Power Lumbar
The power lumbar
controls are located on
the outboard side of
the front seats behind
the power seat controls.
Press the lumbar control forward to increase
support and rearward to decrease support. Press
the top or bottom of the control to raise or
lower the support mechanism.
The ignition does not need to be on for the power
lumbar feature to work.
Keep in mind that as your seating position
changes, as it may during long trips, so should the
position of your lumbar support. Adjust the seat
as needed.
Massaging Lumbar
If your vehicle has this
feature, the switch is
located on the outboard
side of the front
seats behind the lumbar
switch. Press the
switch to turn the
massaging lumbar
feature on. The ignition
must be on.
The massage cycle will run for up to 10 minutes.
To stop massage, press the massaging lumbar
switch again, or press the power lumbar switch.
10

Heated and Cooled Seats
Your vehicle may have heated and cooled front
seats.
To operate the heated or cooled seats, the ignition
must be on.
The buttons are located
on the front doors.
I(Heated Seatback):Press this button to turn
on the heated seatback.
H(Cooled Seat):Press this button to turn on the
cooled seat.
J(Heated Seat and Seatback):Press this
button to turn on the heated seat and seatback.
Press a button to turn on the desired feature.
A light on that button will display to show which
feature is on.
There are three temperature settings for each
feature. A column of three lights next to the buttons
will display which setting the feature is in: high,
medium or low. Three lights indicate the highest
setting, two lights for medium and one light for the
lowest setting.
When you press a button, the feature will turn on at
the highest setting. Each time you press the button,
the feature will go down one temperature setting.
To turn the feature off, keep pressing the button
until the display lights turn off.
If your vehicle has remote vehicle start and is
started using the remote keyless entry transmitter,
the front heated seats will be turned on to the high
setting if it is cold outside. See “Remote Vehicle
Start” underRemote Keyless Entry (RKE) System
Operation on page 96. When the key is inserted
into the ignition and the ignition is turned on, the
heated seat feature will turn off. To turn the heated
seat feature back on, press the desired button.
Driver’s Side Buttons
Shown, Passenger’s
Side Buttons Similar
11

If you use the remote keyless entry transmitter to
enter your vehicle and the remote recall memory
feature is on, automatic seat and mirror movement
will occur. See “MEMORY SEAT RECALL”
underDIC Vehicle Customization on page 259for
more information.
To stop recall movement of the memory feature at
any time, press one of the power seat controls,
memory buttons, power tilt wheel control, or power
mirror buttons.
If something has blocked the driver’s seat and/or
the steering column while recalling a memory
position, the driver’s seat and/or the steering
column recall may stop. If this happens remove
the obstruction, then press the appropriate control
for the area that is not recalling for two seconds.
Try recalling the memory position again by
pressing the appropriate memory button. If the
memory position is still not recalling, see
your dealer for service.Easy Exit Seat
The control for this feature is located on the
driver’s door panel between buttons 1 and 2.
With the vehicle in PARK (P), the exit position can
be recalled by pressing the exit button. You will
hear a single beep. The driver’s seat will move
back, and if the vehicle has the power tilt wheel and
telescopic steering feature, the power telescopic
steering column will move up and forward.
If the easy exit seat feature is on in the DIC,
automatic seat and power telescopic steering
column movement will occur when the key
is removed from the ignition. See “EASY EXIT
SEAT” underDIC Vehicle Customization on
page 259for more information.
Further programming for automatic seat and
steering wheel movement can be done using the
Driver Information Center (DIC). You can select
or not select the following:
The easy exit seat feature
The memory seat recall feature
For programming information, seeDIC Vehicle
Customization on page 259.
13

Center Seat
Your vehicle may have a front center seat. This
seat can be converted to a storage area by
lowering the seatback. SeeCenter Flex Storage
Unit on page 156.
For information on safety belts for this position,
seeCenter Front Passenger Position on page 35.
Rear Seats
Heated Seats
Your vehicle may have heated rear seats.
To operate the rear heated seats, the ignition
must be on.
The buttons are located
on the rear doors.
I(Heated Seatback):Press this button to turn
on the heated seatback.
J(Heated Seat and Seatback):Press this
button to turn on the heated seat and seatback.
17

Press a button to turn on the desired feature. A
light on that button will display to show which
feature is on.
There are three temperature settings for each
feature. A column of three lights next to the
buttons will display which setting the feature is in:
high, medium or low. Three lights indicate the
highest setting, two lights for medium and one light
for the lowest setting.
When you press a button, the feature will turn on
at the highest setting. Each time you press the
button, the feature will go down one temperature
setting.
To turn the feature off, keep pressing the button
until the display lights turn off.
Rear Seat Pass-Through Door
Your vehicle has a pass-through door that provides
access to the trunk from the rear seats. See
“Rear Seat Pass-Through Door” underTrunk on
page 106.
Power Lumbar
Your vehicle may be equipped with four-way
lumbar support, without the massage feature, for
the outboard rear seat positions.
The rear lumbar support
controls are located on
the rear doors in
front of the heated seat
buttons.
To turn on the lumbar support feature, press the
front of the control to increase support or rearward
to decrease support. The lumbar control can
also be moved up and down to adjust the location
of the support.
The ignition does not need to be on for the power
lumbar feature to work.
18

In many crashes severe enough to inate the
airbag, windshields are broken by vehicle
deformation. Additional windshield breakage may
also occur from the right front passenger airbag.
Airbags are designed to inate only once. After
an airbag inates, you will need some new
parts for the airbag system. If you do not get
them, the airbag system will not be there to help
protect you in another crash. A new system will
include airbag modules and possibly other
parts. The service manual for your vehicle
covers the need to replace other parts.
Your vehicle has a crash sensing and
diagnostic module which records information
after a crash. SeeVehicle Data Recording and
Privacy on page 500andEvent Data
Recorders on page 500.
Let only qualied technicians work on the
airbag systems. Improper service can mean
that an airbag system will not work properly.
See your dealer/retailer for service.
Passenger Sensing System
Your vehicle has a passenger sensing system.
The passenger airbag status indicator on the
overhead console will be visible when you turn
your ignition key to RUN or START.
The words ON and OFF or the symbol for on and
off, will be visible during the system check.
When the system check is complete, either the
word ON or the word OFF, or the symbol for on or
the symbol for off will be visible. SeePassenger
Airbag Status Indicator on page 227.
United StatesCanada
81

SeeAdding Equipment to Your Airbag-Equipped
Vehicle on page 87for more information about
modications that can affect how the system
operates.
{CAUTION:
Stowing of articles under the passenger’s
seat or between the passenger’s seat
cushion and seatback may interfere with
the proper operation of the passenger
sensing system.
Servicing Your Airbag-Equipped
Vehicle
Airbags affect how your vehicle should be serviced.
There are parts of the airbag system in several
places around your vehicle. You do not want the
system to inate while someone is working on your
vehicle. Your dealer/retailer and the service manual
have information about servicing your vehicle and
the airbag system. To purchase a service manual,
seeService Publications Ordering Information on
page 498.
{CAUTION:
For up to 10 seconds, after the ignition is
turned off and the battery is disconnected,
an airbag can still inate during improper
service. You can be injured if you are
close to an airbag when it inates. Avoid
yellow connectors. They are probably part
of the airbag system. Be sure to follow
proper service procedures, and make sure
the person performing work for you is
qualied to do so.
The airbag system does not need regular
maintenance.
86

Keys.............................................................. 93
Remote Keyless Entry (RKE) System.......... 95
Remote Keyless Entry (RKE) System
Operation................................................. 96
Doors and Locks........................................ 102
Door Locks................................................ 102
Central Door Unlocking System................. 103
Power Door Locks..................................... 103
Programmable Automatic Door Locks........ 104
Rear Door Security Locks......................... 104
Lockout Protection..................................... 105
Trunk........................................................ 106
Windows...................................................... 108
Power Windows........................................ 109
Sun Visors................................................ 111
Theft-Deterrent Systems............................. 112
Valet Lockout Switch................................. 112
Content Theft-Deterrent............................. 113
PASS-Key
®III+......................................... 115
PASS-Key®III+ Operation......................... 115Starting and Operating Your Vehicle......... 117
New Vehicle Break-In................................ 117
Ignition Positions....................................... 118
Retained Accessory Power (RAP)............. 119
Starting the Engine.................................... 119
Engine Coolant Heater.............................. 121
Automatic Transaxle Operation.................. 122
Performance Shifting................................. 125
Parking Brake........................................... 125
Shifting Into Park (P)................................. 126
Shifting Out of Park (P)............................. 129
Parking Over Things That Burn................. 129
Engine Exhaust......................................... 130
Running the Engine While Parked............. 131
Mirrors......................................................... 132
Automatic Dimming Rearview Mirror with
Intellibeam™, OnStar
®, and Compass.... 132
Automatic Dimming Rearview Mirror
with OnStar
®and Compass................... 134
Automatic Dimming Rearview Mirror
with Compass........................................ 136
Section 2 Features and Controls
91
