2007 BMW MOTORRAD K 1200 R fuel consumption

If you prefer, you can use but-
ton2for this purpose.
The tripmeter is reset to zero. with OE On-board computer
or with OE Tyre-pressure
monitoring (RDC):
Press and hold down button 2.
In this case, the button
on the handlebar fitting
is for operating the on-board
computer or calling up the RDC
readings.
Residual rangeResidual-range reading appears
accompanied by the wordRANGE
and indicates how
far you can ride with the fuel
remaining in the tank. This
reading is not displayed until fuel
level has dropped to reserve.
This distance is calculated on the
basis of fuel level and average
consumption.
When you refuel, the increase in
fuel level is not registered unless
several litres are added to the
fuel already in the tank.
When refuelling after running on
reserve, make sure that you top
449zOperation

up the tank to a level above re-
serve, as otherwise the sensor
will not be able to register the
new level. If the sensor cannot
register the new level neither
the fuel-level reading nor the
residual-range readout can be
updated.The calculated range is an
approximate value. Con-
sequently, BMW Motorrad re-
commends that you should not
try to use the full residual range
before refuelling.On-board computer
OE
Selecting readingsSwitch on the ignition. Press button
1.
The display starts with the cur-
rent value and each time the but-
ton is pressed it moves one step
through the following sequence: Ambient temperature Average speed
Average consumption
Range
Oil level
Tyre pressures (OE)
Ambient temperatureWhen the motorcycle is at a
standstill the heat of the engine
can falsify ambient-temperature
reading
1. If the effect of the en-
gine's heat becomes excessive,--
temporarily appears on the
display.
450zOperation

If ambient temperature
drops below 3 °C a warn-
ing appears, drawing your atten-
tion to the risk of black ice form-
ing. The display automatically
switches from any other mode
to the temperature reading when
the temperature drops below this
threshold for the first time.
Average speedAverage speed 1is calculated
on the basis of the time elapsed
since the last reset. Times
during which the engine was
stopped are excluded from the
calculation.
Resetting average speedSwitch on the ignition.
Select average speed.
Press and hold down button 1.
Average speed is reset to zero.
Average consumptionAverage consumption 1is cal-
culated by dividing the distance
covered since the last reset by
the corresponding amount of fuel
used.Resetting average
consumptionSwitch on the ignition.
Select average consumption.
451zOperation

Press and hold down button1.
Average consumption is reset
to zero.
RangeThe description of the residual-
range function ( 49) also cov-
ers the range readout. You can
also view range 1before the fuel
level drops to reserve. A special
average-consumption figure is
used to calculate range; this fig-
ure is not necessarily the same
as the value you can call up for
viewing on the display.
When the motorcycle is propped
on its side stand the slight angle
of inclination means that the
sensor cannot register the fuel
level correctly. This is the reason
why the range is calculated only when the motorcycle is on the
move.
When refuelling after running on
reserve, make sure that you top
up the tank to a level above re-
serve, as otherwise the sensor
will not be able to register the
new level. If the sensor cannot
register the new level neither the
fuel-level reading nor the range
readout can be updated.
The calculated range is only
an approximate reading.
Consequently, BMW Motorrad
recommends that you should not
try to use the full range before
refuelling.
452zOperation

Refuelling
Fuel is highly flammable. A
naked flame close to the
fuel tank can cause a fire or ex-
plosion.
Do not smoke. Never bring a
naked flame near the fuel tank.
Fuel expands when hot.
Fuel escaping from an
overfilled tank could make its way
onto the rear tyre. This could
cause a fall.
Do not fill the tank past the bot-
tom edge of the filler neck.
Fuel attacks plastics, which
become dull or unsightly.
Wipe off plastic parts immediately
if they come into contact with
fuel.
Fuel can attack the material
of the windscreen, which
becomes dull or unsightly.
Wipe off the windscreen immedi- ately if it comes into contact with
fuel.
Leaded fuel will destroy the
catalytic converter.
Use only unleaded fuel.
Make sure the ground is level
and firm and place the motor-
cycle on its stand.
Open the protective cap.
Open the fuel tank cap with
the ignition key by turning it
counter-clockwise. Refuel with fuel of the grade
stated below; do not fill the
tank past the bottom edge of
the filler neck.
Recommended fuel
grade
98 ROZ/RON (Premium plus
unleaded)
95 ROZ/RON (Premium
unleaded (fuel grade,
usable with power- and
consumption-related
restrictions))
579zRiding

FuelRecommended fuel grade98 ROZ/RON, Premium plus unleaded
95 ROZ/RON, Premium unleaded (fuel grade, us-
able with power- and consumption-related restric-
tions)
Usable fuel capacity 19 l
Reserve fuel ≥4lEngine oilEngine oil, capacity 3.5 l, with filter change
0.5 l, Difference between MIN / MAX marks
Lubricant Castrol GPS 10W-40 (SAE 10W40; API SG;
JASO MA)
Oil grades Mineral oils of API classification SF through SH.
BMW Motorrad recommends not using oil addit-
ives, because they can have a detrimental effect
on clutch operation. Please do not hesitate to
contact your authorised BMW Motorrad dealer
if you have any questions relating the choice of a
suitable engine oil for your motorcycle.
10140zTechnical data

K
Keys, 44
L
Laying up, 134
LightsHeadlight flasher, 16, 54
High-beam headlight, 54
Low-beam headlight, 54
Parking light, 55
Side light, 54
Luggage Correct loading, 91
Luggage loops, 68
M
Maintenance General instructions, 98
Mirrors Adjusting, 60
Motorcycle General view, left side, 11
General view, right side, 13
Laying up, 134
Restoring to use, 134 Multifunction display, 18
Overview, 22
O
Odometer and tripmeters Resetting, 48
Selecting readings, 47
On-board computer Ambient temperature, 50
Average consumption, 51
Average speed, 51
Oil level, 53
Range, 52
Selecting readings, 50
Warning, 29
P
Power socket, 11
Pre-ride check, 73
R
Rear-wheel drive Technical data, 142
Rear-wheel stand, 116
Refuelling, 79 Reserve
Warning, 26
Residual range, 49
Restoring to use, 134
Rev. counter, 18
Rims Test, 107
Running gear Technical data, 142
Running in, 75
S
Seat Installation, 67
Lock, 11
Removal, 66
Service, 152 Status indicators on the
display, 22
Service Card, 152
Side stand For starting, 72
Spark plugs, 146
Speedometer, 18
12163zIndex

The most important data for a filling-station stop can be found in the following chart:Fuel
Recommended fuel grade98 ROZ/RON, Premium plus un-
leaded
95 ROZ/RON, Premium unleaded
(fuel grade, usable with power-
and consumption-related restric-
tions)
Usable fuel capacity 19 l
Reserve fuel 4l
Tyre pressure
Tyre pressure, front 2.5 bar, one-up, tyre cold
2.5 bar, two-up and/or with lug-
gage, tyre cold
Tyre pressure, rear 2.9 bar, one-up, tyre cold
2.9 bar, two-up and/or with lug-
gage, tyre cold
BMW recommends
Order No. 01 41 7 712 101
07.2007, 4th edition
