Page 458 of 560
9. In ate the tire up to the recommended
in ation pressure, found on the Tire and
Loading Information label located on
the vehicle’s center pillar (B-pillar) below the
vehicle’s door latch, using the air pressure
gage on the top of the unit.
The pressure gage reading is slightly high
while the compressor is on. Turn the
compressor off to get an accurate pressure
reading.
Notice:If the recommended pressure cannot
be reached after 15 minutes, the vehicle
should not be driven farther. Damage to the
tire is severe and the sealant will not be
effective. Remove the air compressor plug
from the accessory power outlet and unscrew
the in ating hose from the tire valve. See
Roadside Service on page 531.
10. Move the in ator kit switch to the O (off)
position once the correct tire pressure is
obtained.11. Turn off the engine.
12. Unplug the air compressor accessory plug
from the accessory power outlet in the
vehicle.
13. Disconnect the sealant lling hose from the
tire valve stem, by turning it counterclockwise,
and replace the tire valve stem cap.
Be careful when handling the tire in ator
components as they may be hot after usage.
14. Wrap the sealant lling hose around the air
compressor channel to stow it in its original
location.
15. Stow the air compressor accessory plug back
in the air compressor. To do this, wrap the air
compressor accessory plug, snap in the
plug, and then push in the bottom and then
the top of the wrapped air compressor
accessory plug.
458
Page 461 of 560
4. Push the air compressor in ator hose onto the
tire valve stem and push the lever down to
secure in place.
5. Plug the air compressor accessory plug into
an accessory power outlet in the vehicle. See
Accessory Power Outlet(s) on page 228for
more information.
{CAUTION:
Idling the engine in a closed-in place or
with the climate control system off can
cause deadly carbon monoxide (CO). See
Engine Exhaust on page 125.
6. Start the vehicle. SeeStarting the Engine on
page 113for more information. The vehicle
must be running while using the air
compressor.
{CAUTION:
In ating something too much can make it
explode, and you or others could be
injured. Be sure to read the in ator
instructions, and in ate the tire to its
recommended pressure. Do not exceed
36 psi (248 kPa).
7. Move the in ator kit switch to the I (on)
position.
8. Make sure there is a proper connection
between the tire valve stem and the air
compressor hose by looking at the air
pressure gage. If there is not a pressure
reading while the compressor is running, the
connection between the in ator kit and
the tire is bad.
Check the attachment between the air
compressor hose and the tire valve stem.
461
Page 464 of 560
Changing a Flat Tire
If you have an STS-V model, there is no spare tire
and no tire changing equipment. Your vehicle is
equipped with run- at tires. SeeRun-Flat
Tires (STS-V) on page 429for more information. If
you have an STS model, your vehicle may be
equipped with a tire in ator kit. SeeTire In ator Kit
on page 452for more information. If your vehicle
is not equipped with a tire in ator kit, follow
the directions for changing a at tire in this section.
If a tire goes at, avoid further tire and wheel
damage by driving slowly to a level place. Turn on
your vehicle’s hazard warning ashers. See
Hazard Warning Flashers on page 180for more
information.{CAUTION:
Changing a tire can be dangerous. The
vehicle can slip off the jack and roll over
or fall on you or other people. You and
they could be badly injured or even killed.
Find a level place to change your tire. To
help prevent the vehicle from moving:
1. Set the parking brake rmly.
2. Put the shift lever in PARK (P).
3. Turn off the engine and do not restart
while the vehicle is raised.
4. Do not allow passengers to remain in
the vehicle.
To be even more certain the vehicle will
not move, you should put blocks at the
front and rear of the tire farthest away
from the one being changed. That would
be the tire, on the other side, at the
opposite end of the vehicle.
464
Page 485 of 560
Vehicle Identi cation
Vehicle Identi cation Number (VIN)
This is the legal identi er for your vehicle. It
appears on a plate in the front corner of the
instrument panel, on the driver side. You can see
it if you look through the windshield from outside
your vehicle. The VIN also appears on the Vehicle
Certi cation and Service Parts labels and the
certi cates of title and registration.
Engine Identi cation
The eighth character in the VIN is the engine
code. This code helps you identify your vehicle’s
engine, speci cations, and replacement parts.
Service Parts Identi cation Label
This label is on your spare tire cover. It is
very helpful if you ever need to order parts. The
label has the following information:
Vehicle Identi cation Number (VIN)
Model designation
Paint information
Production options and special equipment
Do not remove this label from the vehicle.
485
Page 487 of 560
Power Windows and Other Power
Options
Circuit breakers protect the power windows and
power seats. When the current load is too
heavy, the circuit breaker opens and closes,
protecting the circuit until the problem is xed or
goes away.
Fuses and Circuit Breakers
The wiring circuits in your vehicle are protected
from short circuits by a combination of fuses,
circuit breakers and fusible thermal links.
This greatly reduces the chance of res caused by
electrical problems.Look at the silver-colored band inside the fuse. If
the band is broken or melted, replace the fuse.
Be sure you replace a bad fuse with a new one of
the identical size and rating. If a fuse should
blow, see your dealer for service immediately.
If you ever have a problem on the road
and don’t have a spare fuse, you can borrow
one that has the same amperage. Just pick some
feature of your vehicle that you can get along
without – like the radio or cigarette lighter – and
use its fuse, if it is the correct amperage. Replace
it as soon as you can.
The fuses are located in three fuse blocks.
One is located in the engine compartment, on the
passenger’s side of the vehicle, and the other
two are located under the rear seat on both the
driver’s and passenger’s side of the vehicle.
487
Page 489 of 560
The underhood fuse block is located in the front of
the engine compartment on the passenger’s
side of the vehicle. SeeEngine Compartment
Overview on page 373for more information
on location and removal procedure for the front
compartment underhood sights shields.
To access the fuses, push in the tabs located on
each side of the fuse block cover, then lift the
cover off.
Fuses Usage
BLOWER Blower Motor
R REAR Passenger’s Side Rear Fuse Block
I/P OUTLET Front Accessory Power Outlet
CCP Climate Control, Headlamp Leveling
PRE 02/CAMOxygen Sensor, Variable Intake (V6),
Purge Solenoid (V6), Camshaft
Phasers (V6)
R REAR Passenger’s Side Rear Fuse Block
WPR SW Wiper/Washer Switch
FOG LAMP Fog Lamps
OUTLET Rear Accessory Power Outlet
EVEN COILSEven Ignition Coils, Even Fuel
Injectors
Fuses Usage
L REAR Driver’s Side Rear Fuse Block
WPR MOD Wiper Module
POST 02 Oxygen Sensor
COMP CLTCH Air Conditioner Compressor Clutch
STARTER Starter Solenoid
ABS Anti-lock Brake Pump
L REAR Driver’s Side Rear Fuse Block
RAIN SSRRain Sensor, Headlamp Washer,
Tire Pressure Monitor
CCP Climate Control
SMT BM-OPT IntelliBeam™ Relay (If Equipped)
EXT LIGHTSLow Beam Relay, High Beam Relay,
Park Lamp Relay
VOLT CHECK Instrument Panel Module
ECM/TCMEngine Control Module (ECM),
Transmission Control Module (TCM),
Easy Key Module, Instrument Panel
Cluster
SPARE Spare
SPARE Spare
LT PARKDriver’s Side Park Lamp, Driver’s
Side Taillamp
489
Page 490 of 560
Fuses Usage
LIC/DIMMINGLicense Plate, Instrument
Panel Dimming
IPM/ALDLInstrument Panel Module Assembly
Line Data Link Connector
HUDHeads-Up Display, Column Lock
Module, Steering Column Switch
V8 ECMV8 Engine Control Module (ECM),
Evap. Solenoid, Vacuum Bypass
ABS Anti-lock Brake Controller
STR RLY Starter Relay
WASH
NOZ/AQSHeated Washer Nozzles, Air
Quality Sensor
ODD COILSOdd Ignition Coils, Odd
Fuel Injectors
TCM IPCTransmission Control Module (TCM),
Instrument Panel, Engine Control
SPARE Spare
MAF Mass Air Flow Sensor (V6)
HIGH FAN Cooling Fan - High Speed
LOW FAN Cooling Fan - Low Speed
RT PARKPassenger’s Side Park Lamp,
Right TaillampFuses Usage
HORN Horn
LT HI BEAM Driver’s Side Headlamp High-Beam
LT LOW BEAM Driver’s Side Headlamp Low-Beam
RT LOW BEAMPassenger’s Side Headlamp
Low-Beam
RT HI BEAM Right Headlamp High-Beam
HFV6 ECMHigh Feature V6 Engine Control
Module (ECM), Mass Air Flow
Sensor (MAF) (V8)
Relays Usage
HDLP WASH
RELAY
JUMPER -OPTHeadlamp Washer
STARTER
RELAY MINIStarter
SPARE Spare
FOG LAMP
RELAY MICROFog Lamps
CMP CLU
RELAY MICROAir Conditioning Compressor
Clutch
490
Page 491 of 560
Relays Usage
BLOWER
RELAY MINIFront Blower Motor
POWERTRAIN
RELAY MICROEngine Controls
RUN/CRANK
RELAY MICROIgnition 1, Starter, Washer Nozzle,
Air Quality, Anti-lock Brake System,
Climate Control Panel, Transmission
Control Module, Instrument Panel
Cluster, Mass Air ow Sensor,
Engine Control Module
LOW SPEED
FAN RELAY
MINICooling Fan Low Speed
ACCESSORY
RELAY MINIIgnition 3, Rain Sensor, Headlamp
Washer, Windshield Wiper/Washer
Module
PARK LAMP
RELAY MICROParking Lamps, Instrument Panel
Dimming, Rear License Plate Lamps
HIGH BEAM
RELAY MICROHeadlamp High-Beam
LOW BEAM
RELAY/HID
MINI-OPTLow-Beam/High Intensity DischargeRelays Usage
HIGH SPEED
FAN RELAY
MINICooling Fan High Speed
S/P FAN
RELAY MINICooling Fan Series/Parallel
HORN RELAY
MICROHorn
SPARE Spare
Circuit
BreakersUsage
HDLP WASH
C/B -OPTHeadlamp Washer (If Equipped)
Harness
ConnectionUsage
ENG W/H Engine Harness Connection
BODY W/H Body Harness Connection
BODY W/H Body Harness Connection
491
