2007 AUDI A3 engine

Downloaded from www.Manualslib.com manuals search engine Cruise control system
When the system is switched on, the indicator
lamp appears in the instrument cluster.
To switch on/off:Pull/press lever .
To set speed: Press button .
To adjust stored speed: Press lever up (faster)
or down (slower).
2
1
Technology
hill hold assist
Driving away on a slope
If you press and hold the foot brake for several seconds on a gradient,
this will prevent the vehicle from rolling back. When you take your foot
off the brake pedal, the vehicle will be held for a moment longer,
allowing you to drive off.
1
2
1
2
open sky sun roof
Comfort position: Briefly press rear end of
switch twice.
To open/close: Press rear end of switch
(open) or front end of switch (close)
until the open sky sun roof is fully open/
closed or has reached the desired position.
To tilt open/close: Briefly press rear or front
end of switch or .
2
2
1
1
1

Downloaded from www.Manualslib.com manuals search engine 1
22
Audi Navigation System plus
ComponentsDriver information systemMulti-function steering wheel
Scroll the left thumbwheel to select a menu item in the
driver information system. Press the thumbwheel to
confirm the selection.
Press the MODE button to switch between the active audio
source and the navigation and telephone functions.
Briefly press the button to switch on the speech
dialogue system.
Speak after the , e.g. say to call up the
possible operating commands.
Press and hold the talk button to switch off the speech
dialogue system.
Scroll the right thumbwheel to adjust the volume. If you
press the right thumbwheel, the last navigation cue will be
repeated.
2
1

Downloaded from www.Manualslib.com manuals search engine 3
Infotainment
Display
Function selector buttons
Press one of the buttons
(e.g. RADIO) to activate
the desired mode.
ON/OFF button
To switch on:Press briefly.
To adjust volume: Turn.
To mute: Press briefly.
To switch off: Press and hold.
Control buttons
To activate one of the functions
shown in the four corners of
the display, press the control
button for that corner of the display.
Rotary pushbutton
To select a menu item on display :
Turn the rotary pushbutton.
To confirm selection:
Press the rotary pushbutton.3
7
5
6
4
3
Operating logic
The operating logic for
accessing the functions is
always the same.
To call up the menu in a
corner of the display: Press
the corresponding button.
To select: Turn the rotary
pushbutton.
To confirm: Press the rotary
pushbutton.A
C
B
C
A
B
5
7
6
6
4

Downloaded from www.Manualslib.com manuals search engine 6
4
Press the RADIO function selector
button.1Press the rotary pushbutton to confirm.3
Press the rotary pushbutton to confirm.6
Turn the rotary pushbutton and select
the desired station.2
Press the control button for ”Memory”.
The control button corresponds to the
top left-hand corner of the display.4
Storing a radio station
12
Turn the rotary pushbutton and select
the desired memory position.5
3
5

Downloaded from www.Manualslib.com manuals search engine 5
8
Infotainment
GermanyM
MÜNCH-LEU…
MÜNCHAUR…
MÜNCHBERG
MÜNCHEBERG
DELLIST
N
MÜNCHEN
MÜNCH-LEU…
MÜNCHAUR…
MÜNCHBERG
MÜNCHEBERG
DEL
Press the NAV function selector button.1Turn the rotary pushbutton and select
the first letter of the destination town.
Press the rotary pushbutton to confirm.
5
4
Select ”Start route guidance” from the
menu.
Press the rotary pushbutton to confirm.
The route will be calculated.
10
9
Turn the rotary pushbutton and select
”Town/ZIP”.
Press the rotary pushbutton to confirm.
3
2
Repeat the above step to enter the
remaining letters of the destination
town until the name of the desired
town appears on the display.6When you have entered the town, turn
the rotary pushbutton and select ”OK”.
Press the rotary pushbutton to confirm.
8
7
1
6MÜNCH-LEU…
MÜNCHAUR…
MÜNCHBERG
MÜNCHEBERG
DELLIST
NMÜN10MÜNCHEN/MÜNCHEN (…
CentreGermany
Starting the navigation system
3
2
7
4
9

Downloaded from www.Manualslib.com manuals search engine Functions
Establishing a BluetoothTMconnection
for a mobile phone
You can quickly connect a Bluetooth
mobile phone to the onboard phone
system on your navigation system:
p Switch on the ignition, navigation
system and mobile phone.
p On your mobile phone, select the menu
that looks for

Bluetooth devices (e.g.
”Hands-free”).
p On the mobile phone, select ”Audi UHV”
and confirm.
p Enter the PIN ”1234” on your

mobile
phone.
Memory cards
Loading:
p Press the button to open the
display.
p Insert the memory

card into the reader
slot as shown in the illustration and
pr

ess in the memory card until you feel
it click into place.
Removing:
p Press the button to open the
display.
p Pr

ess in the memory card. The card will
be released and c
an then be removed
from the reader slot.
Bluetooth©
Infotainment

Downloaded from www.Manualslib.com manuals search engine Warning and indicator lamps
Door/s open
Tailgate open
Brake pads worn1)
Diesel particulate filter
obstructed
Light sensor/
rain sensor defective
adaptive light defective
Headlight range control
defective1)
Check engine oil level
(lights up permanently)
Engine oil sensor
defective1)(flashes)
Press clutch pedal
Washer fluid level low
Cruise control system
Airbag system1)
Alternator1)
Seat belt warning lamp
Fault in brake system or
handbrake is applied
Anti-lock brake system1)
Electro-mechanical
power steering
Tyre pressure too low
(check without delay)
Engine management1)or
Glow plug system1)
Electronic stabilisation
program (ESP)
Emission control system
Main beam headlights
Trailer turn signals
Turn signals/
hazard warning lights
Fuel level low
Engine oil pressure
too low1)
Bonnet open
Warning and indicator lamps
© 2007 AUDI AGAUDI AG reserves the right to alter any part of the vehicle, its equipment and technical specifications.
No legal commitment can be implied by the information, illustrations or descriptions in this publication.
No part of this publication may be reprinted, reproduced or translated without the written permission
of AUDI AG. All rights under the laws of copyright are expressly reserved by AUDI AG. Subject to alter ation
and amendment. Concept and layout: Pfriemer GmbH. Printed in Germany. If one of these red symbols lights up in the
display while you are driving, stop the car
immediately, switch off the engine and refer to
the Owner’s Manual.
Electro-mechanical
power steering
Fault in the brake system
Fault in the cooling
system
Engine oil pressure
too low
Warning symbols
1)If this warning lamp lights up when driving, please contact a qualified workshop without delay.

Downloaded from www.Manualslib.com manuals search engine Audi A3 A3 Sportback
Audi S3
Kurzanleitung
englisch 11.07
282.562.755.20
www.audi.com
