
1-888-4-ONSTAR and they can send a signal
to unlock your doors. If you need roadside
assistance, press the OnStar
®button and they
can contact Roadside Service for you.OnStar
®service is provided to you subject to the
OnStar®Terms and Conditions. You may cancel
your OnStar®service at any time by contacting
OnStar®as provided below. A complete OnStar®
Owners Guide and the OnStar®Terms and
Conditions are included in the vehicle’s OnStar®
Subscriber glove box literature. For more
information, visit onstar.com or onstar.ca, contact
OnStar
®at 1-888-4-ONSTAR (1-888-466-7827) or
TTY 1-877-248-2080, or press the OnStar®button
to speak with an OnStar®advisor 24 hours a day,
7 days a week.
Not all OnStar
®features are available on all
vehicles. To check if your vehicle is equipped to
provide the services described below, or for a
full description of OnStar
®services and system
limitations, see the OnStar®Owner’s Guide in your
glove box or visit onstar.com.
156

OnStar®Services
For new vehicles with OnStar®, the Safe & Sound
Plan, or the Directions & Connections®Plan is
included for one year from the date of purchase.
You can extend this plan beyond the rst year,
or upgrade to the Directions & Connections
®Plan.
For more information, press the OnStar®button
to speak with an advisor. Some OnStar®services
(such as Remote Door Unlock or Stolen Vehicle
Location Assistance) may not be available
until you register with OnStar
®.
Available Services with Safe & Sound®Plan

Automatic Notication of Airbag Deployment
Advanced Automatic Crash Notication (AACN)
(If equipped)
Link to Emergency Services
Roadside Assistance
Stolen Vehicle Location Assistance
AccidentAssist
Remote Door Unlock/Vehicle Alert
OnStar®Vehicle Diagnostics
GM Goodwrench®On Demand Diagnostics
OnStar®Hands-Free Calling with
30 complimentary minutes
OnStar®Virtual Advisor (U.S. Only)
Available Services included with Directions
& Connections®Plan

All Safe and Sound Plan Services
Driving Directions - Advisor delivered or
OnStar®Turn-by-Turn Navigation (If equipped)
RideAssist
Information and Convenience Services
OnStar®Hands-Free Calling
OnStar®Hands-Free Calling allows eligible
OnStar®subscribers to make and receive calls
using voice commands. Hands-Free Calling is fully
integrated into the vehicle, and can be used with
OnStar
®Pre-Paid Minute Packages. Hands-Free
Calling may also be linked to a Verizon Wireless
service plan in the U.S. or a Bell Mobility service
plan in Canada, depending on eligibility. To nd out
more, refer to the OnStar
®Owners Guide in the
vehicle’s glove box, visit www.onstar.com or
www.onstar.ca, or speak with an OnStar
®advisor
by pressing the OnStar®button or calling
1-888-4-ONSTAR (1-888-466-7827).
157

Reprogramming a Single Universal
Home Remote Button
To program a device to Universal Home Remote
using a Universal Home Remote button
previously trained, follow these steps:
1. Press and hold the desired Universal Home
Remote button. Do not release the button.
2. The indicator light will begin to ash after
20 seconds. While still holding the Universal
Home Remote button, proceed with
Step 2 under “Programming Universal
Home Remote” shown earlier in this section.
For additional information on Universal Home
Remote, seeCustomer Assistance Offices
on page 586.
Storage Areas
Glove Box
Open the glove box by pulling up on the bottom
of the handle.
Cupholder(s)
Your vehicle may have cupholders for the front
and rear passengers.
The cupholders are located in the center console
for the front passengers and on the rear of the
center console for the rear passengers.
The front cupholder may be removed for cleaning
by pushing down and then back on the cupholder.
To use the front cupholders, press down on
the access door and release. The door will then
open. Push the door back down to close it.
To use the rear cupholders, pull down on the
door located on the back of the console.
170

The main components of your instrument panel are the following:
A. Air Outlets. SeeOutlet Adjustment on
page 238.
B. Turn Signal/Multifunction Lever. SeeTurn
Signal/Multifunction Lever on page 207.
C. Instrument Panel Cluster. SeeInstrument Panel
Cluster on page 240.
D. Hazard Warning Flasher Button. SeeHazard
Warning Flashers on page 206.
E. Shift Lever. SeeAutomatic Transmission
Operation on page 128.
F. Tow/Haul Selector Button (If Equipped).
SeeTow/Haul Mode on page 131.
G. Driver Information Center Controls. See
Driver Information Center (DIC) on page 257.
H. Audio System. SeeAudio System(s) on
page 286.
I. Exterior Lamps Control. SeeExterior Lamps
on page 215.
J. Dome Lamp Override Button. SeeDome Lamp
Override on page 220.
K. Automatic Transfer Case Control. (If Equipped).
SeeFour-Wheel Drive on page 132.
L. Cruise Control Buttons. SeeCruise Control
on page 212.M. Tilt Wheel Lever. SeeTilt Wheel on page 207.
N. Horn. SeeHorn on page 206.
O. Audio Steering Wheel Controls. SeeAudio
Steering Wheel Controls on page 347.
P. Dual Climate Controls or Dual Automatic
Climate Controls (If Equipped). SeeDual
Climate Control System on page 227orDual
Automatic Climate Control System on
page 230.
Q. Accessory Power Outlets. SeeAccessory
Power Outlet(s) on page 226. Cigarette Lighter
(If Equipped). SeeAshtray(s) and Cigarette
Lighter on page 226.
R. StabiliTrak
®Button. SeeStabiliTrak®System
on page 359. Pedal Adjust Button (If Equipped).
SeeAdjustable Throttle and Brake Pedal
on page 126. Rear Park Assist Disable
Button (If Equipped). SeeUltrasonic Rear
Parking Assist (URPA) on page 222. Heated
Windshield Washer Fluid Button (If Equipped).
SeeWindshield Washer on page 211. Power
Running Boards Disable Button (If Equipped).
SeePower Running Boards on page 115.
S. Glove Box. SeeGlove Box on page 170.
205

Vehicle Identication
Vehicle Identication Number (VIN)
This is the legal identier for your vehicle.
It appears on a plate in the front corner of the
instrument panel, on the driver side. You can
see it if you look through the windshield from
outside your vehicle. The VIN also appears on
the Certication/Tire and Service Parts labels
and the certicates of title and registration.
Engine Identication
The eighth character in the VIN is the engine
code. This code helps you identify your vehicle’s
engine, specications, and replacement parts.
Service Parts Identication Label
This label is on the inside of the glove box.
It is very helpful if you ever need to order parts.
The label has the following information:
Vehicle Identication Number (VIN)
Model designation
Paint information
Production options and special equipment
Do not remove this label from the vehicle.
546

F
Filter
Engine Air Cleaner................................... 451
Finish Damage............................................ 544
Fixed Mast Antenna.................................... 349
Flashers, Hazard Warning........................... 206
Flash-to-Pass.............................................. 209
Flat Tire...................................................... 515
Flat Tire, Changing...................................... 516
Flat Tire, Storing......................................... 533
Fluid
Automatic Transmission............................ 454
Power Steering........................................ 469
Windshield Washer.................................. 470
Fog Lamp Light........................................... 255
Fog Lamps.................................................. 218
Four-Wheel Drive...............................132, 483
Front Armrest Storage Area......................... 171
Front Axle................................................... 484
Fuel............................................................ 435
Additives.................................................. 437
California Fuel.......................................... 436
E85 (85% Ethanol)................................... 438
Filling a Portable Fuel Container.............. 442
Filling Your Tank...................................... 440
Fuels in Foreign Countries....................... 439Fuel (cont.)
Gage....................................................... 256
Gasoline Octane...................................... 436
Gasoline Specications............................ 436
Fuses
Center Instrument Panel Fuse Block........ 550
Fuses and Circuit Breakers...................... 548
Instrument Panel Fuse Block................... 548
Underhood Fuse Block............................. 551
Windshield Wiper..................................... 547
G
Gage
Engine Coolant Temperature.................... 249
Fuel......................................................... 256
Oil Pressure............................................. 253
Speedometer........................................... 241
Tachometer.............................................. 241
Voltmeter Gage........................................ 246
Garage Door Opener..........................159, 160
Gasoline
Octane..................................................... 436
Specications........................................... 436
Glove Box................................................... 170
GM Mobility Reimbursement Program.......... 588
608

Seats (cont.)
Rear Seat Operation.................................. 19
Reclining Seatbacks................................... 14
Secondary Latch System............................. 529
Securing a Child Restraint
Center Front Seat Position......................... 67
Rear Seat Position..................................... 65
Right Front Seat Position........................... 68
Security Light.............................................. 255
Service........................................................ 432
Accessories and Modications.................. 433
Adding Equipment to the Outside
of Your Vehicle..................................... 435
California Proposition 65 Warning............. 433
Doing Your Own Work............................. 434
Engine Soon Light................................... 250
Publications Ordering Information............. 600
Servicing Your Airbag-Equipped
Vehicle....................................................... 86
Sheet Metal Damage................................... 544
Shifting Into Park (P)................................... 139
Shifting Out of Park (P)............................... 141
Shoulder Belt Height Adjuster........................ 34
Signals, Turn and Lane-Change.................. 208Spare Tire................................................... 536
Installing.................................................. 522
Removing................................................ 518
Storing..................................................... 533
Specications, Capacities............................ 556
Speedometer............................................... 241
StabiliTrak
®System..................................... 359
StabiliTrak®Indicator Light........................... 248
Starting Your Engine................................... 124
Steering...................................................... 363
Steering Wheel Controls, Audio................... 347
Steering Wheel, Tilt Wheel.......................... 207
Storage Areas
All-Weather Cargo Area........................... 186
Center Console Storage Area................... 171
Center Overhead Console........................ 171
Cupholder(s)............................................ 170
Front Armrest Storage Area...................... 171
Glove Box................................................ 170
Luggage Carrier....................................... 171
Rear Storage Area................................... 173
Top-Box Storage...................................... 191
Stuck in Sand, Mud, Ice, or Snow............... 400
Sun Visors.................................................. 118
Sunroof....................................................... 199
615
