Seats and Restraint Systems
....................... 7
Front Seats
.............................................. 9
Rear Seats
............................................. 14
Safety Belts
............................................ 15
Child Restraints
...................................... 38
Airbag System
........................................ 64
Restraint System Check
......................... 80
Features and Controls
................................ 83
Keys
....................................................... 85
Doors and Locks
.................................... 98
Windows
............................................... 104
Theft-Deterrent Systems
....................... 107
Starting and Operating Your Vehicle
..... 111
Mirrors
.................................................. 127
OnStar
®System
................................... 132
Universal Home Remote System
.......... 135
Storage Areas
...................................... 146
Sunroof
................................................ 147
Vehicle Personalization
......................... 148Instrument Panel
....................................... 175
Instrument Panel Overview
................... 178
Climate Controls
................................... 230
Warning Lights, Gages, and
Indicators
.......................................... 241
Driver Information Center (DIC)
............ 258
Audio System(s)
................................... 280
Driving Your Vehicle
................................. 315
Your Driving, the Road, and
Your Vehicle
..................................... 316
Towing
................................................. 355
Service and Appearance Care
.................. 359
Service
................................................. 362
Fuel
...................................................... 365
Checking Things Under the Hood
......... 372
All-Wheel Drive
..................................... 414
Rear Axle
............................................. 416
Front Axle
............................................ 417
Bulb Replacement
................................ 417
2007 Cadillac STS/STS-V Owner ManualM
1

Front Seats
Power Seats
The power seat
controls are located
on the outboard side
of the seats.
To adjust the seat, do any of the following:
Move the seat forward or rearward by sliding
the horizontal control forward or rearward.
Raise or lower the front part of the seat
cushion by moving the front of the horizontal
control up or down.
Raise or lower the rear part of the seat
cushion by moving the rear of the horizontal
control up or down.
Use the vertical control to recline the seatback.
SeePower Reclining Seatbacks on page 11.If your vehicle has the memory feature, you can
program and recall memory settings for seat
positions. SeeMemory Seat, Mirrors and
Steering Wheel on page 169.
Power Lumbar
Your vehicle’s seats may be equipped with
power lumbar.
You can increase or
decrease lumbar
support in an area of
the lower seatback with
this control, located
on the outboard sides
of the front seat(s).
To increase support, press and hold the front
of the control. To decrease support, press and
hold the rear of the control. Let go of the control
when the lower seatback reaches the desired
level of support.
9

Keys.............................................................. 85
Keyless Access System.............................. 87
Keyless Access System Operation.............. 88
Doors and Locks.......................................... 98
Door Locks................................................. 98
Power Door Locks....................................... 99
Programmable Automatic Door Locks.......... 99
Rear Door Security Locks......................... 100
Lockout Protection..................................... 101
Trunk........................................................ 101
Windows...................................................... 104
Power Windows........................................ 105
Sun Visors................................................ 107
Theft-Deterrent Systems............................. 107
Theft-Deterrent System.............................. 108
Valet Lockout Switch................................. 110
Starting and Operating Your Vehicle......... 111
New Vehicle Break-In................................ 111
Ignition Positions....................................... 111
Retained Accessory Power (RAP)............. 112
Starting the Engine.................................... 113Engine Coolant Heater.............................. 115
Automatic Transmission Operation............. 116
Parking Brake........................................... 121
Shifting Into Park (P) ................................. 122
Shifting Out of Park (P)............................. 124
Parking Over Things That Burn................. 124
Engine Exhaust......................................... 125
Running the Engine While Parked............. 126
Mirrors......................................................... 127
Automatic Dimming Rearview Mirror
with Intellibeam™ and OnStar
®.............. 127
Automatic Dimming Rearview Mirror.......... 127
Automatic Dimming Rearview Mirror
with OnStar
®.......................................... 127
Automatic Dimming Rearview Mirror
with OnStar
®and Compass................... 128
Outside Power Heated Mirrors................... 130
Outside Automatic Dimming Mirror............. 131
Outside Convex Mirror............................... 131
Outside Parallel Park Assist Mirror............ 131
OnStar
®System.......................................... 132
Section 2 Features and Controls
83

Universal Home Remote System................ 135
Universal Home Remote System
(With Three Round LED)....................... 135
Universal Home Remote System
(With One Triangular LED)..................... 136
Universal Home Remote System
Operation (With Three Round LED)....... 137
Universal Home Remote System Operation
(With One Triangular LED)...................... 142Storage Areas............................................. 146
Glove Box................................................. 146
Cupholder(s).............................................. 146
Center Console Storage Area.................... 146
Convenience Net....................................... 146
Sunroof....................................................... 147
Vehicle Personalization.............................. 148
Memory Seat, Mirrors and
Steering Wheel...................................... 169
Section 2 Features and Controls
84

Window Lockout
o
(Window Lockout):The rear window lockout
button is located on the driver’s door armrest
near the window switches. Press this button to
disable the rear window controls. The light on the
button will illuminate, indicating that the feature
is in use. The rear windows can be raised or
lowered using the driver’s window switches when
the lockout feature is on. To restore power to
the rear windows, press the button again. The light
on the button will go out.
The front passenger window can be programmed
to be disabled using the window lockout button.
SeeVehicle Personalization on page 148.
Secure Car Feature
The windows can be closed by pressing the lock
button on the keyless access transmitter. See
Keyless Access System Operation on page 88for
more information. The window, if down, will
express-up. If any window was unable to
completely close, it will reverse and the horn will
chirp. See “Anti-Pinch Feature” previously.
The engine must be off to operate this feature.
Sun Visors
Swing down the visor or detach it from the center
mount and move to the side to block out glare.
The visors also have side-to-side slide capability
for greater coverage.
Lighted Visor Vanity Mirrors
Pull the visor down and lift the cover. Move the
slide switch up or down to brighten or dim
the lamp.
Theft-Deterrent Systems
Vehicle theft is big business, especially in some
cities. Although your vehicle has a number of
theft-deterrent features, we know that nothing
we put on it can make it impossible to steal.
107

Mirrors
Automatic Dimming Rearview Mirror
with Intellibeam™ and OnStar
®
Your vehicle may have an Intellibeam™ inside
rearview mirror with OnStar®controls. For
more information about OnStar®, seeOnStar®
System on page 132.
To turn on and enable Intellibeam™, press and
release the Intellibeam™ button on the inside rear
view mirror. If the vehicle has the IntelliBeam™
Intelligent High-Beam Headlamp Control System,
the on/off button can also be used to turn off
or reset this system. See “IntelliBeam™ Intelligent
High-Beam Headlamp Control System” under
Headlamps on page 211.
Automatic Dimming Rearview Mirror
Your vehicle may have an automatic dimming
rearview mirror.
O(On/Off):Press and hold the button, located
on the lower left side of the mirror face, for
about three seconds to turn the automatic dimming
feature on or off. The indicator light will illuminate
when this feature is active. The automatic
dimming feature is active each time the vehicle is
started.
Automatic Dimming Rearview Mirror
with OnStar
®
Your vehicle may have an automatic dimming
rearview mirror that also contains OnStar®
controls. For more information on OnStar®, see
OnStar®System on page 132.
127

Mirror Operation
O
(On/Off):Press and hold the button, located
on the lower left side of the mirror face, for about
three seconds to turn the automatic dimming
feature on or off. The indicator light will illuminate
when this feature is active. The automatic dimming
feature is active each time the vehicle is started.
Cleaning the Mirror
When cleaning the mirror, use a paper towel or
similar material dampened with glass cleaner.
Do not spray glass cleaner directly on the mirror
as that may cause the liquid cleaner to enter
the mirror housing.
Automatic Dimming Rearview Mirror
with OnStar
®and Compass
Your vehicle may have an automatic dimming
rearview mirror with a compass display. The mirror
also contains OnStar
®controls. For more
information seeOnStar®System on page 132.
The mirror includes an eight-point compass display
in the upper right corner of the mirror face.
When on, the compass automatically calibrates as
the vehicle is driven.
Mirror Operation
O
(On/Off):Press and hold the button, located
on the lower left side of the mirror face, for about
three seconds to turn the automatic dimming
feature on or off. The indicator light will illuminate
when this feature is active. The automatic dimming
feature is active each time the vehicle is started.
Compass Operation
Press the on/off button once to turn the compass
on or off.
When the ignition and the compass feature are
on, the compass will show two character boxes
for about two seconds. After two seconds,
the mirror will display the compass heading.
Compass Calibration
If after two seconds, the display does not show a
compass heading (for example, N for North),
there may be a strong magnetic eld interfering
with the compass. Such interference may be
caused by a magnetic antenna mount, magnetic
note pad holder or a similar magnetic item. If
the letter C should ever appear in the compass
window, the compass may need calibration.
128

Cleaning the Mirror
When cleaning the mirror, use a paper towel or
similar material dampened with glass cleaner.
Do not spray glass cleaner directly on the mirror
as that may cause the liquid cleaner to enter
the mirror housing.
Outside Power Heated Mirrors
The power mirror
control is on the driver’s
door armrest and
controls the driver’s
side and passenger’s
side mirrors.
Move the selector switch left or right to choose the
driver’s side or passenger’s side mirror. Use the
arrows located on the control pad to adjustthe position of each mirror. Adjust each mirror so
you can see the side of your vehicle and the
area behind your vehicle. Return the selector
switch to the center position when nished
adjusting. This will prevent unwanted mirror
movement in case the control pad is accidentally
bumped while driving.
The preferred mirror positions can be stored with
the memory option. SeeMemory Seat, Mirrors
and Steering Wheel on page 169.
The mirrors can be manually folded inward to
prevent damage when going through car washes
or conned spaces. To fold, push the mirror
toward the vehicle. To return the mirror to its
original position, push outward. Be sure to return
both mirrors to their original unfolded position
before driving.
When the rear window defogger is turned on, both
outside rear view mirrors are heated to help
clear them of ice, snow, or condensation. See
“Rear Window Defogger” underDual Climate
Control System on page 230.
130
