2007 CADILLAC CTS display

Tire Pressure Warning Message
When you see this
ashing symbol, one or
more of the vehicle’s
tires is either under
or over-inated.
To acknowledge this warning, press either button
on the outboard switch on the left spoke of the
steering wheel. There are three levels of warning
for this display:
1. High Tire Pressure (above 42 psi (290 kPa))
2. Low Tire Pressure (below 25 psi (170 kPa))
3. Flat Tire (below 5 psi (35 kPa))For conditions 1 and 2, this warning will ash
ve times and the display will then show the tire
pressure gage. For condition 3, this warning
will ash continuously until the driver
acknowledges it. In any of the three cases, the
warning will redisplay every 10 minutes until
the situation is corrected. Conditions 2 and 3 will
also display a warning light elsewhere on the
cluster that will stay on after this warning is
acknowledged. SeeTire Pressure Light (CTS-V
Only) on page 208for more information. Also see
Tire Pressure Monitor System on page 405for
more information on tire pressure specications.
221

One-to-Four Shift Message
(CTS-V Only)
This message indicates
that you can only shift
from FIRST (1) to
FOURTH (4) instead of
FIRST (1) to
SECOND (2).
You must complete the shift into FOURTH (4) to
turn off this feature. This helps you get the
best possible fuel economy.
After shifting to FOURTH (4), you may downshift
to a lower gear if you prefer.
SeeManual Transmission Operation on page 126
for more information.
Notice:Forcing the shift lever into any gear
except FOURTH (4) when the 1 TO 4 SHIFT
message comes on may damage the
transmission. Shift only from FIRST (1) to
FOURTH (4) when the light comes on.
Driver Information Center (DIC)
The DIC gives you the status of many of your
vehicle’s systems. It is also used to display driver
personalization features and warning/status
messages. All messages will appear on the audio
system display.
If your vehicle has the Base audio system, use the
information contained in this manual for
instructions on operating the DIC for your vehicle.
If your vehicle has the Navigation system, see
the Navigation system manual for instructions on
operating the DIC for your vehicle.
222

System Controls
Use the following controls located on the audio
system to operate the DIC:
INFO (Information):Press the up or down arrows
on this switch, located on the right side of the
audio system, to scroll through the system status
information.CLR (Clear):Press this button, located on the
right side of the audio system, to clear DIC
messages and to reset some DIC displays to zero.
This button is also used to exit out of a menu.
SeeDIC Warnings and Messages on page 232
andStatus of Vehicle Systems on page 223
for more information.
TUNE/SEL (Select) Knob:Turn this knob, located
in the lower right corner of the audio system, to
scroll through the menu items displayed. Press this
knob to select the menu item.
Status of Vehicle Systems
You can view the status of several vehicle
systems using the DIC.
223

Vehicle Information Menu
To access this menu, press the up or down arrow
on the INFO switch located to the right of the
display.
The following items are available when the ignition
is in ON. These items will not be available when
the ignition is in ACCESSORY. The tire pressure
menu items are only available if your vehicle
has the Tire Pressure Monitor (TPM) system:
OUTSIDE TEMP
MI TRIP A (KM TRIP A)*
MI TRIP B (KM TRIP B)*
MILES RANGE (KM RANGE)
MPG AVG (L/100 KM AVG)*
MPG INST (L/100 KM INST)
GAL FUEL USED (L FUEL USED)*
AVG MPH (AVG KM/H)*
TIMER*
BATTERY VOLTS
ENGINE OIL LIFE*
TRANS FLUID LIFE* (Automatic
Transmission Only)
PSI LF TIRE (KPA LF TIRE)
PSI RF TIRE (KPA RF TIRE)
PSI RR TIRE (KPA RR TIRE)
PSI LR TIRE (KPA LR TIRE)
BLANK LINE
*These items can be reset. Each one must be
reset individually. For a detailed description of the
menu items and how to reset them, see “Vehicle
Information Menu Item Descriptions” later in
this section.
You can view any of these items at any time, but
only one item can be displayed at a time.
224

Vehicle Information Menu Item
Descriptions
The following paragraphs contain a more detailed
description of each menu item:
OUTSIDE TEMP:If you select this item, the
current outside temperature is displayed at the top
of the screen. It will be in either degrees
Fahrenheit (°F) or degrees Celsius (°C) depending
upon whether the system is set for English or
metric units. If you wish to change the units, see
DIC Main Menu on page 228.
MI TRIP A and B (KM TRIP A and B):For
information on the trip odometers, seeTrip
Odometers on page 200.
MILES RANGE (KM RANGE):If you select this
item, the approximate number of remaining
miles or kilometers you can drive without refueling
is displayed. This estimate is based on the
current driving conditions and will change if the
driving conditions change. For example, if you are
driving in traffic making frequent stops, the
display may read one number, but if you enter the
freeway, the number may change even thoughyou still have the same amount of gas in the gas
tank. This is because different driving conditions
produce different fuel economies. Generally,
freeway driving produces better fuel economy than
city driving.
If your vehicle is low on fuel, the Fuel Level Low
message will be displayed. See “Fuel Level
Low” underDIC Warnings and Messages on
page 232for more information.
MPG AVG (L/100 KM AVG):If you select this
item, the approximate average miles per
gallon (mpg) or liters per 100 kilometers (L/100 km)
is displayed. This number is calculated based
on the number of mpg (L/100 km) recorded since
the last time this menu item was reset.
To reset the MPG AVG (L/100 KM AVG), press
the CLR button located to the right of the screen.
The display will return to zero.
MPG INST (L/100 KM INST):If you select this
item, the current fuel economy is displayed. This
number reects only the fuel economy that the
vehicle has right now and will change frequently as
driving conditions change. Unlike average fuel
economy, this menu item cannot be reset.
225

GAL FUEL USED (L FUEL USED):If you select
this item, the number of gallons or liters of fuel
used since the last reset of this menu item
is displayed.
To reset GAL FUEL USED (L FUEL USED), press
the CLR button located to the right of the screen.
The display will return to zero.
AVG MPH (AVG KM/H):If you select this item,
the average speed of the vehicle is displayed
in miles per hour (mph) or kilometers per
hour (km/h). This average is calculated based on
the various vehicle speeds recorded since the
last reset of this menu item.
To reset AVG MPH (AVG KM/H), press the
CLR button located to the right of the screen.
The display will return to zero.
TIMER:If you select this item, a timing feature is
displayed. The timer functions like a stopwatch
in that you can record the time it takes to
travel from one point to another.
To turn on the timer, press the CLR button located
to the right of the screen once. The display will
read 00:00:00 TIMER ON and begin counting.To turn off the timer, press the CLR button again.
When the timer is off, the display will show the
timer value and TIMER OFF. The timing feature
will stop.
To reset the timer, turn off the timer and then
press and hold the CLR button. The display will
return to zero.
BATTERY VOLTS:If you select this item, the
current battery voltage is displayed. If the voltage
is in the normal range, the display will have
OK after it. For example, the display may read
13.2 BATTERY VOLTS OK.
If there is a problem with the battery charging
system, there are four possible DIC messages that
may be displayed. SeeDIC Warnings and
Messages on page 232for more information.
ENGINE OIL LIFE:If you select this item,
the percentage of remaining oil life is displayed.
If you see 99% ENGINE OIL LIFE on the display,
that means that 99% of the current oil life remains.
226

When the oil life is depleted, the Change Engine
Oil message will appear on the display. See
your dealer for service. In addition to the engine
oil life system monitoring the oil life, additional
maintenance is recommended in the Maintenance
Schedule in this manual. SeeScheduled
Maintenance on page 462andEngine Oil on
page 346for more information.
When you reset the Change Engine Oil message
by clearing it from the display, you still must reset
the engine oil life system separately. For more
information on resetting the engine oil life system,
see “How to Reset the Engine Oil Life System
and the Oil Life Indicator” underEngine Oil
Life System on page 349. If you clear the Change
Engine Oil message from the display, it will not
re-appear.
TRANS FLUID LIFE (Automatic Transmission):
If you select this item, the percentage of
remaining transmission uid life is displayed.
If you see 99% TRANS FLUID LIFE on the display,
that means that 99% of the current transmission
uid life remains.When the transmission uid life is depleted, the
Change Trans Fluid message will appear on
the display. You should change the transmission
uid as soon as possible. Be sure to keep a written
record of the mileage and date of the uid
change so you will have it for future reference.
SeeScheduled Maintenance on page 462
andRecommended Fluids and Lubricants on
page 473for more information.
When you reset the Change Trans Fluid message
by clearing it from the display, you still must
reset the transmission uid life monitor separately.
For more information on resetting the transmission
uid life monitor, seeAutomatic Transmission
Fluid on page 353.
LF TIRE:If you select this item, the driver’s side
front tire pressure will be displayed. If the tire
pressure is low, LOW will be displayed with this
item. The pressure can be displayed in pounds per
square inch (PSI) or kilopascals (KPA). To change
the units, seeDIC Main Menu on page 228
DIC Main Menu.
227

RF TIRE:If you select this item, the passenger’s
side front tire pressure will be displayed. If the
tire pressure is low, LOW will be displayed
with this item. The pressure can be displayed in
pounds per square inch (PSI) or kilopascals (KPA).
To change the units, seeDIC Main Menu on
page 228DIC Main Menu.
RR TIRE:If you select this item, the passenger’s
side rear tire pressure will be displayed. If the
tire pressure is low, LOW will be displayed
with this item. The pressure can be displayed in
pounds per square inch (PSI) or kilopascals (KPA).
To change the units, seeDIC Main Menu on
page 228DIC Main Menu.
LR TIRE:If you select this item, the driver’s side
rear tire pressure will be displayed. If the tire
pressure is low, LOW will be displayed with this
item. The pressure can be displayed in pounds per
square inch (PSI) or kilopascals (KPA). To change
the units, seeDIC Main Menu on page 228
DIC Main Menu.
BLANK LINE:If you select this item, nothing is
displayed at the top of the screen.DIC Main Menu
Accessing the DIC Main Menu
To access the main menu of the DIC, do the
following:
1. Press the PWR/VOL knob to turn the radio on.
2. Press the TUNE/SEL knob once.
3. Turn the TUNE/SEL knob clockwise or
counterclockwise to scroll through the
menu items.
The DIC main menu consists of the following
menu items:
eBASS - MID - TREBLE
eEQ
DSP (Bose®Audio System)
AVC (Bose®Audio System)
H/A
AUTOSTORE PRESETS
CAT
TA
MSG RECALL RDS MESSAGE
228
